- Dynamo
-
HC-Cargo Dynamo
- Dynamo
-
HC-Cargo Dynamo
Varenr.: F032116298
HC-Cargo Dynamo
Spenningsregulator: 14, Amp: 140, Rotasjon: med urviseren, Monteringsbrakett avstand.: 62.00
Beskrivelse
HC-Cargo Dynamo 14V - 140A, 6gr 52mm
Spenningsnivå: 14
Ampere: 140
Bøssing av remskive: 29.50
Bredde/holderarm: 14.00
Festebrakett avstand: 62.00
Brakettshull: 8.50
Remjustering brakettshull pos.: 45
Remjustering brakettshull 1: 8.50
Remjustering brakettshull 2: M8
Remskivediameter: 52.00
Groover/remskive: 6
Radius: 90.00
Radius 2: 90.00
B+: M8
Posisjon/B+ i min.: 50
Rotasjon: med urviseren
Stikkontakt nr.: PL125
Total lengde mm: 202.00
Klemmer: COM
Kommunikasjon: LIN
Remskive: SP/FW
Regulator type: IR
Anmerkninger: Denne alternatoren har en COM-klemme på regulatoren. Det anbefales at OEM-nummer brukes for å kontrollere egnetheten før bestilling.
Spenningsnivå: 14
Ampere: 140
Bøssing av remskive: 29.50
Bredde/holderarm: 14.00
Festebrakett avstand: 62.00
Brakettshull: 8.50
Remjustering brakettshull pos.: 45
Remjustering brakettshull 1: 8.50
Remjustering brakettshull 2: M8
Remskivediameter: 52.00
Groover/remskive: 6
Radius: 90.00
Radius 2: 90.00
B+: M8
Posisjon/B+ i min.: 50
Rotasjon: med urviseren
Stikkontakt nr.: PL125
Total lengde mm: 202.00
Klemmer: COM
Kommunikasjon: LIN
Remskive: SP/FW
Regulator type: IR
Anmerkninger: Denne alternatoren har en COM-klemme på regulatoren. Det anbefales at OEM-nummer brukes for å kontrollere egnetheten før bestilling.
Filer
Spesifikasjon
| B+ | M8 |
|---|---|
| Communication | LIN |
| Mount. bracket dist. | 62.00 |
| Belt. adj. bracket hole 1 | 8.50 |
| Belt. adj. bracket hole 2 | M8 |
| Belt. adj. brackethole pos. | 45 |
| Plug no. | PL125 |
| Bracket hole | 8.50 |
| Position/B+ in min. | 50 |
| Pulley | SP/FW |
| Pulley dia. | 52.00 |
| Pulley dist. | 29.50 |
| Radius | 90.00 |
| Radius 2 | 90.00 |
| Regulator type | IR |
| Remarks | This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering. |
| Rotation | CW |
| Grooves/pulley | 6 |
| Terminal type | COM |
| Voltage | 14 |
| Total length | 202.00 mm |
| Width/holder arm | 14.00 |
| Amp | 140 |
-
OEM
A3340PR, CAL10552, CAL10553, DRA1346, F000 BL0 8F1, F000 BL0 8F2, F000 BL0 8P3, F000 BL0 8P4, F000BL08F1, F000BL08F2, F000BL08J3, F000BL08J4, F032113489, F032116298, 04C 903 023L, 04C 903 023T, 04C903023L, 04C903023LX, 04C903023MX, 04C903023T, 04C903023TX, 04E903015P, 04E903015PX, 04E903015Q, 04E903015T, 04E903015TX, 04E903024S, 8EL015630-021, 305.317.140, 305.541.140, 1986A01094, 1986A01370, 20352N, 20352N-OE, 116298, 209262, 209262A, 12090519, 32083340, 0986083790 -
Konkurrentreferens
A3340PR, CAL10552, CAL10553, DRA1346, 8EL015630-021, 305.317.140, 305.541.140, 20352N, 20352N-OE, 209262, 209262A, 12090519, 32083340, 0986083790 -
Bilmärken
AUDI, SEAT, SKODA, VW -
NormaliseratArtNr
a3340pr, cal10552, cal10553, dra1346, f000bl08f1, f000bl08f2, f000bl08j3, f000bl08j4, f000bl08p3, f000bl08p4, f032113489, f032116298, 04c903023l, 04c903023lx, 04c903023mx, 04c903023t, 04c903023tx, 04e903015p, 04e903015px, 04e903015q, 04e903015t, 04e903015tx, 04e903024s, 8el015630021, 1986a01094, 1986a01370, 20352n, 20352noe, 116298, 209262, 209262a, 12090519, 32083340, 305317140, 305541140, 0986083790 -
Passar modeller
AUDI A1 Allstreet (GBH) 35 TFSI Engine volume: 1.5 Engine type: DXDB, DPCA Year: 07.22- AUDI A1 City Carver (GBH) 25 TFSI Engine volume: 1.0 Engine type: DKLA Year: 07.19-06.22 AUDI A1 City Carver (GBH) 30 TFSI Engine volume: 1.0 Engine type: DKJA, DKRF Year: 07.19-06.22 AUDI A1 City Carver (GBH) 35 TFSI Engine volume: 1.5 Engine type: DPCA Year: 07.19-06.22 AUDI A1 Sportback (GBA) 25 TFSI Engine volume: 1.0 Engine type: DKLA, DUSB, DLAC Year: 11.18- AUDI A1 Sportback (GBA) 30 TFSI Engine volume: 1.0 Engine type: DKJA, DKRF, DUSA Year: 07.18- AUDI A1 Sportback (GBA) 35 TFSI Engine volume: 1.5 Engine type: DXDB, DPCA, DADA Year: 09.18- AUDI A3 (8V1, 8VK) 1.5 TFSI Engine volume: 1.5 Engine type: DADA Year: 05.17-12.17 AUDI A3 Cabriolet (8V7, 8VE) 1.5 TFSI Engine volume: 1.5 Engine type: DADA Year: 05.17-10.18 AUDI A3 Cabriolet (8V7, 8VE) 35 TFSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 10.18-10.20 AUDI A3 Limousine (8VS, 8VM) 1.5 TFSI Engine volume: 1.5 Engine type: DADA Year: 05.17-10.18 AUDI A3 Limousine (8VS, 8VM) 30 TFSI Engine volume: 1.0 Engine type: DKRF Year: 07.18-10.20 AUDI A3 Limousine (8VS, 8VM) 35 TFSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 10.18-10.20 AUDI A3 Sportback (8VA, 8VF) 1.5 TFSI Engine volume: 1.5 Engine type: DADA Year: 05.17-10.18 AUDI A3 Sportback (8VA, 8VF) 30 TFSI Engine volume: 1.0 Engine type: DKRF Year: 07.18-10.20 AUDI A3 Sportback (8VA, 8VF) 35 TFSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 10.18-10.20 AUDI Q3 (8UB, 8UG) 1.4 TSI Engine volume: 1.4 Engine type: CZEA, CZDA, CHPB Year: 10.13-10.18 AUDI Q3 (F3B) 35 TFSI Engine volume: 1.5 Engine type: DXDB, DPCA, DADA Year: 08.18- SEAT ALHAMBRA (710, 711) 1.4 TSI Engine volume: 1.4 Engine type: CZDA, DJKA Year: 05.15-12.22 SEAT ALHAMBRA VAN (711) TSi Engine volume: 1.4 Engine type: CZDA Year: 05.15-12.22 SEAT ARONA (KJ7, KJP) 1.0 TSI Engine volume: 1.0 Engine type: DUSA, DKJA, DXUA, DKRF, CHZJ Year: 07.17- SEAT ARONA (KJ7, KJP) 1.5 TSI Engine volume: 1.5 Engine type: DADA, DPCA, DXDB Year: 07.17- SEAT ATECA (KH7, KHP) 1.5 TSI 4Drive Engine volume: 1.5 Engine type: DADA, DPCA Year: 07.18- SEAT ATECA (KH7, KHP) 1.5 TSI Engine volume: 1.5 Engine type: DADA, DPCA, DXDB Year: 07.18- SEAT IBIZA IV (6J5, 6P1) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 09.15-06.17 SEAT IBIZA IV (6J5, 6P1) 1.4 TSI Engine volume: 1.4 Engine type: CZEA Year: 11.15-06.17 SEAT IBIZA IV SC (6J1, 6P5) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 09.15-12.16 SEAT IBIZA IV SC (6J1, 6P5) 1.4 TSI Engine volume: 1.4 Engine type: CZEA Year: 11.15-12.16 SEAT IBIZA IV ST (6J8, 6P8) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 09.15-07.16 SEAT IBIZA IV ST (6J8, 6P8) 1.4 TSI Engine volume: 1.4 Engine type: CZEA Year: 11.15-07.16 SEAT IBIZA V (KJ1, KJG) 1.0 TSI Engine volume: 1.0 Engine type: DUSA, DKJA, DKRF, CHZJ Year: 01.17- SEAT IBIZA V (KJ1, KJG) 1.0 TSI Engine volume: 1.0 Engine type: DUSB, CHZL, DKLA, DLAC Year: 01.17- SEAT LEON (5F1) 1.5 TGi Engine volume: 1.5 Engine type: DHFA Year: 10.18-08.20 SEAT LEON Skåpbil/halvkombi (5F1) 1.0 TSI Engine volume: 1.0 Engine type: CHZD Year: 05.15-08.20 SEAT LEON Skåpbil/halvkombi (5F1) 1.2 TSI Engine volume: 1.2 Engine type: CYVA, CJZB Year: 01.13-08.18 SEAT LEON Skåpbil/halvkombi (5F1) 1.2 TSI Engine volume: 1.2 Engine type: CYVB Year: 04.14-08.18 SEAT LEON Skåpbil/halvkombi (5F1) 1.4 TSI Engine volume: 1.4 Engine type: CHPA, CPTA Year: 09.12-10.16 SEAT LEON Skåpbil/halvkombi (5F1) 1.4 TSI Engine volume: 1.4 Engine type: CMBA, CXSA Year: 09.12-10.16 SEAT LEON Skåpbil/halvkombi (5F1) 1.4 TSI Engine volume: 1.4 Engine type: CZEA Year: 05.14-08.20 SEAT LEON ST Skåp / kombi (5F8) 1.0 TSI Engine volume: 1.0 Engine type: CHZD Year: 05.15-08.20 SEAT LEON ST Skåp / kombi (5F8) 1.2 TSI Engine volume: 1.2 Engine type: CYVA, CJZB Year: 01.13-08.18 SEAT LEON ST Skåp / kombi (5F8) 1.2 TSI Engine volume: 1.2 Engine type: CYVB Year: 05.14-08.18 SEAT LEON ST Skåp / kombi (5F8) 1.4 TSI Engine volume: 1.4 Engine type: CZDA, CZEA Year: 05.14-08.20 SEAT TARRACO (KN2) 1.5 TSI ACT Engine volume: 1.5 Engine type: DADA, DPCA, DXDB Year: 09.18-05.24 SEAT TOLEDO IV (KG3) 1.0 TSI Engine volume: 1.0 Engine type: DKRC, CHZC Year: 05.17-04.19 SEAT TOLEDO IV (KG3) 1.2 TSI Engine volume: 1.2 Engine type: CJZC Year: 05.15-05.17 SEAT TOLEDO IV (KG3) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 05.15-05.17 SEAT TOLEDO IV (KG3) 1.4 TSI Engine volume: 1.4 Engine type: CZCA Year: 05.15-04.19 SKODA FABIA III (NJ3) 1.0 TSI Engine volume: 1.0 Engine type: DKRC, CHZC Year: 08.14-06.21 SKODA FABIA III Kombi (NJ5) 1.0 TSI Engine volume: 1.0 Engine type: DKRC, CHZC Year: 08.14-12.22 SKODA KAMIQ (NW4) 1.0 TGI CNG Engine volume: 1.0 Engine type: DBYA Year: 11.19- SKODA KAMIQ (NW4) 1.0 TSI Engine volume: 1.0 Engine type: DUSB, DKLA, DLAC Year: 07.19- SKODA KAMIQ (NW4) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 07.19- SKODA KAROQ (NU7, ND7) 1.0 TSI Engine volume: 1.0 Engine type: CHZJ, DKRF, DUSA Year: 07.17- SKODA KAROQ (NU7, ND7) 1.4 TSI Engine volume: 1.4 Engine type: CZEA, DJKA Year: 07.17- SKODA KAROQ (NU7, ND7) 1.5 TSI 4x4 Engine volume: 1.5 Engine type: DPCA, DADA Year: 07.17- SKODA KAROQ (NU7, ND7) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 07.17- SKODA KODIAQ I (NS6, NS7, NV7) 1.5 TSI 4x4 Engine volume: 1.5 Engine type: DPCA, DADA Year: 07.18- SKODA KODIAQ I (NS6, NS7, NV7) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 07.18- SKODA OCTAVIA III (5E3, NL3, NR3) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 02.17-10.20 SKODA OCTAVIA III Combi (5E5, 5E6) 1.4 TSI G-TEC Engine volume: 1.4 Engine type: CPWA Year: 11.12-02.17 SKODA OCTAVIA III Combi (5E5, 5E6) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 02.17-10.20 SKODA OCTAVIA III Combi (5E5, 5E6) 1.5 TSI G-TEC Engine volume: 1.5 Engine type: DHFA Year: 01.19-10.20 SKODA RAPID (NH3, NK3, NK6) 1.0 TSI Engine volume: 1.0 Engine type: CHZB, DKLD Year: 06.17-12.19 SKODA RAPID (NH3, NK3, NK6) 1.0 TSI Engine volume: 1.0 Engine type: DKRC, CHZC Year: 06.17-12.19 SKODA RAPID (NH3, NK3, NK6) 1.2 TSI Engine volume: 1.2 Engine type: CJZC Year: 05.15-12.19 SKODA RAPID (NH3, NK3, NK6) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 05.15-12.19 SKODA RAPID (NH3, NK3, NK6) 1.4 TSI Engine volume: 1.4 Engine type: CZCA Year: 05.15-03.22 SKODA RAPID Spaceback (NH1) 1.2 TSI Engine volume: 1.2 Engine type: CJZC Year: 05.15-12.19 SKODA RAPID Spaceback (NH1) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 05.15-12.19 SKODA RAPID Spaceback (NH1) 1.4 TSI Engine volume: 1.4 Engine type: CZCA Year: 05.15-12.19 SKODA SCALA (NW1) 1.0 TGI CNG Engine volume: 1.0 Engine type: DBYA Year: 11.19- SKODA SCALA (NW1) 1.0 TSI Engine volume: 1.0 Engine type: DKJA, DKRF, DUSA, DXUA Year: 02.19- SKODA SCALA (NW1) 1.0 TSI Engine volume: 1.0 Engine type: DUSB, DKLA, DLAC Year: 02.19- SKODA SCALA (NW1) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 02.19- SKODA SUPERB III (3V3) 1.4 TSI 4x4 Engine volume: 1.4 Engine type: CZEA Year: 03.15-06.24 SKODA SUPERB III Kombi (3V5) 1.4 TSI 4x4 Engine volume: 1.4 Engine type: CZEA Year: 03.15-06.24 VW ARTEON (3H7, 3H8) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 11.17- VW CADDY ALLTRACK IV Minibus, minivan (SAB) 1.0 TSI Engine volume: 1.0 Engine type: DKRD Year: 11.18-07.19 VW CADDY ALLTRACK IV Skåpbil/minivan (SAA) 1.4 TSI Engine volume: 1.4 Engine type: DJKD Year: 06.19-09.20 VW CADDY IV Minibus, minivan (SAB, SAJ) 1.0 TSI Engine volume: 1.0 Engine type: DKRD Year: 11.18-07.19 VW CADDY IV Skåpbil/minivan (SAA, SAH) 1.4 TSI Engine volume: 1.4 Engine type: DJKD Year: 06.19-09.20 VW GOLF SPORTSVAN VII (AM1, AN1) 1.0 TSI Engine volume: 1.0 Engine type: CHZC Year: 05.17-07.18 VW GOLF SPORTSVAN VII (AM1, AN1) 1.0 TSI Engine volume: 1.0 Engine type: DKLB, CHZK Year: 05.17-07.19 VW GOLF SPORTSVAN VII (AM1, AN1) 1.5 TSI Engine volume: 1.5 Engine type: DPBA, DACA Year: 05.17-08.20 VW GOLF SPORTSVAN VII (AM1, AN1) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 05.17-08.20 VW GOLF VAN VII Variant (BA5) 1.2 TSi Engine volume: 1.2 Engine type: CJZA Year: 04.13-03.17 VW GOLF VAN VII Variant (BA5) 1.2 TSi Engine volume: 1.2 Engine type: CJZB, CYVA Year: 05.13-03.17 VW GOLF VAN VII Variant (BA5) 1.4 TSi Engine volume: 1.4 Engine type: CHPA Year: 05.13-03.17 VW GOLF VAN VII Variant (BA5) 1.4 TSi Engine volume: 1.4 Engine type: CXSA Year: 05.13-03.17 VW GOLF VII (5G1, BQ1, BE1, BE2) 1.0 TSI Engine volume: 1.0 Engine type: CHZC Year: 11.16-08.20 VW GOLF VII (5G1, BQ1, BE1, BE2) 1.0 TSI Engine volume: 1.0 Engine type: DKLB, CHZK Year: 01.17-07.19 VW GOLF VII (5G1, BQ1, BE1, BE2) 1.0 TSI Engine volume: 1.0 Engine type: DKRF, CHZD Year: 05.15-08.20 VW GOLF VII (5G1, BQ1, BE1, BE2) 1.5 TGI Engine volume: 1.5 Engine type: DHFA Year: 11.18-08.20 VW GOLF VII (5G1, BQ1, BE1, BE2) 1.5 TSI Engine volume: 1.5 Engine type: DPBA, DACA Year: 05.17-08.20 VW GOLF VII (5G1, BQ1, BE1, BE2) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 04.17-08.20 VW GOLF VII Van (5G1, BQ1) 1.2 TSi Engine volume: 1.2 Engine type: CJZA Year: 11.12-03.17 VW GOLF VII Van (5G1, BQ1) 1.2 TSi Engine volume: 1.2 Engine type: CJZB Year: 08.12-03.17 VW GOLF VII Van (5G1, BQ1) 1.4 TSi Engine volume: 1.4 Engine type: CHPA Year: 08.12-03.17 VW GOLF VII Van (5G1, BQ1) 1.4 TSi Engine volume: 1.4 Engine type: CXSA Year: 05.13-03.17 VW GOLF VII Variant (BA5, BV5) 1.0 TSI Engine volume: 1.0 Engine type: CHZC Year: 11.16-08.20 VW GOLF VII Variant (BA5, BV5) 1.0 TSI Engine volume: 1.0 Engine type: DKLB, CHZK Year: 01.17-07.19 VW GOLF VII Variant (BA5, BV5) 1.5 TGI Engine volume: 1.5 Engine type: DHFA Year: 12.18-08.20 VW GOLF VII Variant (BA5, BV5) 1.5 TSI Engine volume: 1.5 Engine type: DPBA, DACA Year: 07.17-08.20 VW GOLF VII Variant (BA5, BV5) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 04.17-08.20 VW JETTA IV (162, 163, AV3, AV2) 1.2 TSI 16V Engine volume: 1.2 Engine type: CYVD Year: 08.14-12.17 VW JETTA VII Sedan (BU3, BU4, BU5) 1.4 TSI Engine volume: 1.4 Engine type: CZDA, DSJA, CWLA, DJXA, DGXA Year: 12.17- VW PASSAT ALLTRACK B8 Variant (3G5, CB5) 1.4 TSI 4motion Engine volume: 1.4 Engine type: CZEA Year: 05.15-11.18 VW PASSAT B8 (3G2, CB2) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 08.18-03.24 VW PASSAT B8 Variant (3G5, CB5) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 08.18-03.24 VW POLO V Skåp/halvkombi (6R1, 6C1) 1.0 TSI Engine volume: 1.0 Engine type: CHZC Year: 11.14-10.17 VW POLO V Skåpbil/halvkombi (6R1, 6C1) 1.0 TSI Engine volume: 1.0 Engine type: CHZB Year: 11.14-10.17 VW POLO V Skåpbil/halvkombi (6R1, 6C1) 1.2 TSI Engine volume: 1.2 Engine type: CJZC Year: 02.14-10.17 VW POLO V Skåpbil/halvkombi (6R1, 6C1) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 01.14-10.17 VW POLO V Skåpbil/halvkombi (6R1, 6C1) 1.4 TSI Engine volume: 1.4 Engine type: CZEA Year: 05.14-10.17 VW POLO VI (AW1, BZ1, AE1) 1.0 TGI Engine volume: 1.0 Engine type: DBYA Year: 09.17- VW POLO VI (AW1, BZ1, AE1) 1.0 TSI Engine volume: 1.0 Engine type: CHZJ, DKJA, DKRF, DUSA, DXUA Year: 09.17- VW POLO VI (AW1, BZ1, AE1) 1.0 TSI Engine volume: 1.0 Engine type: DKLA, DUSB, CHZL, DXTA, DLAC Year: 06.17- VW POLO VI (AW1, BZ1, AE1) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 10.18-08.21 VW SCIROCCO III (137, 138) 1.4 TSI Engine volume: 1.4 Engine type: CZCA, CXSB Year: 11.13-11.17 VW T-CROSS (C11, D31) 1.0 TSi Engine volume: 1.0 Engine type: DKJA, DKRF, DUSA, DXUA Year: 12.18- VW T-CROSS (C11, D31) 1.0 TSi Engine volume: 1.0 Engine type: DKLA, DUSB, CHZL, DXTA, DLAC Year: 12.18- VW T-CROSS (C11, D31) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 01.20- VW T-ROC (A11, D11) 1.0 TSI Engine volume: 1.0 Engine type: CHZJ, DKRF, DUSA Year: 07.17- VW T-ROC (A11, D11) 1.5 TSI 4motion Engine volume: 1.5 Engine type: DPCA, DADA Year: 05.18-11.19 VW T-ROC (A11, D11) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 11.17- VW TAIGO (CS1) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DXDB Year: 09.21- VW TIGUAN (AD1, AX1) 1.5 TSI Engine volume: 1.5 Engine type: DPBE, DACB Year: 07.18-04.24 VW TIGUAN (AD1, AX1) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 11.18-04.24 VW TIGUAN ALLSPACE (BW2, BJ2) 1.4 TSI Engine volume: 1.4 Engine type: CZDA, CZEA Year: 06.17- VW TOURAN (5T1) 1.0 TSI Engine volume: 1.0 Engine type: DKRB Year: 12.18-07.19 VW TOURAN (5T1) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 11.18- 1 / 27
-
Beskrivelse
HC-Cargo Dynamo 14V - 140A, 6gr 52mm
Spenningsnivå: 14
Ampere: 140
Bøssing av remskive: 29.50
Bredde/holderarm: 14.00
Festebrakett avstand: 62.00
Brakettshull: 8.50
Remjustering brakettshull pos.: 45
Remjustering brakettshull 1: 8.50
Remjustering brakettshull 2: M8
Remskivediameter: 52.00
Groover/remskive: 6
Radius: 90.00
Radius 2: 90.00
B+: M8
Posisjon/B+ i min.: 50
Rotasjon: med urviseren
Stikkontakt nr.: PL125
Total lengde mm: 202.00
Klemmer: COM
Kommunikasjon: LIN
Remskive: SP/FW
Regulator type: IR
Anmerkninger: Denne alternatoren har en COM-klemme på regulatoren. Det anbefales at OEM-nummer brukes for å kontrollere egnetheten før bestilling.Filer
-
Spesifikasjon
B+ M8 Communication LIN Mount. bracket dist. 62.00 Belt. adj. bracket hole 1 8.50 Belt. adj. bracket hole 2 M8 Belt. adj. brackethole pos. 45 Plug no. PL125 Bracket hole 8.50 Position/B+ in min. 50 Pulley SP/FW Pulley dia. 52.00 Pulley dist. 29.50 Radius 90.00 Radius 2 90.00 Regulator type IR Remarks This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering. Rotation CW Grooves/pulley 6 Terminal type COM Voltage 14 Total length 202.00 mm Width/holder arm 14.00 Amp 140 -
Kjøretøymatching
-
OEM
A3340PR, CAL10552, CAL10553, DRA1346, F000 BL0 8F1, F000 BL0 8F2, F000 BL0 8P3, F000 BL0 8P4, F000BL08F1, F000BL08F2, F000BL08J3, F000BL08J4, F032113489, F032116298, 04C 903 023L, 04C 903 023T, 04C903023L, 04C903023LX, 04C903023MX, 04C903023T, 04C903023TX, 04E903015P, 04E903015PX, 04E903015Q, 04E903015T, 04E903015TX, 04E903024S, 8EL015630-021, 305.317.140, 305.541.140, 1986A01094, 1986A01370, 20352N, 20352N-OE, 116298, 209262, 209262A, 12090519, 32083340, 0986083790 -
Konkurrentreferens
A3340PR, CAL10552, CAL10553, DRA1346, 8EL015630-021, 305.317.140, 305.541.140, 20352N, 20352N-OE, 209262, 209262A, 12090519, 32083340, 0986083790 -
Bilmärken
AUDI, SEAT, SKODA, VW -
NormaliseratArtNr
a3340pr, cal10552, cal10553, dra1346, f000bl08f1, f000bl08f2, f000bl08j3, f000bl08j4, f000bl08p3, f000bl08p4, f032113489, f032116298, 04c903023l, 04c903023lx, 04c903023mx, 04c903023t, 04c903023tx, 04e903015p, 04e903015px, 04e903015q, 04e903015t, 04e903015tx, 04e903024s, 8el015630021, 1986a01094, 1986a01370, 20352n, 20352noe, 116298, 209262, 209262a, 12090519, 32083340, 305317140, 305541140, 0986083790 -
Passar modeller
AUDI A1 Allstreet (GBH) 35 TFSI Engine volume: 1.5 Engine type: DXDB, DPCA Year: 07.22- AUDI A1 City Carver (GBH) 25 TFSI Engine volume: 1.0 Engine type: DKLA Year: 07.19-06.22 AUDI A1 City Carver (GBH) 30 TFSI Engine volume: 1.0 Engine type: DKJA, DKRF Year: 07.19-06.22 AUDI A1 City Carver (GBH) 35 TFSI Engine volume: 1.5 Engine type: DPCA Year: 07.19-06.22 AUDI A1 Sportback (GBA) 25 TFSI Engine volume: 1.0 Engine type: DKLA, DUSB, DLAC Year: 11.18- AUDI A1 Sportback (GBA) 30 TFSI Engine volume: 1.0 Engine type: DKJA, DKRF, DUSA Year: 07.18- AUDI A1 Sportback (GBA) 35 TFSI Engine volume: 1.5 Engine type: DXDB, DPCA, DADA Year: 09.18- AUDI A3 (8V1, 8VK) 1.5 TFSI Engine volume: 1.5 Engine type: DADA Year: 05.17-12.17 AUDI A3 Cabriolet (8V7, 8VE) 1.5 TFSI Engine volume: 1.5 Engine type: DADA Year: 05.17-10.18 AUDI A3 Cabriolet (8V7, 8VE) 35 TFSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 10.18-10.20 AUDI A3 Limousine (8VS, 8VM) 1.5 TFSI Engine volume: 1.5 Engine type: DADA Year: 05.17-10.18 AUDI A3 Limousine (8VS, 8VM) 30 TFSI Engine volume: 1.0 Engine type: DKRF Year: 07.18-10.20 AUDI A3 Limousine (8VS, 8VM) 35 TFSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 10.18-10.20 AUDI A3 Sportback (8VA, 8VF) 1.5 TFSI Engine volume: 1.5 Engine type: DADA Year: 05.17-10.18 AUDI A3 Sportback (8VA, 8VF) 30 TFSI Engine volume: 1.0 Engine type: DKRF Year: 07.18-10.20 AUDI A3 Sportback (8VA, 8VF) 35 TFSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 10.18-10.20 AUDI Q3 (8UB, 8UG) 1.4 TSI Engine volume: 1.4 Engine type: CZEA, CZDA, CHPB Year: 10.13-10.18 AUDI Q3 (F3B) 35 TFSI Engine volume: 1.5 Engine type: DXDB, DPCA, DADA Year: 08.18- SEAT ALHAMBRA (710, 711) 1.4 TSI Engine volume: 1.4 Engine type: CZDA, DJKA Year: 05.15-12.22 SEAT ALHAMBRA VAN (711) TSi Engine volume: 1.4 Engine type: CZDA Year: 05.15-12.22 SEAT ARONA (KJ7, KJP) 1.0 TSI Engine volume: 1.0 Engine type: DUSA, DKJA, DXUA, DKRF, CHZJ Year: 07.17- SEAT ARONA (KJ7, KJP) 1.5 TSI Engine volume: 1.5 Engine type: DADA, DPCA, DXDB Year: 07.17- SEAT ATECA (KH7, KHP) 1.5 TSI 4Drive Engine volume: 1.5 Engine type: DADA, DPCA Year: 07.18- SEAT ATECA (KH7, KHP) 1.5 TSI Engine volume: 1.5 Engine type: DADA, DPCA, DXDB Year: 07.18- SEAT IBIZA IV (6J5, 6P1) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 09.15-06.17 SEAT IBIZA IV (6J5, 6P1) 1.4 TSI Engine volume: 1.4 Engine type: CZEA Year: 11.15-06.17 SEAT IBIZA IV SC (6J1, 6P5) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 09.15-12.16 SEAT IBIZA IV SC (6J1, 6P5) 1.4 TSI Engine volume: 1.4 Engine type: CZEA Year: 11.15-12.16 SEAT IBIZA IV ST (6J8, 6P8) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 09.15-07.16 SEAT IBIZA IV ST (6J8, 6P8) 1.4 TSI Engine volume: 1.4 Engine type: CZEA Year: 11.15-07.16 SEAT IBIZA V (KJ1, KJG) 1.0 TSI Engine volume: 1.0 Engine type: DUSA, DKJA, DKRF, CHZJ Year: 01.17- SEAT IBIZA V (KJ1, KJG) 1.0 TSI Engine volume: 1.0 Engine type: DUSB, CHZL, DKLA, DLAC Year: 01.17- SEAT LEON (5F1) 1.5 TGi Engine volume: 1.5 Engine type: DHFA Year: 10.18-08.20 SEAT LEON Skåpbil/halvkombi (5F1) 1.0 TSI Engine volume: 1.0 Engine type: CHZD Year: 05.15-08.20 SEAT LEON Skåpbil/halvkombi (5F1) 1.2 TSI Engine volume: 1.2 Engine type: CYVA, CJZB Year: 01.13-08.18 SEAT LEON Skåpbil/halvkombi (5F1) 1.2 TSI Engine volume: 1.2 Engine type: CYVB Year: 04.14-08.18 SEAT LEON Skåpbil/halvkombi (5F1) 1.4 TSI Engine volume: 1.4 Engine type: CHPA, CPTA Year: 09.12-10.16 SEAT LEON Skåpbil/halvkombi (5F1) 1.4 TSI Engine volume: 1.4 Engine type: CMBA, CXSA Year: 09.12-10.16 SEAT LEON Skåpbil/halvkombi (5F1) 1.4 TSI Engine volume: 1.4 Engine type: CZEA Year: 05.14-08.20 SEAT LEON ST Skåp / kombi (5F8) 1.0 TSI Engine volume: 1.0 Engine type: CHZD Year: 05.15-08.20 SEAT LEON ST Skåp / kombi (5F8) 1.2 TSI Engine volume: 1.2 Engine type: CYVA, CJZB Year: 01.13-08.18 SEAT LEON ST Skåp / kombi (5F8) 1.2 TSI Engine volume: 1.2 Engine type: CYVB Year: 05.14-08.18 SEAT LEON ST Skåp / kombi (5F8) 1.4 TSI Engine volume: 1.4 Engine type: CZDA, CZEA Year: 05.14-08.20 SEAT TARRACO (KN2) 1.5 TSI ACT Engine volume: 1.5 Engine type: DADA, DPCA, DXDB Year: 09.18-05.24 SEAT TOLEDO IV (KG3) 1.0 TSI Engine volume: 1.0 Engine type: DKRC, CHZC Year: 05.17-04.19 SEAT TOLEDO IV (KG3) 1.2 TSI Engine volume: 1.2 Engine type: CJZC Year: 05.15-05.17 SEAT TOLEDO IV (KG3) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 05.15-05.17 SEAT TOLEDO IV (KG3) 1.4 TSI Engine volume: 1.4 Engine type: CZCA Year: 05.15-04.19 SKODA FABIA III (NJ3) 1.0 TSI Engine volume: 1.0 Engine type: DKRC, CHZC Year: 08.14-06.21 SKODA FABIA III Kombi (NJ5) 1.0 TSI Engine volume: 1.0 Engine type: DKRC, CHZC Year: 08.14-12.22 SKODA KAMIQ (NW4) 1.0 TGI CNG Engine volume: 1.0 Engine type: DBYA Year: 11.19- SKODA KAMIQ (NW4) 1.0 TSI Engine volume: 1.0 Engine type: DUSB, DKLA, DLAC Year: 07.19- SKODA KAMIQ (NW4) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 07.19- SKODA KAROQ (NU7, ND7) 1.0 TSI Engine volume: 1.0 Engine type: CHZJ, DKRF, DUSA Year: 07.17- SKODA KAROQ (NU7, ND7) 1.4 TSI Engine volume: 1.4 Engine type: CZEA, DJKA Year: 07.17- SKODA KAROQ (NU7, ND7) 1.5 TSI 4x4 Engine volume: 1.5 Engine type: DPCA, DADA Year: 07.17- SKODA KAROQ (NU7, ND7) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 07.17- SKODA KODIAQ I (NS6, NS7, NV7) 1.5 TSI 4x4 Engine volume: 1.5 Engine type: DPCA, DADA Year: 07.18- SKODA KODIAQ I (NS6, NS7, NV7) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 07.18- SKODA OCTAVIA III (5E3, NL3, NR3) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 02.17-10.20 SKODA OCTAVIA III Combi (5E5, 5E6) 1.4 TSI G-TEC Engine volume: 1.4 Engine type: CPWA Year: 11.12-02.17 SKODA OCTAVIA III Combi (5E5, 5E6) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 02.17-10.20 SKODA OCTAVIA III Combi (5E5, 5E6) 1.5 TSI G-TEC Engine volume: 1.5 Engine type: DHFA Year: 01.19-10.20 SKODA RAPID (NH3, NK3, NK6) 1.0 TSI Engine volume: 1.0 Engine type: CHZB, DKLD Year: 06.17-12.19 SKODA RAPID (NH3, NK3, NK6) 1.0 TSI Engine volume: 1.0 Engine type: DKRC, CHZC Year: 06.17-12.19 SKODA RAPID (NH3, NK3, NK6) 1.2 TSI Engine volume: 1.2 Engine type: CJZC Year: 05.15-12.19 SKODA RAPID (NH3, NK3, NK6) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 05.15-12.19 SKODA RAPID (NH3, NK3, NK6) 1.4 TSI Engine volume: 1.4 Engine type: CZCA Year: 05.15-03.22 SKODA RAPID Spaceback (NH1) 1.2 TSI Engine volume: 1.2 Engine type: CJZC Year: 05.15-12.19 SKODA RAPID Spaceback (NH1) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 05.15-12.19 SKODA RAPID Spaceback (NH1) 1.4 TSI Engine volume: 1.4 Engine type: CZCA Year: 05.15-12.19 SKODA SCALA (NW1) 1.0 TGI CNG Engine volume: 1.0 Engine type: DBYA Year: 11.19- SKODA SCALA (NW1) 1.0 TSI Engine volume: 1.0 Engine type: DKJA, DKRF, DUSA, DXUA Year: 02.19- SKODA SCALA (NW1) 1.0 TSI Engine volume: 1.0 Engine type: DUSB, DKLA, DLAC Year: 02.19- SKODA SCALA (NW1) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 02.19- SKODA SUPERB III (3V3) 1.4 TSI 4x4 Engine volume: 1.4 Engine type: CZEA Year: 03.15-06.24 SKODA SUPERB III Kombi (3V5) 1.4 TSI 4x4 Engine volume: 1.4 Engine type: CZEA Year: 03.15-06.24 VW ARTEON (3H7, 3H8) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 11.17- VW CADDY ALLTRACK IV Minibus, minivan (SAB) 1.0 TSI Engine volume: 1.0 Engine type: DKRD Year: 11.18-07.19 VW CADDY ALLTRACK IV Skåpbil/minivan (SAA) 1.4 TSI Engine volume: 1.4 Engine type: DJKD Year: 06.19-09.20 VW CADDY IV Minibus, minivan (SAB, SAJ) 1.0 TSI Engine volume: 1.0 Engine type: DKRD Year: 11.18-07.19 VW CADDY IV Skåpbil/minivan (SAA, SAH) 1.4 TSI Engine volume: 1.4 Engine type: DJKD Year: 06.19-09.20 VW GOLF SPORTSVAN VII (AM1, AN1) 1.0 TSI Engine volume: 1.0 Engine type: CHZC Year: 05.17-07.18 VW GOLF SPORTSVAN VII (AM1, AN1) 1.0 TSI Engine volume: 1.0 Engine type: DKLB, CHZK Year: 05.17-07.19 VW GOLF SPORTSVAN VII (AM1, AN1) 1.5 TSI Engine volume: 1.5 Engine type: DPBA, DACA Year: 05.17-08.20 VW GOLF SPORTSVAN VII (AM1, AN1) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 05.17-08.20 VW GOLF VAN VII Variant (BA5) 1.2 TSi Engine volume: 1.2 Engine type: CJZA Year: 04.13-03.17 VW GOLF VAN VII Variant (BA5) 1.2 TSi Engine volume: 1.2 Engine type: CJZB, CYVA Year: 05.13-03.17 VW GOLF VAN VII Variant (BA5) 1.4 TSi Engine volume: 1.4 Engine type: CHPA Year: 05.13-03.17 VW GOLF VAN VII Variant (BA5) 1.4 TSi Engine volume: 1.4 Engine type: CXSA Year: 05.13-03.17 VW GOLF VII (5G1, BQ1, BE1, BE2) 1.0 TSI Engine volume: 1.0 Engine type: CHZC Year: 11.16-08.20 VW GOLF VII (5G1, BQ1, BE1, BE2) 1.0 TSI Engine volume: 1.0 Engine type: DKLB, CHZK Year: 01.17-07.19 VW GOLF VII (5G1, BQ1, BE1, BE2) 1.0 TSI Engine volume: 1.0 Engine type: DKRF, CHZD Year: 05.15-08.20 VW GOLF VII (5G1, BQ1, BE1, BE2) 1.5 TGI Engine volume: 1.5 Engine type: DHFA Year: 11.18-08.20 VW GOLF VII (5G1, BQ1, BE1, BE2) 1.5 TSI Engine volume: 1.5 Engine type: DPBA, DACA Year: 05.17-08.20 VW GOLF VII (5G1, BQ1, BE1, BE2) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 04.17-08.20 VW GOLF VII Van (5G1, BQ1) 1.2 TSi Engine volume: 1.2 Engine type: CJZA Year: 11.12-03.17 VW GOLF VII Van (5G1, BQ1) 1.2 TSi Engine volume: 1.2 Engine type: CJZB Year: 08.12-03.17 VW GOLF VII Van (5G1, BQ1) 1.4 TSi Engine volume: 1.4 Engine type: CHPA Year: 08.12-03.17 VW GOLF VII Van (5G1, BQ1) 1.4 TSi Engine volume: 1.4 Engine type: CXSA Year: 05.13-03.17 VW GOLF VII Variant (BA5, BV5) 1.0 TSI Engine volume: 1.0 Engine type: CHZC Year: 11.16-08.20 VW GOLF VII Variant (BA5, BV5) 1.0 TSI Engine volume: 1.0 Engine type: DKLB, CHZK Year: 01.17-07.19 VW GOLF VII Variant (BA5, BV5) 1.5 TGI Engine volume: 1.5 Engine type: DHFA Year: 12.18-08.20 VW GOLF VII Variant (BA5, BV5) 1.5 TSI Engine volume: 1.5 Engine type: DPBA, DACA Year: 07.17-08.20 VW GOLF VII Variant (BA5, BV5) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 04.17-08.20 VW JETTA IV (162, 163, AV3, AV2) 1.2 TSI 16V Engine volume: 1.2 Engine type: CYVD Year: 08.14-12.17 VW JETTA VII Sedan (BU3, BU4, BU5) 1.4 TSI Engine volume: 1.4 Engine type: CZDA, DSJA, CWLA, DJXA, DGXA Year: 12.17- VW PASSAT ALLTRACK B8 Variant (3G5, CB5) 1.4 TSI 4motion Engine volume: 1.4 Engine type: CZEA Year: 05.15-11.18 VW PASSAT B8 (3G2, CB2) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 08.18-03.24 VW PASSAT B8 Variant (3G5, CB5) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 08.18-03.24 VW POLO V Skåp/halvkombi (6R1, 6C1) 1.0 TSI Engine volume: 1.0 Engine type: CHZC Year: 11.14-10.17 VW POLO V Skåpbil/halvkombi (6R1, 6C1) 1.0 TSI Engine volume: 1.0 Engine type: CHZB Year: 11.14-10.17 VW POLO V Skåpbil/halvkombi (6R1, 6C1) 1.2 TSI Engine volume: 1.2 Engine type: CJZC Year: 02.14-10.17 VW POLO V Skåpbil/halvkombi (6R1, 6C1) 1.2 TSI Engine volume: 1.2 Engine type: CJZD Year: 01.14-10.17 VW POLO V Skåpbil/halvkombi (6R1, 6C1) 1.4 TSI Engine volume: 1.4 Engine type: CZEA Year: 05.14-10.17 VW POLO VI (AW1, BZ1, AE1) 1.0 TGI Engine volume: 1.0 Engine type: DBYA Year: 09.17- VW POLO VI (AW1, BZ1, AE1) 1.0 TSI Engine volume: 1.0 Engine type: CHZJ, DKJA, DKRF, DUSA, DXUA Year: 09.17- VW POLO VI (AW1, BZ1, AE1) 1.0 TSI Engine volume: 1.0 Engine type: DKLA, DUSB, CHZL, DXTA, DLAC Year: 06.17- VW POLO VI (AW1, BZ1, AE1) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA Year: 10.18-08.21 VW SCIROCCO III (137, 138) 1.4 TSI Engine volume: 1.4 Engine type: CZCA, CXSB Year: 11.13-11.17 VW T-CROSS (C11, D31) 1.0 TSi Engine volume: 1.0 Engine type: DKJA, DKRF, DUSA, DXUA Year: 12.18- VW T-CROSS (C11, D31) 1.0 TSi Engine volume: 1.0 Engine type: DKLA, DUSB, CHZL, DXTA, DLAC Year: 12.18- VW T-CROSS (C11, D31) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 01.20- VW T-ROC (A11, D11) 1.0 TSI Engine volume: 1.0 Engine type: CHZJ, DKRF, DUSA Year: 07.17- VW T-ROC (A11, D11) 1.5 TSI 4motion Engine volume: 1.5 Engine type: DPCA, DADA Year: 05.18-11.19 VW T-ROC (A11, D11) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 11.17- VW TAIGO (CS1) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DXDB Year: 09.21- VW TIGUAN (AD1, AX1) 1.5 TSI Engine volume: 1.5 Engine type: DPBE, DACB Year: 07.18-04.24 VW TIGUAN (AD1, AX1) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 11.18-04.24 VW TIGUAN ALLSPACE (BW2, BJ2) 1.4 TSI Engine volume: 1.4 Engine type: CZDA, CZEA Year: 06.17- VW TOURAN (5T1) 1.0 TSI Engine volume: 1.0 Engine type: DKRB Year: 12.18-07.19 VW TOURAN (5T1) 1.5 TSI Engine volume: 1.5 Engine type: DPCA, DADA, DXDB Year: 11.18- 1 / 27
-
