HC-Cargo Dynamo
HC-Cargo Dynamo
Varenr.: F032115864

HC-Cargo Dynamo

Teknisk info:

Spenning: 14, Amp: 90, Rotasjon: CW, Drivskive diameter: 48.20

Beskrivelse

Spenningsverdi: 14
Ampere: 90
Reimskive avstand: 90.00
Bredd/holderarm: 58.00
Klemmehull: 10.50
Belt. just. brakketthull pos.: 10
Belt. just. brakketthull 1: M8
Reimskive diameter: 48.20
Groover/reimskive: 6
Radius: 80.00
Radius 2: 84.00
B+: M6
Posisjon/B+ i min.: 60
D+ Størrelse: Plugg
Rotasjon: med urviseren
Plugg nr.: PL74
Total lengde mm: 168.00
Reimskive: SP
Regulator type: IR
Prod. info: BN

Filer

Spesifikasjon

B+ M6
Belt. adj. bracket hole 1 M8
Belt. adj. brackethole pos. 10
Plug no. PL74
Bracket hole 10.50
Position/B+ in min. 60
Prod. info BN
Pulley SP
Pulley dia. 48.20
Pulley dist. 90.00
Radius 80.00
D+ Size Plug
Radius 2 84.00
Regulator type IR
Rotation CW
Grooves/pulley 6
Voltage 14
Total length 168.00 mm
Width/holder arm 58.00
Amp 90

  • OEM
    F032115864, ja1596ir, YLE102330, 102211-1470, 102211-1471

  • Konkurrentreferens
    A6639S, CAL40265, dra4034, 28-4505, 214.143.1202, 455.512.120, 23070R, 111721, 401596RI, 440849, 12090118, 32321580, 0986081290

  • NormaliseratArtNr
    a6639s, cal40265, dra4034, f032115864, ja1596ir, yle102330, 23070r, 111721, 284505, 401596ri, 440849, 12090118, 32321580, 455512120, 0986081290, 1022111470, 1022111471, 2141431202

  • Passar modeller
    MG Model: MG ZT Model series: MG ZT Model type: 180 (RJ) Size of motor: 2.5 Brand of engine: 25K4F Body: Saloon Fuel: Petrol Approved: Yes
    MG Model: ZS Model series: ZS 180 Size of motor: 2.5 Brand of engine: 25 K4F Body: Hatchback From date: 01-07-2001 To date: 01-10-2005 Fuel: Gasoline Approved: Yes
    MG Model: ZS Model series: ZS 180 Size of motor: 2.5 Brand of engine: 25 K4F From date: 01-07-2001 To date: 01-04-2005 Fuel: Gasoline Approved: Yes
    MG Model: ZT Model series: ZT 160 Size of motor: 2.5 Brand of engine: 25K4F From date: 01-06-2001 To date: 01-07-2005 Fuel: Gasoline Approved: Yes
    MG Model: ZT Model series: ZT 190 Size of motor: 2.5 Brand of engine: 25K4F From date: 01-06-2001 To date: 01-07-2005 Fuel: Gasoline Approved: Yes
    Rover Model: 45 Model series: 45 Type of engine: V6 Size of motor: 2.0 Brand of engine: 20K4F Type description: RT Body: Hatchback From date: 01-02-2000 To date: 01-05-2005 Fuel: Gasoline Approved: Yes
    Rover Model: 45 Model series: 45 Type of engine: V6 Size of motor: 2.0 Brand of engine: 20K4F Type description: RT From date: 01-02-2000 To date: 01-05-2005 Fuel: Gasoline Approved: Yes
    Rover Model: 75 Model series: 75 Type of engine: V6 Size of motor: 2.0 Brand of engine: 20K4F From date: 01-02-1999 To date: 01-05-2005 Fuel: Gasoline Approved: Yes
    Rover Model: 75 Model series: 75 Type of engine: V6 Size of motor: 2.0 Brand of engine: 20K4F Type description: RJ Body: Estate From date: 01-08-2001 To date: 01-05-2005 Fuel: Gasoline Approved: Yes Manufacture type: Tourer
    Rover Model: 75 Model series: 75 Type of engine: V6 Size of motor: 2.5 Brand of engine: 25K4F Type description: RJ From date: 01-10-2001 To date: 01-05-2005 Fuel: Gasoline Approved: Yes
    Rover Model: 75 Model series: 75 Type of engine: V6 Size of motor: 2.5 Brand of engine: KV6 From date: 01-02-1999 To date: 01-10-2001 Fuel: Gasoline Approved: Yes
    Rover Model: 75 Model series: 75 Type of engine: V6 Size of motor: 2.5 Brand of engine: KV6 Type description: RJ Body: Estate From date: 01-08-2001 To date: 01-05-2005 Fuel: Gasoline Approved: Yes Manufacture type: Tourer
    1 / 3
  • Beskrivelse
    Spenningsverdi: 14
    Ampere: 90
    Reimskive avstand: 90.00
    Bredd/holderarm: 58.00
    Klemmehull: 10.50
    Belt. just. brakketthull pos.: 10
    Belt. just. brakketthull 1: M8
    Reimskive diameter: 48.20
    Groover/reimskive: 6
    Radius: 80.00
    Radius 2: 84.00
    B+: M6
    Posisjon/B+ i min.: 60
    D+ Størrelse: Plugg
    Rotasjon: med urviseren
    Plugg nr.: PL74
    Total lengde mm: 168.00
    Reimskive: SP
    Regulator type: IR
    Prod. info: BN

    Filer

  • Spesifikasjon
    B+ M6
    Belt. adj. bracket hole 1 M8
    Belt. adj. brackethole pos. 10
    Plug no. PL74
    Bracket hole 10.50
    Position/B+ in min. 60
    Prod. info BN
    Pulley SP
    Pulley dia. 48.20
    Pulley dist. 90.00
    Radius 80.00
    D+ Size Plug
    Radius 2 84.00
    Regulator type IR
    Rotation CW
    Grooves/pulley 6
    Voltage 14
    Total length 168.00 mm
    Width/holder arm 58.00
    Amp 90
  • Kjøretøymatching

    • OEM
      F032115864, ja1596ir, YLE102330, 102211-1470, 102211-1471

    • Konkurrentreferens
      A6639S, CAL40265, dra4034, 28-4505, 214.143.1202, 455.512.120, 23070R, 111721, 401596RI, 440849, 12090118, 32321580, 0986081290

    • NormaliseratArtNr
      a6639s, cal40265, dra4034, f032115864, ja1596ir, yle102330, 23070r, 111721, 284505, 401596ri, 440849, 12090118, 32321580, 455512120, 0986081290, 1022111470, 1022111471, 2141431202

    • Passar modeller
      MG Model: MG ZT Model series: MG ZT Model type: 180 (RJ) Size of motor: 2.5 Brand of engine: 25K4F Body: Saloon Fuel: Petrol Approved: Yes
      MG Model: ZS Model series: ZS 180 Size of motor: 2.5 Brand of engine: 25 K4F Body: Hatchback From date: 01-07-2001 To date: 01-10-2005 Fuel: Gasoline Approved: Yes
      MG Model: ZS Model series: ZS 180 Size of motor: 2.5 Brand of engine: 25 K4F From date: 01-07-2001 To date: 01-04-2005 Fuel: Gasoline Approved: Yes
      MG Model: ZT Model series: ZT 160 Size of motor: 2.5 Brand of engine: 25K4F From date: 01-06-2001 To date: 01-07-2005 Fuel: Gasoline Approved: Yes
      MG Model: ZT Model series: ZT 190 Size of motor: 2.5 Brand of engine: 25K4F From date: 01-06-2001 To date: 01-07-2005 Fuel: Gasoline Approved: Yes
      Rover Model: 45 Model series: 45 Type of engine: V6 Size of motor: 2.0 Brand of engine: 20K4F Type description: RT Body: Hatchback From date: 01-02-2000 To date: 01-05-2005 Fuel: Gasoline Approved: Yes
      Rover Model: 45 Model series: 45 Type of engine: V6 Size of motor: 2.0 Brand of engine: 20K4F Type description: RT From date: 01-02-2000 To date: 01-05-2005 Fuel: Gasoline Approved: Yes
      Rover Model: 75 Model series: 75 Type of engine: V6 Size of motor: 2.0 Brand of engine: 20K4F From date: 01-02-1999 To date: 01-05-2005 Fuel: Gasoline Approved: Yes
      Rover Model: 75 Model series: 75 Type of engine: V6 Size of motor: 2.0 Brand of engine: 20K4F Type description: RJ Body: Estate From date: 01-08-2001 To date: 01-05-2005 Fuel: Gasoline Approved: Yes Manufacture type: Tourer
      Rover Model: 75 Model series: 75 Type of engine: V6 Size of motor: 2.5 Brand of engine: 25K4F Type description: RJ From date: 01-10-2001 To date: 01-05-2005 Fuel: Gasoline Approved: Yes
      Rover Model: 75 Model series: 75 Type of engine: V6 Size of motor: 2.5 Brand of engine: KV6 From date: 01-02-1999 To date: 01-10-2001 Fuel: Gasoline Approved: Yes
      Rover Model: 75 Model series: 75 Type of engine: V6 Size of motor: 2.5 Brand of engine: KV6 Type description: RJ Body: Estate From date: 01-08-2001 To date: 01-05-2005 Fuel: Gasoline Approved: Yes Manufacture type: Tourer
