HC-Cargo Dynamo
HC-Cargo Dynamo
Varenr.: F032114214

HC-Cargo Dynamo

Teknisk info:

Spenningsregulator: 14, Amp: 80, Rotasjon: medurs, Monteringsbeslag avstand.: 80.00

Beskrivelse

Spenningsspenning: 14
Ampere: 80
Drevskive dist.: 46.50
Bredde/holderarm: 13.00
Festebrakett dist.: 80.00
Brakett hole: 8.50
Båndinnstillingsbrakett hull: 60
Båndinnstillingsbrakett hull 1: M8
Drevenes diameter: 54.00
Groover/drevskive: 5
Radius: 87.00
Radius 2: 85.00
B+: M8
Posisjon/B+ i min.: 45
D+: Størrelse: Plugg
Rotasjon: medur
Plugg nr.: PL163
Drev: SP
Regulator type: IR

Filer

Spesifikasjon

B+ M8
Mount. bracket dist. 80.00
Belt. adj. bracket hole 1 M8
Belt. adj. brackethole pos. 60
Plug no. PL163
Bracket hole 8.50
Position/B+ in min. 45
Pulley SP
Pulley dia. 54.00
Pulley dist. 46.50
Radius 87.00
D+ Size Plug
Radius 2 85.00
Regulator type IR
Rotation CW
Grooves/pulley 5
Voltage 14
Width/holder arm 13.00
Amp 80

  • OEM
    A002TB3091, A002TB5391, A002TB6991, A002TG0391, a2tb3091, A2TB5391, A2TB6991, a2tg0391, F032114214, 2083ir, 23700-AA380, 23700-AA420, 23700-AA450, 23700-AA540

  • Konkurrentreferens
    A5074, CAL35182, DRA4278, LRA02102, 28-4542, 233.117.802, 11058, 11058N, 112678, 209355, 209355A, 553265RI, 9045741, 12060776, 0986045741

  • NormaliseratArtNr
    a002tb3091, a002tb5391, a002tb6991, a002tg0391, a2tb3091, a2tb5391, a2tb6991, a2tg0391, a5074, cal35182, dra4278, f032114214, lra02102, 2083ir, 11058, 11058n, 23700aa380, 23700aa420, 23700aa450, 23700aa540, 112678, 209355, 209355a, 284542, 553265ri, 9045741, 12060776, 233117802, 0986045741

  • Passar modeller
    Saab Model: 9-2 Model series: 9-2X Model type: Aero Type of engine: Turbo Size of motor: 2.5 Brand of engine: EJ255 From date: 01-01-2006 Fuel: Gasoline Approved: Yes
    Saab Model: 9-2 Model series: 9-2X Size of motor: 2.5 Brand of engine: EJ253 From date: 01-01-2006 Fuel: Gasoline Approved: Yes
    Subaru Model: Forester Model series: Forester Model type: 4x4 Size of motor: 2.5 Brand of engine: EJ25D Type description: SF From date: 01-07-1997 To date: 01-05-2002 Fuel: Gasoline Approved: Yes
    Subaru Model: Forester Model series: Forester Model type: 4x4 Type of engine: Turbo Size of motor: 2.5 Type description: SF From date: 01-09-1998 To date: 01-05-2002 Fuel: Gasoline Approved: Yes
    Subaru Model: Forester Model series: Forester Model type: S Type of engine: Turbo Size of motor: 2.0 Brand of engine: EJ20 Type description: SG Body: Estate From date: 01-02-2002 To date: 01-05-2005 Fuel: Gasoline Approved: Yes
    Subaru Model: Forester Model series: Forester Size of motor: 2.0 Brand of engine: EJ20 Type description: SG Body: Estate From date: 01-06-2002 To date: 01-05-2005 Fuel: Gasoline Approved: Yes
    Subaru Model: Forester Model series: Forester Size of motor: 2.0 Brand of engine: EJ20 Type description: SH From date: 01-01-2008 To date: 01-09-2013 Fuel: Gasoline Approved: Yes
    Subaru Model: Forester Model series: Forester Size of motor: 2.5 Brand of engine: EJ25 Type description: SG Body: Estate From date: 01-12-2003 To date: 01-05-2005 Fuel: Gasoline Approved: Yes
    Subaru Model: Impreza Model series: Impreza Estate Model type: WRX AWD (GGA) Size of motor: 2.0 Brand of engine: EJ205 Type description: GG Body: Estate From date: 01-09-2001 To date: 01-12-2005 Fuel: Petrol Approved: Yes Manufacture type: Estate
    Subaru Model: Impreza Model series: Impreza Model type: 4WD Size of motor: 2.0 Brand of engine: EJ205P Type description: GD,GG From date: 01-10-2005 To date: 01-03-2007 Fuel: Gasoline Approved: Yes
    Subaru Model: Impreza Model series: Impreza Model type: 4x4 Size of motor: 1.5 Brand of engine: EL15 Body: Hatchback From date: 01-02-2008 To date: 01-03-2012 Fuel: Gasoline Approved: Yes
    Subaru Model: Impreza Model series: Impreza Model type: 4x4 Size of motor: 1.5 Brand of engine: EL15 Type description: GR From date: 01-02-2008 Fuel: Gasoline Approved: Yes
    Subaru Model: Impreza Model series: Impreza Model type: BiFuel AWD Type of engine: Bifuel Size of motor: 1.5 Brand of engine: EL154 Type description: GR, GH, G3 Body: Hatchback From date: 01-01-2010 To date: 01-03-2012 Fuel: Petrol/Electro Approved: Yes
    Subaru Model: Impreza Model series: Impreza Model type: WRX 4WD Type of engine: Turbo Size of motor: 2.0 Brand of engine: EJ205 Type description: GD, GG Body: Estate From date: 01-12-2002 To date: 01-09-2006 Fuel: Gasoline Approved: Yes
    Subaru Model: Impreza Model series: Impreza Model type: WRX 4WD Type of engine: Turbo Size of motor: 2.0 Brand of engine: EJ205 Type description: GD, GG From date: 01-12-2002 To date: 01-03-2007 Fuel: Gasoline Approved: Yes
    Subaru Model: Impreza Model series: Impreza Model type: WRX STi 4WD Size of motor: 2.0 Brand of engine: EJ208 Type description: GD,GG Body: Estate From date: 01-10-2000 To date: 01-10-2002 Fuel: Gasoline Approved: Yes
    Subaru Model: Impreza Model series: Impreza Size of motor: 1.5 Brand of engine: EL15 Body: Hatchback From date: 01-02-2008 To date: 01-03-2012 Fuel: Gasoline Approved: Yes
    Subaru Model: Impreza Model series: Impreza Size of motor: 1.5 Brand of engine: EL15 Type description: GD,GG Body: Estate From date: 01-05-2006 To date: 01-03-2007 Fuel: Gasoline Approved: Yes
    Subaru Model: Impreza Model series: Impreza Size of motor: 1.5 Brand of engine: EL15 Type description: GD,GG From date: 01-05-2006 To date: 01-03-2007 Fuel: Gasoline Approved: Yes
    Subaru Model: Impreza Model series: Impreza Size of motor: 1.6 Brand of engine: EJ16 Type description: GD, GG From date: 01-06-2001 To date: 01-09-2006 Fuel: Gasoline Approved: Yes
    Subaru Model: Impreza Model series: Impreza Size of motor: 1.6 Brand of engine: EJ161 Type description: GD, GG From date: 01-06-2001 To date: 01-09-2006 Fuel: Gasoline Approved: Yes
    Subaru Model: Legacy Model series: Lagacy Size of motor: 2.0 Brand of engine: EJ20 Body: Estate From date: 01-12-1998 To date: 01-08-2003 Fuel: Gasoline Approved: Yes
    Subaru Model: Legacy Model series: Legacy Size of motor: 2.0 Brand of engine: EJ20 From date: 01-04-1999 To date: 01-08-2003 Fuel: Gasoline Approved: Yes
