HC-Cargo Dynamo
HC-Cargo Dynamo
Varenr.: F032116354

HC-Cargo Dynamo

Teknisk info:

Spenningsregulator: 14, Amp: 140, Rotasjon: med urviseren, Monteringsbrakett avstand.: 62.00

Beskrivelse

Spenning: 14
Amp: 140
Lærerdistanse: 30.30
Bredde/holderarm: 14.50
Monteringsbeslag dist.: 62.00
Beslagshull: 8.50
Belt. justering beslags hull pos.: 45
Belt. justering beslags hull 1: 8.50
Lærerdia.: 56.00
Riller/lære: 6
Radius: 90.00
Radius 2: 90.00
B+: M8
Posisjon/B+ i min.: 50
Rotasjon: med klokka
Kabelnummer: PL86
Total lengde mm: 180.00
Terminaltype: COM
Kommunikasjon: LIN
Lære: SP
Regulator type: IR
Merk: Dette generatoren har en COM-terminal på regulatoren. Det anbefales å bruke OEM-nummeret for å sjekke egnetheten før bestilling.

Filer

Spesifikasjon

B+ M8
Communication LIN
Mount. bracket dist. 62.00
Belt. adj. bracket hole 1 8.50
Belt. adj. brackethole pos. 45
Plug no. PL86
Bracket hole 8.50
Position/B+ in min. 50
Pulley SP
Pulley dia. 56.00
Pulley dist. 30.30
Radius 90.00
Radius 2 90.00
Regulator type IR
Remarks This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.
Rotation CW
Grooves/pulley 6
Terminal type COM
Voltage 14
Total length 180.00 mm
Width/holder arm 14.50
Amp 140

  • OEM
    A0568S, A0823S, A3481S, CAL10381, DRA0315, F032116354, tg14c022, TG14C042, 28-5832, 211.355.1402, 1986A00897, 113098, 200299, 209208, 209208A, 210737, 210737A, 301992RI, 439643, 439776, 440209, 747074, 2543400, 2543400A, 9090605, 12090348, 32081180, 059903016E, 059903016EX, 059903016g, 059903016GX, 0124525116, 0124525531

  • Konkurrentreferens
    A0568S, A0823S, A3481S, CAL10381, DRA0315, 28-5832, 211.355.1402, 113098, 200299, 209208, 209208A, 210737, 210737A, 301992RI, 439643, 439776, 440209, 747074, 9090605, 12090348, 32081180

  • Bilmärken
    AUDI

  • NormaliseratArtNr
    a0568s, a0823s, a3481s, cal10381, dra0315, f032116354, tg14c022, tg14c042, 1986a00897, 113098, 200299, 209208, 209208a, 210737, 210737a, 285832, 301992ri, 439643, 439776, 440209, 747074, 2543400, 2543400a, 9090605, 12090348, 32081180, 059903016e, 059903016ex, 059903016g, 059903016gx, 0124525116, 0124525531, 2113551402

  • Passar modeller
    AUDI A4 Allroad B8 (8KH) 3.0 TDI quattro Engine volume: 3.0 Engine type: CCWA Year: 04.09-01.12
    AUDI A4 B8 (8K2) 2.7 TDI Engine volume: 2.7 Engine type: CAMA, CGKA Year: 11.07-03.12
    AUDI A4 B8 (8K2) 2.7 TDI Engine volume: 2.7 Engine type: CAMB, CGKB Year: 11.07-03.12
    AUDI A4 B8 (8K2) 3.0 TDI quattro Engine volume: 3.0 Engine type: CCLA, CAPA, CCWA Year: 11.07-03.12
    AUDI A4 B8 (8K2) 3.0 TDI quattro Engine volume: 3.0 Engine type: CCWB Year: 06.08-05.10
    AUDI A4 B8 Avant (8K5) 2.7 TDI Engine volume: 2.7 Engine type: CAMB, CGKB Year: 04.08-03.12
    AUDI A4 B8 Avant (8K5) 3.0 TDI quattro Engine volume: 3.0 Engine type: CCLA, CAPA, CCWA Year: 04.08-03.12
    AUDI A4 B8 Avant (8K5) 3.0 TDI quattro Engine volume: 3.0 Engine type: CCWB Year: 06.08-05.10
    AUDI A5 (8T3) 2.7 TDI Engine volume: 2.7 Engine type: CAMA, CGKA Year: 06.07-03.12
    AUDI A5 (8T3) 2.7 TDI Engine volume: 2.7 Engine type: CAMB, CGKB Year: 09.07-03.12
    AUDI A5 (8T3) 3.0 TDI quattro Engine volume: 3.0 Engine type: CAPA, CCWA Year: 06.07-03.12
    AUDI A5 (8T3) 3.0 TDI quattro Engine volume: 3.0 Engine type: CCWB Year: 03.08-05.10
    AUDI A5 Cabriolet (8F7) 2.7 TDI Engine volume: 2.7 Engine type: CGKA Year: 03.09-03.12
    AUDI A5 Cabriolet (8F7) 3.0 TDI quattro Engine volume: 3.0 Engine type: CCWA Year: 03.09-03.12
    AUDI A5 Sportback (8TA) 2.7 TDI Engine volume: 2.7 Engine type: CGKA Year: 09.09-03.12
    AUDI A5 Sportback (8TA) 3.0 TDI quattro Engine volume: 3.0 Engine type: CCWA Year: 09.09-03.12
    AUDI Q5 (8RB) 3.0 TDI quattro Engine volume: 3.0 Engine type: CCWB Year: 11.08-09.12
    AUDI Q5 (8RB) 3.0 TDI quattro Engine volume: 3.0 Engine type: CPNB, CCWA Year: 11.08-05.17
    AUDI Q5 Van (8RB) 3.0 TDI quattro Engine volume: 3.0 Engine type: CCWA Year: 11.08-04.13
