HC-Cargo Dynamo
HC-Cargo Dynamo
Varenr.: F032113972

HC-Cargo Dynamo

Teknisk info:

Spenning: 14, Amp: 100, Rotasjon: CW, Monteringsbeslag avstand: 39.00

Beskrivelse

Spenningsnivå: 14
Amp: 100
Drevkugg. dist.: 31,00
Bredde/holderarm: 16,00
Monteringsbrakett dist.: 39,00
Brakettønn: 11,00
Remjustering brakettønn pos.: 59
Remjustering brakettønn 1: M8
Drev diameter: 62,00
Riller/drev: 6
Radius: 87,00
Radius 2: 87,00
B+: M6
Posisjon/B+ i min.: 50
D+ Størrelse: Koble
Rotasjon: med urviseren
Koblingsnummer: PL78
Total lengde mm: 165,00
Lampen type: Inaktiv
Drev: SP/FW
Vifte: IF
Regulator type: IR
Prod. info: BN

Filer

Spesifikasjon

B+ M6
Mount. bracket dist. 39.00
Belt. adj. bracket hole 1 M8
Belt. adj. brackethole pos. 59
Plug no. PL78
Bracket hole 11.00
Position/B+ in min. 50
Prod. info BN
Pulley SP/FW
Pulley dia. 62.00
Pulley dist. 31.00
Radius 87.00
D+ Size Plug
Radius 2 87.00
Regulator type IR
Rotation CW
Fan IF
Grooves/pulley 6
Lamp type Inactive
Voltage 14
Total length 165.00 mm
Width/holder arm 16.00
Amp 100

  • OEM
    F032113972, 1964ir, 1986A01688, 27060-0N020, 27060-0N021, 27060-0N030, 27060-0N031, 27060-33071, 27060-33072, 104210-4100, 104210-4101, 104210-4102, 104210-5150, 104210-5151, 104210-5591

  • Konkurrentreferens
    A6038, A6038(DENSO), A6038PR, CAL40206, dan1076, DRA0411, DRA0411X, J5112148, 8EL012429-531, 8EL738212-931, 28-4959, 195.582.100, 9311, 23843, 112859, 210882, 210882A, 301964RI, 440517, 440913, 443077, 9212697, 12060858, 0986082020, 09860820200, 944390904080

  • NormaliseratArtNr
    a6038, a6038denso, a6038pr, cal40206, dan1076, dra0411, dra0411x, f032113972, j5112148, 8el012429531, 8el738212931, 1964ir, 1986a01688, 9311, 23843, 112859, 210882, 210882a, 270600n020, 270600n021, 270600n030, 270600n031, 284959, 301964ri, 440517, 440913, 443077, 9212697, 12060858, 195582100, 0986082020, 1042104100, 1042104101, 1042104102, 1042105150, 1042105151, 1042105591, 2706033071, 2706033072, 09860820200, 944390904080

  • Passar modeller
    Lancia Model: Kappa Model series: Kappa Type of engine: TD Size of motor: 2.4 Brand of engine: 838A3.000 Type description: 838 Body: Estate From date: 01-07-1996 To date: 01-10-2001 Fuel: Diesel Approved: Yes
    Toyota Model: Auris Model series: Auris Type of engine: D-4D Size of motor: 1.4 Brand of engine: 1ND-TV Type description: NDE150 Body: Hatchback From date: 01-03-2007 To date: 01-09-2012 Fuel: Diesel Approved: Yes
    Toyota Model: Auris Model series: Auris Type of engine: D-4D Size of motor: 1.4 Brand of engine: 1ND-TV Type description: _E15_ Body: Box From date: 01-03-2007 To date: 01-09-2012 Fuel: Diesel Approved: Yes
    Toyota Model: Corolla Model series: Corolla Type of engine: Diesel Size of motor: 1.4 Brand of engine: 1ND-TV Type description: E12_, 12J_ Body: Estate From date: 01-06-2004 To date: 01-10-2007 Fuel: Diesel Approved: Yes
    Toyota Model: Corolla Model series: Corolla Type of engine: Diesel Size of motor: 1.4 Brand of engine: 1ND-TV Type description: _E12U_, _E12J_ Body: Hatchback From date: 01-07-2004 To date: 01-02-2007 Fuel: Diesel Approved: Yes
    Toyota Model: Corolla Model series: Corolla Type of engine: Diesel Size of motor: 1.4 Brand of engine: 1ND-TV Type description: _E12_ From date: 01-06-2004 To date: 01-10-2006 Fuel: Diesel Approved: Yes
    1 / 2
  • Beskrivelse
    Spenningsnivå: 14
    Amp: 100
    Drevkugg. dist.: 31,00
    Bredde/holderarm: 16,00
    Monteringsbrakett dist.: 39,00
    Brakettønn: 11,00
    Remjustering brakettønn pos.: 59
    Remjustering brakettønn 1: M8
    Drev diameter: 62,00
    Riller/drev: 6
    Radius: 87,00
    Radius 2: 87,00
    B+: M6
    Posisjon/B+ i min.: 50
    D+ Størrelse: Koble
    Rotasjon: med urviseren
    Koblingsnummer: PL78
    Total lengde mm: 165,00
    Lampen type: Inaktiv
    Drev: SP/FW
    Vifte: IF
    Regulator type: IR
    Prod. info: BN

    Filer

  • Spesifikasjon
    B+ M6
    Mount. bracket dist. 39.00
    Belt. adj. bracket hole 1 M8
    Belt. adj. brackethole pos. 59
    Plug no. PL78
    Bracket hole 11.00
    Position/B+ in min. 50
    Prod. info BN
    Pulley SP/FW
    Pulley dia. 62.00
    Pulley dist. 31.00
    Radius 87.00
    D+ Size Plug
    Radius 2 87.00
    Regulator type IR
    Rotation CW
    Fan IF
    Grooves/pulley 6
    Lamp type Inactive
    Voltage 14
    Total length 165.00 mm
    Width/holder arm 16.00
    Amp 100
  • Kjøretøymatching

    • OEM
      F032113972, 1964ir, 1986A01688, 27060-0N020, 27060-0N021, 27060-0N030, 27060-0N031, 27060-33071, 27060-33072, 104210-4100, 104210-4101, 104210-4102, 104210-5150, 104210-5151, 104210-5591

    • Konkurrentreferens
      A6038, A6038(DENSO), A6038PR, CAL40206, dan1076, DRA0411, DRA0411X, J5112148, 8EL012429-531, 8EL738212-931, 28-4959, 195.582.100, 9311, 23843, 112859, 210882, 210882A, 301964RI, 440517, 440913, 443077, 9212697, 12060858, 0986082020, 09860820200, 944390904080

    • NormaliseratArtNr
      a6038, a6038denso, a6038pr, cal40206, dan1076, dra0411, dra0411x, f032113972, j5112148, 8el012429531, 8el738212931, 1964ir, 1986a01688, 9311, 23843, 112859, 210882, 210882a, 270600n020, 270600n021, 270600n030, 270600n031, 284959, 301964ri, 440517, 440913, 443077, 9212697, 12060858, 195582100, 0986082020, 1042104100, 1042104101, 1042104102, 1042105150, 1042105151, 1042105591, 2706033071, 2706033072, 09860820200, 944390904080

    • Passar modeller
      Lancia Model: Kappa Model series: Kappa Type of engine: TD Size of motor: 2.4 Brand of engine: 838A3.000 Type description: 838 Body: Estate From date: 01-07-1996 To date: 01-10-2001 Fuel: Diesel Approved: Yes
      Toyota Model: Auris Model series: Auris Type of engine: D-4D Size of motor: 1.4 Brand of engine: 1ND-TV Type description: NDE150 Body: Hatchback From date: 01-03-2007 To date: 01-09-2012 Fuel: Diesel Approved: Yes
      Toyota Model: Auris Model series: Auris Type of engine: D-4D Size of motor: 1.4 Brand of engine: 1ND-TV Type description: _E15_ Body: Box From date: 01-03-2007 To date: 01-09-2012 Fuel: Diesel Approved: Yes
      Toyota Model: Corolla Model series: Corolla Type of engine: Diesel Size of motor: 1.4 Brand of engine: 1ND-TV Type description: E12_, 12J_ Body: Estate From date: 01-06-2004 To date: 01-10-2007 Fuel: Diesel Approved: Yes
      Toyota Model: Corolla Model series: Corolla Type of engine: Diesel Size of motor: 1.4 Brand of engine: 1ND-TV Type description: _E12U_, _E12J_ Body: Hatchback From date: 01-07-2004 To date: 01-02-2007 Fuel: Diesel Approved: Yes
      Toyota Model: Corolla Model series: Corolla Type of engine: Diesel Size of motor: 1.4 Brand of engine: 1ND-TV Type description: _E12_ From date: 01-06-2004 To date: 01-10-2006 Fuel: Diesel Approved: Yes
      1 / 2
