- Dynamo
-
HC-Cargo Dynamo
- Dynamo
-
HC-Cargo Dynamo
Varenr.: F032112679
HC-Cargo Dynamo
Voltage: 14, Amp: 110, Rotation: CW, Mount. bøssing dist.: 66.30
Beskrivelse
Spenningspotensial: 14
Amp.: 110
Terminal: W
Drevskive fordeling: 46.50
Bredde/festearm: 27.70
Festebrakett avstand: 66.30
Brakettøye: 10.20
Drev. justering brakett bøyle pos.: 5
Drev. justering brakett hull pos.: 8.30
Drevskive dia.: 55.00
Spor/drevskive: 6
Radius: 85.00
Radius 2: 100.00
B+: M6
Posisjon/B+ i min.: 15
D+ Størrelse: M5
Rotasjon: medur
W plugg type: 6.30
Total lengde mm: 190.00
Drevskive: SP
Regulator type: IR
Produktinfo: BN
Service: Renault
Amp.: 110
Terminal: W
Drevskive fordeling: 46.50
Bredde/festearm: 27.70
Festebrakett avstand: 66.30
Brakettøye: 10.20
Drev. justering brakett bøyle pos.: 5
Drev. justering brakett hull pos.: 8.30
Drevskive dia.: 55.00
Spor/drevskive: 6
Radius: 85.00
Radius 2: 100.00
B+: M6
Posisjon/B+ i min.: 15
D+ Størrelse: M5
Rotasjon: medur
W plugg type: 6.30
Total lengde mm: 190.00
Drevskive: SP
Regulator type: IR
Produktinfo: BN
Service: Renault
Filer
Spesifikasjon
| B+ | M6 |
|---|---|
| Mount. bracket dist. | 66.30 |
| Belt. adj. bracket hole 1 | 8.30 |
| Belt. adj. brackethole pos. | 5 |
| Bracket hole | 10.20 |
| Position/B+ in min. | 15 |
| Prod. info | BN |
| Pulley | SP |
| Pulley dia. | 55.00 |
| Pulley dist. | 46.50 |
| Radius | 85.00 |
| D+ Size | M5 |
| Radius 2 | 100.00 |
| Regulator type | IR |
| Rotation | CW |
| Servicing | Renault |
| Grooves/pulley | 6 |
| Terminal | W |
| Voltage | 14 |
| W plug type | 6.30 |
| Total length | 190.00 mm |
| Width/holder arm | 27.70 |
| Amp | 110 |
-
OEM
a13vi153, a13vi164, a13vi167, a13vi210, a13vi57, aak5521, aan5139, F032112679, 11.203.129, 11.203.227, 1036ir, 1986A01361, 2541610, 2541610G, 2541887, 2541903, 2541903A, 2541906, 2541906A, 2541906B, 2541982, 2541982A, 2541982C, 6201811M91, 8111571, 8111811, 8111888, 8111945, 8602097, 8602185, 7700414371, 7700416958, 7700416985, 7700424582, 7700424595, 7700436626, 7700840260, 7700857073, 7701352301, 7701352302, 7701352354, 7701499610, 7701499611 -
Konkurrentreferens
A3089, A3287, A3297, ALT14048, ALT14065, ALT14134, BAO3216, BAO3226, BAO3255, CAL15159, CAL15192, CAL15214, DRA3357, dra3358, dra3543, DRA3718, DRA3726, dra3727, FRA301, IA1091, IA1126, LRA01811, lrb00202, lrb00323, MG325, MG577, NA461, NA542, NA544, QA2269, va353, 8EL011360-861, 8EL011710-021, 8el732708-001, 28-2607, 28-2895, 28-3629, 230.130.1102, 3142N, 3142R, 4406, 4959, 5010, 21200N, 21200RW, 56313, 118789, 200104, 200116, 200123, 200191, 210049, 210049A, 301036RI, 301309RI, 436467, 436662, 436729, 746107, 746120, 746846, 746854, 746907, 746910, 746920, 747007, 9040081, 12040000, 12040080, 12042200, 12042210, 32042201, 0986040081, 0986042201, 0986042211, 943356961010, 944390400810 -
NormaliseratArtNr
a13vi153, a13vi164, a13vi167, a13vi210, a13vi57, a3089, a3287, a3297, aak5521, aan5139, alt14048, alt14065, alt14134, bao3216, bao3226, bao3255, cal15159, cal15192, cal15214, dra3357, dra3358, dra3543, dra3718, dra3726, dra3727, f032112679, fra301, ia1091, ia1126, lra01811, lrb00202, lrb00323, mg325, mg577, na461, na542, na544, qa2269, va353, 8el011360861, 8el011710021, 8el732708001, 1036ir, 1986a01361, 3142n, 3142r, 4406, 4959, 5010, 21200n, 21200rw, 56313, 118789, 200104, 200116, 200123, 200191, 210049, 210049a, 282607, 282895, 283629, 301036ri, 301309ri, 436467, 436662, 436729, 746107, 746120, 746846, 746854, 746907, 746910, 746920, 747007, 2541610, 2541610g, 2541887, 2541903, 2541903a, 2541906, 2541906a, 2541906b, 2541982, 2541982a, 2541982c, 6201811m91, 8111571, 8111811, 8111888, 8111945, 8602097, 8602185, 9040081, 11203129, 11203227, 12040000, 12040080, 12042200, 12042210, 32042201, 0986040081, 0986042201, 0986042211, 2301301102, 7700414371, 7700416958, 7700416985, 7700424582, 7700424595, 7700436626, 7700840260, 7700857073, 7701352301, 7701352302, 7701352354, 7701499610, 7701499611, 943356961010, 944390400810 -
Passar modeller
Renault Model: Espace Model series: Espace Size of motor: 2.0 Brand of engine: F3R728 Type description: JE0A Body: MPV From date: 01-11-1996 To date: 01-10-2000 Fuel: Gasoline Approved: Yes Renault Model: Espace Model series: Espace Size of motor: 2.0 Brand of engine: F3R729 Type description: JE0A Body: MPV From date: 01-11-1996 To date: 01-10-2000 Fuel: Gasoline Approved: Yes Renault Model: Espace Model series: Espace Type of engine: TD Size of motor: 2.2 Brand of engine: G8T714 Type description: JE0E,JE0H,JE0P Body: MPV From date: 01-11-1996 To date: 01-10-2000 Fuel: Diesel Approved: Yes Renault Model: Espace Model series: Espace Type of engine: TD Size of motor: 2.2 Brand of engine: G8T716 Type description: JE0E,JE0H,JE0P Body: MPV From date: 01-11-1996 To date: 01-10-2000 Fuel: Diesel Approved: Yes Renault Model: Espace Model series: Espace Type of engine: TD Size of motor: 2.2 Brand of engine: G8T760 Type description: JE0E,JE0H,JE0P Body: MPV From date: 01-11-1996 To date: 01-10-2000 Fuel: Diesel Approved: Yes Renault Model: Laguna Model series: Laguna Model type: DTi Type of engine: Diesel Size of motor: 1.9 Brand of engine: F9Q716 Type description: B56_, 556_ Body: Hatchback Fuel: Diesel Approved: Yes Renault Model: Laguna Model series: Laguna Model type: RT Size of motor: 1.8 Brand of engine: F3P670 Type description: B56 Body: Hatchback From date: 01-08-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Model type: RT Size of motor: 1.8 Brand of engine: F3P678 Type description: B56 Body: Hatchback From date: 01-08-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Model type: RT Size of motor: 1.8 Brand of engine: F3P720 Type description: B56 Body: Hatchback From date: 01-08-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Model type: RT Size of motor: 1.8 Brand of engine: F3P724 Type description: B56 Body: Hatchback From date: 01-08-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Size of motor: 1.8 Brand of engine: F3P670 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Manufacture type: Grandtour Renault Model: Laguna Model series: Laguna Size of motor: 1.8 Brand of engine: F3P678 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Manufacture type: Grandtour Renault Model: Laguna Model series: Laguna Size of motor: 1.8 Brand of engine: F3P720 Type description: B56A,B Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Size of motor: 1.8 Brand of engine: F3P720 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Manufacture type: Grandtour Renault Model: Laguna Model series: Laguna Size of motor: 1.8 Brand of engine: F3P724 Type description: B56A,B Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Size of motor: 1.8 Brand of engine: F3P724 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Manufacture type: Grandtour Renault Model: Laguna Model series: Laguna Size of motor: 2.0 Brand of engine: F3R611 Type description: B56U Body: Hatchback From date: 01-03-1999 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Size of motor: 2.0 Brand of engine: F3R722 Type description: B56_ Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Size of motor: 2.0 Brand of engine: F3R722 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Manufacture type: Grandtour Renault Model: Laguna Model series: Laguna Size of motor: 2.0 Brand of engine: F3R723 Type description: B56_ Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Size of motor: 2.0 Brand of engine: F3R723 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Manufacture type: Grandtour Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T706 Type description: B56F Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Diesel Approved: Yes Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T752 Type description: B56F Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Diesel Approved: Yes Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T752 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Diesel Approved: Yes Manufacture type: grandtour Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T760 Type description: K56 Body: Estate From date: 01-03-1996 To date: 01-03-2001 Fuel: Diesel Approved: Yes Manufacture type: grandtour Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T790 Type description: B56F Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Diesel Approved: Yes Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T794 Type description: B56F Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Diesel Approved: Yes Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T794 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Diesel Approved: Yes Manufacture type: grandtour Renault Model: Laguna Model series: Laguna Type of engine: TD Size of motor: 2.2 Brand of engine: G8T760 Type description: B56 Body: Hatchback From date: 01-03-1996 To date: 01-03-2001 Fuel: Diesel Approved: Yes Renault Model: Megane Model series: Megane Model type: Eco Type of engine: Diesel Size of motor: 1.9 Brand of engine: F8Q620 Type description: B/SA0U,BA0A Body: Hatchback From date: 01-01-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Renault Model: Megane Model series: Megane Model type: Eco Type of engine: Diesel Size of motor: 1.9 Brand of engine: F8Q624 Type description: B/SA0U,BA0A Body: Hatchback From date: 01-01-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Renault Model: Megane Model series: Megane Scenic Size of motor: 2.0 Brand of engine: F3R750 Type description: JA0/1_ Body: MPV From date: 01-01-1999 To date: 01-12-2001 Fuel: Petrol Approved: Yes Renault Model: Megane Model series: Megane Size of motor: 2.0 Brand of engine: F3R750 Type description: EA0G Body: Convertible From date: 01-04-1997 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Size of motor: 2.0 Brand of engine: F3R796 Type description: LA0/1_ From date: 01-05-1998 To date: 01-05-2001 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Type of engine: Diesel Size of motor: 1.9 Brand of engine: F8Q620 Type description: LA0A,LA0U From date: 01-09-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: Diesel Size of motor: 1.9 Brand of engine: F8Q624 Type description: LA0A,LA0U From date: 01-09-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: Diesel Size of motor: 1.9 Brand of engine: F8Q790 Type description: JA0J Body: MPV From date: 01-03-1997 To date: 01-09-1999 Fuel: Diesel Approved: Yes Manufacture type: scenic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R750 Body: Coupe From date: 01-03-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: coach Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R750 Body: Hatchback From date: 01-01-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R750 Body: MPV From date: 01-01-1997 To date: 01-09-1999 Fuel: Gasoline Approved: Yes Manufacture type: scenic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R750 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R750 Type description: BA0/1 Body: Hatchback From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R750 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R751 Body: Coupe From date: 01-03-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: coach Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R751 Body: MPV From date: 01-01-1997 To date: 01-09-1999 Fuel: Gasoline Approved: Yes Manufacture type: scenic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R751 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R751 Type description: BA0/1 Body: Hatchback From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R751 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R752 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R752 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R791 Body: Coupe From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: coach Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R791 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R791 Type description: EA0G Body: Convertible From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R791 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R796 Body: Coupe From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: coach Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R796 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R796 Type description: EA0G Body: Convertible From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R796 Type description: JA0G Body: MPV From date: 01-01-1999 To date: 01-09-1999 Fuel: Gasoline Approved: Yes Manufacture type: scenic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R796 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R797 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R797 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R798 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R798 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: TD Size of motor: 1.9 Brand of engine: F8Q784 Body: Hatchback From date: 01-01-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Renault Model: Megane Model series: Megane Type of engine: TD Size of motor: 1.9 Brand of engine: F8Q784 From date: 01-09-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: TD Size of motor: 1.9 Brand of engine: F8Q784 Type description: JA0K,JA0Y Body: MPV From date: 01-01-1997 To date: 01-09-1999 Fuel: Diesel Approved: Yes Manufacture type: scenic Renault Model: Megane Model series: Megane Type of engine: TD Size of motor: 1.9 Brand of engine: F8Q784 Type description: LA0K,LA0Y From date: 01-09-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: TD Size of motor: 1.9 Brand of engine: F8Q786 Type description: JA0K,JA0Y Body: MPV From date: 01-01-1997 To date: 01-09-1999 Fuel: Diesel Approved: Yes Manufacture type: scenic Renault Model: Megane Model series: Megane Type of engine: TD Size of motor: 1.9 Brand of engine: F8Q786 Type description: LA0K,LA0Y From date: 01-09-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Manufacture type: classic Renault Model: Megane Scenic Model series: Megane Scenic Type of engine: Diesel Size of motor: 1.9 Brand of engine: F8Q786 Type description: JA0/1_ Body: Van From date: 01-01-1997 To date: 01-09-1999 Fuel: Diesel Approved: Yes Renault Model: Safrane Model series: Safrane Type of engine: TD Size of motor: 2.2 Brand of engine: G8T740 Type description: B54 Body: Hatchback From date: 01-07-1996 To date: 01-12-2000 Fuel: Diesel Approved: Yes Renault Model: Sc nic Model series: Sc nic Type of engine: i Size of motor: 2.0 Brand of engine: F3R... Type description: JA0G From date: 01-11-1996 Fuel: Gasoline Approved: Yes Volvo Model: S40 Model series: S40 Type of engine: Diesel Di Size of motor: 1.9 Brand of engine: D4192T3 Type description: VS From date: 01-07-2000 To date: 01-12-2003 Fuel: Diesel Approved: Yes Volvo Model: S40 Model series: S40 Type of engine: Diesel Di Size of motor: 1.9 Brand of engine: D4192T4 Type description: VS From date: 01-07-2000 To date: 01-12-2003 Fuel: Diesel Approved: Yes Volvo Model: S40 Model series: S40 Type of engine: TD Size of motor: 1.9 Brand of engine: D4192T From date: 01-07-1995 To date: 01-08-1999 Fuel: Diesel Approved: Yes Volvo Model: V40 Model series: V40 Type of engine: Diesel Di Size of motor: 1.9 Brand of engine: D4192T3 Type description: VW Body: Estate From date: 01-07-2000 To date: 01-06-2004 Fuel: Diesel Approved: Yes Volvo Model: V40 Model series: V40 Type of engine: Diesel Di Size of motor: 1.9 Brand of engine: D4192T4 Type description: VW Body: Estate From date: 01-07-2000 To date: 01-06-2004 Fuel: Diesel Approved: Yes Volvo Model: V40 Model series: V40 Type of engine: TD Size of motor: 1.9 Brand of engine: D4192T Body: Estate From date: 01-07-1995 To date: 01-08-1999 Fuel: Diesel Approved: Yes 1 / 16
-
Beskrivelse
Spenningspotensial: 14
Amp.: 110
Terminal: W
Drevskive fordeling: 46.50
Bredde/festearm: 27.70
Festebrakett avstand: 66.30
Brakettøye: 10.20
Drev. justering brakett bøyle pos.: 5
Drev. justering brakett hull pos.: 8.30
Drevskive dia.: 55.00
Spor/drevskive: 6
Radius: 85.00
Radius 2: 100.00
B+: M6
Posisjon/B+ i min.: 15
D+ Størrelse: M5
Rotasjon: medur
W plugg type: 6.30
Total lengde mm: 190.00
Drevskive: SP
Regulator type: IR
Produktinfo: BN
Service: RenaultFiler
-
Spesifikasjon
B+ M6 Mount. bracket dist. 66.30 Belt. adj. bracket hole 1 8.30 Belt. adj. brackethole pos. 5 Bracket hole 10.20 Position/B+ in min. 15 Prod. info BN Pulley SP Pulley dia. 55.00 Pulley dist. 46.50 Radius 85.00 D+ Size M5 Radius 2 100.00 Regulator type IR Rotation CW Servicing Renault Grooves/pulley 6 Terminal W Voltage 14 W plug type 6.30 Total length 190.00 mm Width/holder arm 27.70 Amp 110 -
Kjøretøymatching
-
OEM
a13vi153, a13vi164, a13vi167, a13vi210, a13vi57, aak5521, aan5139, F032112679, 11.203.129, 11.203.227, 1036ir, 1986A01361, 2541610, 2541610G, 2541887, 2541903, 2541903A, 2541906, 2541906A, 2541906B, 2541982, 2541982A, 2541982C, 6201811M91, 8111571, 8111811, 8111888, 8111945, 8602097, 8602185, 7700414371, 7700416958, 7700416985, 7700424582, 7700424595, 7700436626, 7700840260, 7700857073, 7701352301, 7701352302, 7701352354, 7701499610, 7701499611 -
Konkurrentreferens
A3089, A3287, A3297, ALT14048, ALT14065, ALT14134, BAO3216, BAO3226, BAO3255, CAL15159, CAL15192, CAL15214, DRA3357, dra3358, dra3543, DRA3718, DRA3726, dra3727, FRA301, IA1091, IA1126, LRA01811, lrb00202, lrb00323, MG325, MG577, NA461, NA542, NA544, QA2269, va353, 8EL011360-861, 8EL011710-021, 8el732708-001, 28-2607, 28-2895, 28-3629, 230.130.1102, 3142N, 3142R, 4406, 4959, 5010, 21200N, 21200RW, 56313, 118789, 200104, 200116, 200123, 200191, 210049, 210049A, 301036RI, 301309RI, 436467, 436662, 436729, 746107, 746120, 746846, 746854, 746907, 746910, 746920, 747007, 9040081, 12040000, 12040080, 12042200, 12042210, 32042201, 0986040081, 0986042201, 0986042211, 943356961010, 944390400810 -
NormaliseratArtNr
a13vi153, a13vi164, a13vi167, a13vi210, a13vi57, a3089, a3287, a3297, aak5521, aan5139, alt14048, alt14065, alt14134, bao3216, bao3226, bao3255, cal15159, cal15192, cal15214, dra3357, dra3358, dra3543, dra3718, dra3726, dra3727, f032112679, fra301, ia1091, ia1126, lra01811, lrb00202, lrb00323, mg325, mg577, na461, na542, na544, qa2269, va353, 8el011360861, 8el011710021, 8el732708001, 1036ir, 1986a01361, 3142n, 3142r, 4406, 4959, 5010, 21200n, 21200rw, 56313, 118789, 200104, 200116, 200123, 200191, 210049, 210049a, 282607, 282895, 283629, 301036ri, 301309ri, 436467, 436662, 436729, 746107, 746120, 746846, 746854, 746907, 746910, 746920, 747007, 2541610, 2541610g, 2541887, 2541903, 2541903a, 2541906, 2541906a, 2541906b, 2541982, 2541982a, 2541982c, 6201811m91, 8111571, 8111811, 8111888, 8111945, 8602097, 8602185, 9040081, 11203129, 11203227, 12040000, 12040080, 12042200, 12042210, 32042201, 0986040081, 0986042201, 0986042211, 2301301102, 7700414371, 7700416958, 7700416985, 7700424582, 7700424595, 7700436626, 7700840260, 7700857073, 7701352301, 7701352302, 7701352354, 7701499610, 7701499611, 943356961010, 944390400810 -
Passar modeller
Renault Model: Espace Model series: Espace Size of motor: 2.0 Brand of engine: F3R728 Type description: JE0A Body: MPV From date: 01-11-1996 To date: 01-10-2000 Fuel: Gasoline Approved: Yes Renault Model: Espace Model series: Espace Size of motor: 2.0 Brand of engine: F3R729 Type description: JE0A Body: MPV From date: 01-11-1996 To date: 01-10-2000 Fuel: Gasoline Approved: Yes Renault Model: Espace Model series: Espace Type of engine: TD Size of motor: 2.2 Brand of engine: G8T714 Type description: JE0E,JE0H,JE0P Body: MPV From date: 01-11-1996 To date: 01-10-2000 Fuel: Diesel Approved: Yes Renault Model: Espace Model series: Espace Type of engine: TD Size of motor: 2.2 Brand of engine: G8T716 Type description: JE0E,JE0H,JE0P Body: MPV From date: 01-11-1996 To date: 01-10-2000 Fuel: Diesel Approved: Yes Renault Model: Espace Model series: Espace Type of engine: TD Size of motor: 2.2 Brand of engine: G8T760 Type description: JE0E,JE0H,JE0P Body: MPV From date: 01-11-1996 To date: 01-10-2000 Fuel: Diesel Approved: Yes Renault Model: Laguna Model series: Laguna Model type: DTi Type of engine: Diesel Size of motor: 1.9 Brand of engine: F9Q716 Type description: B56_, 556_ Body: Hatchback Fuel: Diesel Approved: Yes Renault Model: Laguna Model series: Laguna Model type: RT Size of motor: 1.8 Brand of engine: F3P670 Type description: B56 Body: Hatchback From date: 01-08-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Model type: RT Size of motor: 1.8 Brand of engine: F3P678 Type description: B56 Body: Hatchback From date: 01-08-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Model type: RT Size of motor: 1.8 Brand of engine: F3P720 Type description: B56 Body: Hatchback From date: 01-08-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Model type: RT Size of motor: 1.8 Brand of engine: F3P724 Type description: B56 Body: Hatchback From date: 01-08-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Size of motor: 1.8 Brand of engine: F3P670 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Manufacture type: Grandtour Renault Model: Laguna Model series: Laguna Size of motor: 1.8 Brand of engine: F3P678 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Manufacture type: Grandtour Renault Model: Laguna Model series: Laguna Size of motor: 1.8 Brand of engine: F3P720 Type description: B56A,B Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Size of motor: 1.8 Brand of engine: F3P720 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Manufacture type: Grandtour Renault Model: Laguna Model series: Laguna Size of motor: 1.8 Brand of engine: F3P724 Type description: B56A,B Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Size of motor: 1.8 Brand of engine: F3P724 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Manufacture type: Grandtour Renault Model: Laguna Model series: Laguna Size of motor: 2.0 Brand of engine: F3R611 Type description: B56U Body: Hatchback From date: 01-03-1999 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Size of motor: 2.0 Brand of engine: F3R722 Type description: B56_ Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Size of motor: 2.0 Brand of engine: F3R722 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Manufacture type: Grandtour Renault Model: Laguna Model series: Laguna Size of motor: 2.0 Brand of engine: F3R723 Type description: B56_ Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Renault Model: Laguna Model series: Laguna Size of motor: 2.0 Brand of engine: F3R723 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Gasoline Approved: Yes Manufacture type: Grandtour Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T706 Type description: B56F Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Diesel Approved: Yes Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T752 Type description: B56F Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Diesel Approved: Yes Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T752 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Diesel Approved: Yes Manufacture type: grandtour Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T760 Type description: K56 Body: Estate From date: 01-03-1996 To date: 01-03-2001 Fuel: Diesel Approved: Yes Manufacture type: grandtour Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T790 Type description: B56F Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Diesel Approved: Yes Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T794 Type description: B56F Body: Hatchback From date: 01-11-1993 To date: 01-03-2001 Fuel: Diesel Approved: Yes Renault Model: Laguna Model series: Laguna Type of engine: Diesel Size of motor: 2.2 Brand of engine: G8T794 Type description: K56 Body: Estate From date: 01-09-1995 To date: 01-03-2001 Fuel: Diesel Approved: Yes Manufacture type: grandtour Renault Model: Laguna Model series: Laguna Type of engine: TD Size of motor: 2.2 Brand of engine: G8T760 Type description: B56 Body: Hatchback From date: 01-03-1996 To date: 01-03-2001 Fuel: Diesel Approved: Yes Renault Model: Megane Model series: Megane Model type: Eco Type of engine: Diesel Size of motor: 1.9 Brand of engine: F8Q620 Type description: B/SA0U,BA0A Body: Hatchback From date: 01-01-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Renault Model: Megane Model series: Megane Model type: Eco Type of engine: Diesel Size of motor: 1.9 Brand of engine: F8Q624 Type description: B/SA0U,BA0A Body: Hatchback From date: 01-01-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Renault Model: Megane Model series: Megane Scenic Size of motor: 2.0 Brand of engine: F3R750 Type description: JA0/1_ Body: MPV From date: 01-01-1999 To date: 01-12-2001 Fuel: Petrol Approved: Yes Renault Model: Megane Model series: Megane Size of motor: 2.0 Brand of engine: F3R750 Type description: EA0G Body: Convertible From date: 01-04-1997 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Size of motor: 2.0 Brand of engine: F3R796 Type description: LA0/1_ From date: 01-05-1998 To date: 01-05-2001 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Type of engine: Diesel Size of motor: 1.9 Brand of engine: F8Q620 Type description: LA0A,LA0U From date: 01-09-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: Diesel Size of motor: 1.9 Brand of engine: F8Q624 Type description: LA0A,LA0U From date: 01-09-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: Diesel Size of motor: 1.9 Brand of engine: F8Q790 Type description: JA0J Body: MPV From date: 01-03-1997 To date: 01-09-1999 Fuel: Diesel Approved: Yes Manufacture type: scenic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R750 Body: Coupe From date: 01-03-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: coach Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R750 Body: Hatchback From date: 01-01-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R750 Body: MPV From date: 01-01-1997 To date: 01-09-1999 Fuel: Gasoline Approved: Yes Manufacture type: scenic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R750 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R750 Type description: BA0/1 Body: Hatchback From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R750 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R751 Body: Coupe From date: 01-03-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: coach Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R751 Body: MPV From date: 01-01-1997 To date: 01-09-1999 Fuel: Gasoline Approved: Yes Manufacture type: scenic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R751 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R751 Type description: BA0/1 Body: Hatchback From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R751 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R752 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R752 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R791 Body: Coupe From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: coach Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R791 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R791 Type description: EA0G Body: Convertible From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R791 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R796 Body: Coupe From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: coach Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R796 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R796 Type description: EA0G Body: Convertible From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R796 Type description: JA0G Body: MPV From date: 01-01-1999 To date: 01-09-1999 Fuel: Gasoline Approved: Yes Manufacture type: scenic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R796 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R797 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R797 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R798 Type description: (LA0/1_) From date: 01-03-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: i Size of motor: 2.0 Brand of engine: F3R798 Type description: LA07,LA0G From date: 01-09-1996 To date: 01-08-2003 Fuel: Gasoline Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: TD Size of motor: 1.9 Brand of engine: F8Q784 Body: Hatchback From date: 01-01-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Renault Model: Megane Model series: Megane Type of engine: TD Size of motor: 1.9 Brand of engine: F8Q784 From date: 01-09-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: TD Size of motor: 1.9 Brand of engine: F8Q784 Type description: JA0K,JA0Y Body: MPV From date: 01-01-1997 To date: 01-09-1999 Fuel: Diesel Approved: Yes Manufacture type: scenic Renault Model: Megane Model series: Megane Type of engine: TD Size of motor: 1.9 Brand of engine: F8Q784 Type description: LA0K,LA0Y From date: 01-09-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Manufacture type: classic Renault Model: Megane Model series: Megane Type of engine: TD Size of motor: 1.9 Brand of engine: F8Q786 Type description: JA0K,JA0Y Body: MPV From date: 01-01-1997 To date: 01-09-1999 Fuel: Diesel Approved: Yes Manufacture type: scenic Renault Model: Megane Model series: Megane Type of engine: TD Size of motor: 1.9 Brand of engine: F8Q786 Type description: LA0K,LA0Y From date: 01-09-1996 To date: 01-08-2003 Fuel: Diesel Approved: Yes Manufacture type: classic Renault Model: Megane Scenic Model series: Megane Scenic Type of engine: Diesel Size of motor: 1.9 Brand of engine: F8Q786 Type description: JA0/1_ Body: Van From date: 01-01-1997 To date: 01-09-1999 Fuel: Diesel Approved: Yes Renault Model: Safrane Model series: Safrane Type of engine: TD Size of motor: 2.2 Brand of engine: G8T740 Type description: B54 Body: Hatchback From date: 01-07-1996 To date: 01-12-2000 Fuel: Diesel Approved: Yes Renault Model: Sc nic Model series: Sc nic Type of engine: i Size of motor: 2.0 Brand of engine: F3R... Type description: JA0G From date: 01-11-1996 Fuel: Gasoline Approved: Yes Volvo Model: S40 Model series: S40 Type of engine: Diesel Di Size of motor: 1.9 Brand of engine: D4192T3 Type description: VS From date: 01-07-2000 To date: 01-12-2003 Fuel: Diesel Approved: Yes Volvo Model: S40 Model series: S40 Type of engine: Diesel Di Size of motor: 1.9 Brand of engine: D4192T4 Type description: VS From date: 01-07-2000 To date: 01-12-2003 Fuel: Diesel Approved: Yes Volvo Model: S40 Model series: S40 Type of engine: TD Size of motor: 1.9 Brand of engine: D4192T From date: 01-07-1995 To date: 01-08-1999 Fuel: Diesel Approved: Yes Volvo Model: V40 Model series: V40 Type of engine: Diesel Di Size of motor: 1.9 Brand of engine: D4192T3 Type description: VW Body: Estate From date: 01-07-2000 To date: 01-06-2004 Fuel: Diesel Approved: Yes Volvo Model: V40 Model series: V40 Type of engine: Diesel Di Size of motor: 1.9 Brand of engine: D4192T4 Type description: VW Body: Estate From date: 01-07-2000 To date: 01-06-2004 Fuel: Diesel Approved: Yes Volvo Model: V40 Model series: V40 Type of engine: TD Size of motor: 1.9 Brand of engine: D4192T Body: Estate From date: 01-07-1995 To date: 01-08-1999 Fuel: Diesel Approved: Yes 1 / 16
-
