HC-Cargo Dynamo
HC-Cargo Dynamo
Varenr.: F032116192

HC-Cargo Dynamo

Teknisk info:

Spenning: 14, Amp: 90, Rotasjon: CW, Monteringsbrakett avstand: 50.50

Beskrivelse

Spenning: 14
Ampere: 90
Drevskive dist.: 33,00
Bredde/holderarm: 15,00
Monteringsholder dist.: 50,50
Hul i holderen: 10,50
Belt. justeringsbøssing pos.: 55
Belt. justeringsbøssing hull 1: M8
Drevskive diameter: 58,00
Groper/drevskive: 6
Radius: 85,00
Radius 2: 86,00
B+: M8
Posisjon/B+ i min.: 40
D+ Størrelse: Plugg
Rotasjon: CW
Pugg nr.: PL176
Total lengde mm: 175,00
Drevskive: OAD

Filer

Spesifikasjon

B+ M8
Mount. bracket dist. 50.50
Belt. adj. bracket hole 1 M8
Belt. adj. brackethole pos. 55
Plug no. PL176
Bracket hole 10.50
Position/B+ in min. 40
Pulley OAD
Pulley dia. 58.00
Pulley dist. 33.00
Radius 85.00
D+ Size Plug
Radius 2 86.00
Rotation CW
Grooves/pulley 6
Voltage 14
Total length 175.00 mm
Width/holder arm 15.00
Amp 90

  • OEM
    A0002610164, F032116192, 37300-2B520, 37300-2B700, 37300-2B710, 2610164, 2617585

  • Konkurrentreferens
    A9342S, DRA1309, 8EL011713-791, 255.526.090, 20651-OS, 209023, 209023A, 12061148, 0986083650

  • NormaliseratArtNr
    a0002610164, a9342s, dra1309, f032116192, 8el011713791, 20651os, 209023, 209023a, 373002b520, 373002b700, 373002b710, 2610164, 2617585, 12061148, 255526090, 0986083650

  • Passar modeller
    Hyundai Model: Elantra Model series: Elantra Size of motor: 1.4 Brand of engine: G4FA Type description: GD Body: Hatchback From date: 01-01-2013 Fuel: LPG Approved: Yes
    Hyundai Model: Elantra Model series: Elantra Type of engine: MPI Size of motor: 1.6 Brand of engine: G4FC Type description: GD Body: Hatchback From date: 01-06-2014 Fuel: Petrol Approved: Yes
    Hyundai Model: i20 Model series: i20 Size of motor: 1.4 Brand of engine: G4FA Body: Hatchback From date: 01-09-2008 To date: 01-12-2015 Fuel: Gasoline Approved: Yes
    Hyundai Model: i20 Model series: i20 Size of motor: 1.4 Brand of engine: G4FA Type description: PB, PBT Body: Hatchback From date: 01-12-2008 To date: 01-12-2012 Fuel: LPG Approved: Yes
    Hyundai Model: i30 Model series: i30 Size of motor: 1.4 Brand of engine: G4FA Body: Coupe From date: 01-05-2013 Fuel: Gasoline Approved: Yes
    Hyundai Model: I30 Model series: I30 Size of motor: 1.4 Brand of engine: G4FA Type description: GD Body: Estate From date: 01-06-2012 To date: 01-12-2015 Fuel: Gasoline Approved: Yes Manufacture type: CW
    Hyundai Model: i30 Model series: i30 Size of motor: 1.4 Brand of engine: G4FA Type description: GD Body: Hatchback From date: 01-12-2011 To date: 01-12-2015 Fuel: Gasoline Approved: Yes
    Hyundai Model: I30 Model series: I30 Size of motor: 1.4 Brand of engine: G4LC Type description: GD Body: Estate From date: 01-01-2015 Fuel: Gasoline Approved: Yes Manufacture type: CW
    Hyundai Model: i30 Model series: i30 Size of motor: 1.6 Brand of engine: G4FC Type description: GD Body: Hatchback From date: 01-01-2012 To date: 01-12-2016 Fuel: Gasoline Approved: Yes
    Hyundai Model: I30 Model series: I30 Size of motor: 1.6 Brand of engine: G4FG Type description: GD Body: Estate From date: 01-06-2012 Fuel: Gasoline Approved: Yes Manufacture type: CW
    Hyundai Model: I30 Model series: I30 Size of motor: 1.6 Brand of engine: G4FG Type description: GD Body: Estate From date: 01-06-2012 To date: 01-12-2015 Fuel: Gasoline Approved: Yes Manufacture type: CW
    Hyundai Model: i30 Model series: i30 Type of engine: GDI Size of motor: 1.6 Brand of engine: G4FD Body: Coupe From date: 01-05-2013 Fuel: Gasoline Approved: Yes
    Hyundai Model: I30 Model series: I30 Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Type description: GD Body: Estate From date: 01-06-2012 Fuel: Gasoline Approved: Yes Manufacture type: CW
    Hyundai Model: i30 Model series: i30 Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Type description: GD Body: Hatchback From date: 01-12-2011 To date: 01-12-2016 Fuel: Gasoline Approved: Yes
    Hyundai Model: i30 Model series: i30 Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Type description: GDE Body: Box Body / Hatchback From date: 01-05-2015 Fuel: Petrol Approved: Yes
    Hyundai Model: i30 Model series: i30 Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Type description: GDE, GD Body: Box Body / Estate From date: 01-05-2015 Fuel: Petrol Approved: Yes Manufacture type: Kombi Van
    Hyundai Model: i30 Model series: i30 Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FG Type description: GD Body: Hatchback From date: 01-12-2011 To date: 01-12-2015 Fuel: Gasoline Approved: Yes
    Hyundai Model: i30 Model series: i30 Type of engine: MPI Size of motor: 1.6 Brand of engine: G4FC Body: Coupe From date: 01-06-2014 Fuel: Petrol Approved: Yes
    Hyundai Model: ix20 Model series: ix20 Size of motor: 1.4 Brand of engine: G4FA Type description: JC Body: Hatchback From date: 01-11-2010 Fuel: Gasoline Approved: Yes
    Hyundai Model: ix20 Model series: ix20 Type of engine: CVVT Size of motor: 1.4 Brand of engine: D4FA Type description: JC Body: Hatchback From date: 01-11-2010 Fuel: Gasoline Approved: Yes
    Hyundai Model: ix20 Model series: ix20 Type of engine: CVVT Size of motor: 1.6 Brand of engine: G4FC Type description: JC Body: Hatchback From date: 01-11-2010 Fuel: Gasoline Approved: Yes
    Hyundai Model: ix20 Model series: ix20 Type of engine: LPG Size of motor: 1.4 Brand of engine: G4FA Type description: JC Body: Hatchback From date: 01-11-2010 Fuel: Petrol/Electro Approved: Yes
    Hyundai Model: ix20 Model series: ix20 Type of engine: LPG Size of motor: 1.6 Brand of engine: G4FC Type description: JC Body: Hatchback From date: 01-11-2010 Fuel: Petrol/Electro Approved: Yes
    Kia Model: Cee'D Model series: Cee'D Model type: CVVT Size of motor: 1.6 Brand of engine: G4FC Type description: JD Body: Hatchback From date: 01-11-2014 To date: 01-07-2018 Fuel: Petrol Approved: Yes
    Kia Model: Cee'd Model series: Cee'd Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA Body: Hatchback From date: 01-05-2012 Fuel: Gasoline Approved: Yes
    Kia Model: Cee'd Model series: Cee'd Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA-L Body: Hatchback From date: 01-05-2012 Fuel: Gasoline Approved: Yes
    Kia Model: Cee'd Model series: Cee'd Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Body: Hatchback From date: 01-05-2012 Fuel: Gasoline Approved: Yes
    Kia Model: Cee'd Model series: Cee`d Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Body: Estate From date: 01-09-2012 Fuel: Gasoline Approved: Yes Manufacture type: Sportswago
    Kia Model: Cee`d Model series: Cee`d Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA Body: Estate From date: 01-09-2012 Fuel: Gasoline Approved: Yes Manufacture type: Sportswago
    Kia Model: Cee`d Model series: Cee`d Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA Type description: JD Body: Estate From date: 01-04-2015 Fuel: Gasoline Approved: Yes
    Kia Model: Cee`d Model series: Cee`d Type of engine: GDI Size of motor: 1.6 Brand of engine: G4FD Type description: JD Body: Estate From date: 01-04-2015 Fuel: Gasoline Approved: Yes
    Kia Model: Pro Cee'd Model series: Pro Cee'd Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA Type description: JD Body: Hatchback From date: 01-07-2013 Fuel: Gasoline Approved: Yes
    Kia Model: Pro Cee'd Model series: Pro Cee'd Type of engine: GDI Size of motor: 1.6 Brand of engine: G4FD Type description: JD Body: Box Body / Hatchback From date: 01-04-2015 Fuel: Gasoline Approved: Yes
    Kia Model: Pro Cee'd Model series: Pro Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA Body: Hatchback From date: 01-03-2013 Fuel: Gasoline Approved: Yes
    Kia Model: Pro Cee'd Model series: Pro Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Body: Hatchback From date: 01-03-2013 Fuel: Gasoline Approved: Yes
    Kia Model: Venga Model series: Venga Type of engine: 16V Size of motor: 1.4 Brand of engine: G4FA-L Body: Hatchback From date: 01-02-2010 Fuel: Gasoline Approved: Yes
    Kia Model: Venga Model series: Venga Type of engine: 16V Size of motor: 1.6 Brand of engine: G4FC Body: Hatchback From date: 01-02-2010 Fuel: Gasoline Approved: Yes
    Kia Model: Venga Model series: Venga Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA Type description: YN Body: Box Body / Hatchback From date: 01-04-2015 Fuel: Gasoline Approved: Yes
    Kia Model: Venga Model series: Venga Type of engine: CVVT Size of motor: 1.6 Brand of engine: G4FC Type description: YN Body: Box Body / Hatchback From date: 01-02-2015 Fuel: Gasoline Approved: Yes
    Kia Model: Venga Model series: Venga Type of engine: LPG Size of motor: 1.4 Brand of engine: G4FA-L Type description: YN Body: Hatchback From date: 01-02-2010 Fuel: Gasoline Approved: Yes
    1 / 8
  • Beskrivelse
    Spenning: 14
    Ampere: 90
    Drevskive dist.: 33,00
    Bredde/holderarm: 15,00
    Monteringsholder dist.: 50,50
    Hul i holderen: 10,50
    Belt. justeringsbøssing pos.: 55
    Belt. justeringsbøssing hull 1: M8
    Drevskive diameter: 58,00
    Groper/drevskive: 6
    Radius: 85,00
    Radius 2: 86,00
    B+: M8
    Posisjon/B+ i min.: 40
    D+ Størrelse: Plugg
    Rotasjon: CW
    Pugg nr.: PL176
    Total lengde mm: 175,00
    Drevskive: OAD

    Filer

  • Spesifikasjon
    B+ M8
    Mount. bracket dist. 50.50
    Belt. adj. bracket hole 1 M8
    Belt. adj. brackethole pos. 55
    Plug no. PL176
    Bracket hole 10.50
    Position/B+ in min. 40
    Pulley OAD
    Pulley dia. 58.00
    Pulley dist. 33.00
    Radius 85.00
    D+ Size Plug
    Radius 2 86.00
    Rotation CW
    Grooves/pulley 6
    Voltage 14
    Total length 175.00 mm
    Width/holder arm 15.00
    Amp 90
  • Kjøretøymatching

    • OEM
      A0002610164, F032116192, 37300-2B520, 37300-2B700, 37300-2B710, 2610164, 2617585

    • Konkurrentreferens
      A9342S, DRA1309, 8EL011713-791, 255.526.090, 20651-OS, 209023, 209023A, 12061148, 0986083650

    • NormaliseratArtNr
      a0002610164, a9342s, dra1309, f032116192, 8el011713791, 20651os, 209023, 209023a, 373002b520, 373002b700, 373002b710, 2610164, 2617585, 12061148, 255526090, 0986083650

    • Passar modeller
      Hyundai Model: Elantra Model series: Elantra Size of motor: 1.4 Brand of engine: G4FA Type description: GD Body: Hatchback From date: 01-01-2013 Fuel: LPG Approved: Yes
      Hyundai Model: Elantra Model series: Elantra Type of engine: MPI Size of motor: 1.6 Brand of engine: G4FC Type description: GD Body: Hatchback From date: 01-06-2014 Fuel: Petrol Approved: Yes
      Hyundai Model: i20 Model series: i20 Size of motor: 1.4 Brand of engine: G4FA Body: Hatchback From date: 01-09-2008 To date: 01-12-2015 Fuel: Gasoline Approved: Yes
      Hyundai Model: i20 Model series: i20 Size of motor: 1.4 Brand of engine: G4FA Type description: PB, PBT Body: Hatchback From date: 01-12-2008 To date: 01-12-2012 Fuel: LPG Approved: Yes
      Hyundai Model: i30 Model series: i30 Size of motor: 1.4 Brand of engine: G4FA Body: Coupe From date: 01-05-2013 Fuel: Gasoline Approved: Yes
      Hyundai Model: I30 Model series: I30 Size of motor: 1.4 Brand of engine: G4FA Type description: GD Body: Estate From date: 01-06-2012 To date: 01-12-2015 Fuel: Gasoline Approved: Yes Manufacture type: CW
      Hyundai Model: i30 Model series: i30 Size of motor: 1.4 Brand of engine: G4FA Type description: GD Body: Hatchback From date: 01-12-2011 To date: 01-12-2015 Fuel: Gasoline Approved: Yes
      Hyundai Model: I30 Model series: I30 Size of motor: 1.4 Brand of engine: G4LC Type description: GD Body: Estate From date: 01-01-2015 Fuel: Gasoline Approved: Yes Manufacture type: CW
      Hyundai Model: i30 Model series: i30 Size of motor: 1.6 Brand of engine: G4FC Type description: GD Body: Hatchback From date: 01-01-2012 To date: 01-12-2016 Fuel: Gasoline Approved: Yes
      Hyundai Model: I30 Model series: I30 Size of motor: 1.6 Brand of engine: G4FG Type description: GD Body: Estate From date: 01-06-2012 Fuel: Gasoline Approved: Yes Manufacture type: CW
      Hyundai Model: I30 Model series: I30 Size of motor: 1.6 Brand of engine: G4FG Type description: GD Body: Estate From date: 01-06-2012 To date: 01-12-2015 Fuel: Gasoline Approved: Yes Manufacture type: CW
      Hyundai Model: i30 Model series: i30 Type of engine: GDI Size of motor: 1.6 Brand of engine: G4FD Body: Coupe From date: 01-05-2013 Fuel: Gasoline Approved: Yes
      Hyundai Model: I30 Model series: I30 Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Type description: GD Body: Estate From date: 01-06-2012 Fuel: Gasoline Approved: Yes Manufacture type: CW
      Hyundai Model: i30 Model series: i30 Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Type description: GD Body: Hatchback From date: 01-12-2011 To date: 01-12-2016 Fuel: Gasoline Approved: Yes
      Hyundai Model: i30 Model series: i30 Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Type description: GDE Body: Box Body / Hatchback From date: 01-05-2015 Fuel: Petrol Approved: Yes
      Hyundai Model: i30 Model series: i30 Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Type description: GDE, GD Body: Box Body / Estate From date: 01-05-2015 Fuel: Petrol Approved: Yes Manufacture type: Kombi Van
      Hyundai Model: i30 Model series: i30 Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FG Type description: GD Body: Hatchback From date: 01-12-2011 To date: 01-12-2015 Fuel: Gasoline Approved: Yes
      Hyundai Model: i30 Model series: i30 Type of engine: MPI Size of motor: 1.6 Brand of engine: G4FC Body: Coupe From date: 01-06-2014 Fuel: Petrol Approved: Yes
      Hyundai Model: ix20 Model series: ix20 Size of motor: 1.4 Brand of engine: G4FA Type description: JC Body: Hatchback From date: 01-11-2010 Fuel: Gasoline Approved: Yes
      Hyundai Model: ix20 Model series: ix20 Type of engine: CVVT Size of motor: 1.4 Brand of engine: D4FA Type description: JC Body: Hatchback From date: 01-11-2010 Fuel: Gasoline Approved: Yes
      Hyundai Model: ix20 Model series: ix20 Type of engine: CVVT Size of motor: 1.6 Brand of engine: G4FC Type description: JC Body: Hatchback From date: 01-11-2010 Fuel: Gasoline Approved: Yes
      Hyundai Model: ix20 Model series: ix20 Type of engine: LPG Size of motor: 1.4 Brand of engine: G4FA Type description: JC Body: Hatchback From date: 01-11-2010 Fuel: Petrol/Electro Approved: Yes
      Hyundai Model: ix20 Model series: ix20 Type of engine: LPG Size of motor: 1.6 Brand of engine: G4FC Type description: JC Body: Hatchback From date: 01-11-2010 Fuel: Petrol/Electro Approved: Yes
      Kia Model: Cee'D Model series: Cee'D Model type: CVVT Size of motor: 1.6 Brand of engine: G4FC Type description: JD Body: Hatchback From date: 01-11-2014 To date: 01-07-2018 Fuel: Petrol Approved: Yes
      Kia Model: Cee'd Model series: Cee'd Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA Body: Hatchback From date: 01-05-2012 Fuel: Gasoline Approved: Yes
      Kia Model: Cee'd Model series: Cee'd Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA-L Body: Hatchback From date: 01-05-2012 Fuel: Gasoline Approved: Yes
      Kia Model: Cee'd Model series: Cee'd Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Body: Hatchback From date: 01-05-2012 Fuel: Gasoline Approved: Yes
      Kia Model: Cee'd Model series: Cee`d Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Body: Estate From date: 01-09-2012 Fuel: Gasoline Approved: Yes Manufacture type: Sportswago
      Kia Model: Cee`d Model series: Cee`d Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA Body: Estate From date: 01-09-2012 Fuel: Gasoline Approved: Yes Manufacture type: Sportswago
      Kia Model: Cee`d Model series: Cee`d Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA Type description: JD Body: Estate From date: 01-04-2015 Fuel: Gasoline Approved: Yes
      Kia Model: Cee`d Model series: Cee`d Type of engine: GDI Size of motor: 1.6 Brand of engine: G4FD Type description: JD Body: Estate From date: 01-04-2015 Fuel: Gasoline Approved: Yes
      Kia Model: Pro Cee'd Model series: Pro Cee'd Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA Type description: JD Body: Hatchback From date: 01-07-2013 Fuel: Gasoline Approved: Yes
      Kia Model: Pro Cee'd Model series: Pro Cee'd Type of engine: GDI Size of motor: 1.6 Brand of engine: G4FD Type description: JD Body: Box Body / Hatchback From date: 01-04-2015 Fuel: Gasoline Approved: Yes
      Kia Model: Pro Cee'd Model series: Pro Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA Body: Hatchback From date: 01-03-2013 Fuel: Gasoline Approved: Yes
      Kia Model: Pro Cee'd Model series: Pro Type of engine: GDi Size of motor: 1.6 Brand of engine: G4FD Body: Hatchback From date: 01-03-2013 Fuel: Gasoline Approved: Yes
      Kia Model: Venga Model series: Venga Type of engine: 16V Size of motor: 1.4 Brand of engine: G4FA-L Body: Hatchback From date: 01-02-2010 Fuel: Gasoline Approved: Yes
      Kia Model: Venga Model series: Venga Type of engine: 16V Size of motor: 1.6 Brand of engine: G4FC Body: Hatchback From date: 01-02-2010 Fuel: Gasoline Approved: Yes
      Kia Model: Venga Model series: Venga Type of engine: CVVT Size of motor: 1.4 Brand of engine: G4FA Type description: YN Body: Box Body / Hatchback From date: 01-04-2015 Fuel: Gasoline Approved: Yes
      Kia Model: Venga Model series: Venga Type of engine: CVVT Size of motor: 1.6 Brand of engine: G4FC Type description: YN Body: Box Body / Hatchback From date: 01-02-2015 Fuel: Gasoline Approved: Yes
      Kia Model: Venga Model series: Venga Type of engine: LPG Size of motor: 1.4 Brand of engine: G4FA-L Type description: YN Body: Hatchback From date: 01-02-2010 Fuel: Gasoline Approved: Yes
      1 / 8
