HC-Cargo Dynamo
HC-Cargo Dynamo
Varenr.: F032114490

HC-Cargo Dynamo

Teknisk info:

Spenningsregulator: 14, Amp: 100, Rotasjon: CW, Monteringsfeste avstand: 71.50

Beskrivelse

Gen. 12V-100A passer til Toyota 12V - 100A, 7gr, (L, IG, S, DFM) For Yourex produkt bestilt 90-555-5140

Spenning: 14
Ampere: 100
Remskive avstand: 24.00
Bredde/holderarm: 60.00
Monteringsbrakett avstand: 71.50
Brakettfremslag: 8.80
Brakettfeste 2: 10.20
Belt. justeringsbrakettposisjon: 58
Belt. justeringsbrakettfeste 1: 8.50
Remskivens diameter: 58.00
Grooves/remskive: 7
B+: M6
Posisjon/B+ i min.: 8
Rotasjon: CW
Plugg nr.: PL78
Total lengde mm: 152.00
Remskive: SP/FW
Spenningsregulator type: IR

Filer

Spesifikasjon

B+ M6
Mount. bracket dist. 71.50
Belt. adj. bracket hole 1 8.50
Belt. adj. brackethole pos. 58
Plug no. PL78
Bracket hole 8.80
Bracket hole 2 10.20
Position/B+ in min. 8
Pulley SP/FW
Pulley dia. 58.00
Pulley dist. 24.00
Regulator type IR
Rotation CW
Grooves/pulley 7
Voltage 14
Total length 152.00 mm
Width/holder arm 60.00
Amp 100

  • OEM
    F032114490, 1986A00940, 1986A01203, 2036ir, 021080-2010, 27060-0R011, 27060-0R040, 27060-0r040, 27060-0R050, 27060-26051, 104210-2220, 104210-4850, 104210-5140, 104210-5600, 104211-3600, 114490

  • Konkurrentreferens
    A6089, A6089(DENSO), A6096, CAL40291, CAL40303, DAN1022, DAN1045, DAN1351, DRA0598, DRA1287, 8EL015630-691, 28-5784, 195.927.100, 195.970.100, 235.325.1002, 9473, 24110R, 209361, 209361A, 209370, 209370A, 302036RI, 440985, 553488RI, 12060926, 0986082080

  • Bilmärken
    Toyota

  • NormaliseratArtNr
    a6089, a6089denso, a6096, cal40291, cal40303, dan1022, dan1045, dan1351, dra0598, dra1287, f032114490, 8el015630691, 1986a00940, 1986a01203, 2036ir, 9473, 24110r, 114490, 209361, 209361a, 209370, 209370a, 270600r011, 270600r040, 270600r050, 285784, 302036ri, 440985, 553488ri, 12060926, 195927100, 195970100, 0210802010, 0986082080, 1042102220, 1042104850, 1042105140, 1042105600, 1042113600, 2353251002, 2706026051

  • Passar modeller
    Toyota Model: Auris Model series: Auris Type of engine: D-4D Size of motor: 2.0 Brand of engine: 1AD-FTV Type description: ADE150 Body: Hatchback From date: 01-10-2006 To date: 01-09-2012 Fuel: Diesel Approved: Yes
    Toyota Model: Auris Model series: Auris Type of engine: Diesel Size of motor: 2.2 Brand of engine: 2AD-FHV Type description: ADE157 Body: Hatchback From date: 01-11-2006 To date: 01-09-2012 Fuel: Diesel Approved: Yes
    Toyota Model: Corolla Model series: Corolla Type of engine: D-4D Size of motor: 2.0 Brand of engine: 1AD-FTV Type description: ADE150R From date: 01-11-2006 To date: 01-07-2014 Fuel: Diesel Approved: Yes
    Toyota Series: Auris (_E15_) Model: 2.0 D-4D Engine volume: 2.0 Engine type: 1AD-FTV Year: 03.07-09.12
    Toyota Series: Auris (_E15_) Model: 2.2 D Engine volume: 2.2 Engine type: 2AD-FHV Year: 03.07-09.12
    Toyota Series: Avensis (T27) Model: 2.0 D-4D Engine volume: 2.0 Engine type: 1AD-FTV Year: 11.08-12.11
    Toyota Series: Corolla (_E15_) Model: 2.0 D-4D Engine volume: 2.0 Engine type: 1AD-FTV Year: 02.08-05.13
    1 / 2
  • Beskrivelse
    Gen. 12V-100A passer til Toyota 12V - 100A, 7gr, (L, IG, S, DFM) For Yourex produkt bestilt 90-555-5140

    Spenning: 14
    Ampere: 100
    Remskive avstand: 24.00
    Bredde/holderarm: 60.00
    Monteringsbrakett avstand: 71.50
    Brakettfremslag: 8.80
    Brakettfeste 2: 10.20
    Belt. justeringsbrakettposisjon: 58
    Belt. justeringsbrakettfeste 1: 8.50
    Remskivens diameter: 58.00
    Grooves/remskive: 7
    B+: M6
    Posisjon/B+ i min.: 8
    Rotasjon: CW
    Plugg nr.: PL78
    Total lengde mm: 152.00
    Remskive: SP/FW
    Spenningsregulator type: IR

    Filer

  • Spesifikasjon
    B+ M6
    Mount. bracket dist. 71.50
    Belt. adj. bracket hole 1 8.50
    Belt. adj. brackethole pos. 58
    Plug no. PL78
    Bracket hole 8.80
    Bracket hole 2 10.20
    Position/B+ in min. 8
    Pulley SP/FW
    Pulley dia. 58.00
    Pulley dist. 24.00
    Regulator type IR
    Rotation CW
    Grooves/pulley 7
    Voltage 14
    Total length 152.00 mm
    Width/holder arm 60.00
    Amp 100
  • Kjøretøymatching

    • OEM
      F032114490, 1986A00940, 1986A01203, 2036ir, 021080-2010, 27060-0R011, 27060-0R040, 27060-0r040, 27060-0R050, 27060-26051, 104210-2220, 104210-4850, 104210-5140, 104210-5600, 104211-3600, 114490

    • Konkurrentreferens
      A6089, A6089(DENSO), A6096, CAL40291, CAL40303, DAN1022, DAN1045, DAN1351, DRA0598, DRA1287, 8EL015630-691, 28-5784, 195.927.100, 195.970.100, 235.325.1002, 9473, 24110R, 209361, 209361A, 209370, 209370A, 302036RI, 440985, 553488RI, 12060926, 0986082080

    • Bilmärken
      Toyota

    • NormaliseratArtNr
      a6089, a6089denso, a6096, cal40291, cal40303, dan1022, dan1045, dan1351, dra0598, dra1287, f032114490, 8el015630691, 1986a00940, 1986a01203, 2036ir, 9473, 24110r, 114490, 209361, 209361a, 209370, 209370a, 270600r011, 270600r040, 270600r050, 285784, 302036ri, 440985, 553488ri, 12060926, 195927100, 195970100, 0210802010, 0986082080, 1042102220, 1042104850, 1042105140, 1042105600, 1042113600, 2353251002, 2706026051

    • Passar modeller
      Toyota Model: Auris Model series: Auris Type of engine: D-4D Size of motor: 2.0 Brand of engine: 1AD-FTV Type description: ADE150 Body: Hatchback From date: 01-10-2006 To date: 01-09-2012 Fuel: Diesel Approved: Yes
      Toyota Model: Auris Model series: Auris Type of engine: Diesel Size of motor: 2.2 Brand of engine: 2AD-FHV Type description: ADE157 Body: Hatchback From date: 01-11-2006 To date: 01-09-2012 Fuel: Diesel Approved: Yes
      Toyota Model: Corolla Model series: Corolla Type of engine: D-4D Size of motor: 2.0 Brand of engine: 1AD-FTV Type description: ADE150R From date: 01-11-2006 To date: 01-07-2014 Fuel: Diesel Approved: Yes
      Toyota Series: Auris (_E15_) Model: 2.0 D-4D Engine volume: 2.0 Engine type: 1AD-FTV Year: 03.07-09.12
      Toyota Series: Auris (_E15_) Model: 2.2 D Engine volume: 2.2 Engine type: 2AD-FHV Year: 03.07-09.12
      Toyota Series: Avensis (T27) Model: 2.0 D-4D Engine volume: 2.0 Engine type: 1AD-FTV Year: 11.08-12.11
      Toyota Series: Corolla (_E15_) Model: 2.0 D-4D Engine volume: 2.0 Engine type: 1AD-FTV Year: 02.08-05.13
