HC-Cargo Dynamo
HC-Cargo Dynamo
Varenr.: F032115409

HC-Cargo Dynamo

Teknisk info:

Spenningsgiver: 14, Amp: 120, Rotasjon: CW, Drev diameter: 59.70

Beskrivelse

Hyundai Diesel Dynamo 12V-120A 12V - 120A, 6gr.frg, (S, L) Original Denso generator for Yourex produkt bestilling 90-228-2702 Uttak: 14 Ampere: 120 Bøssing av remskiva: 103.00 Bredde/holderarm: 63.00 Hjulbrønn for brakett: 10.50 Remjusteringsbrakettposisjon: 50 Remjusteringsbrakett hull 1: M10 Remskive diameter: 59.70 Dybder/grooves på remskive: 6 Radius: 83.00 Radius 2: 92.50 B+: M8 Posisjon/B+ i min.: 46 Rotasjon: med urviseren Stikkontaktnummer: PL07 Remskive: SP/FW Regulator type: IR Vakuumpumpe: Ja Produsent info: BN

Filer

Spesifikasjon

B+ M8
Belt. adj. bracket hole 1 M10
Belt. adj. brackethole pos. 50
Plug no. PL07
Bracket hole 10.50
Position/B+ in min. 46
Prod. info BN
Pulley SP/FW
Pulley dia. 59.70
Pulley dist. 103.00
Radius 83.00
Radius 2 92.50
Regulator type IR
Rotation CW
Grooves/pulley 6
Vac. pump Yes
Voltage 14
Width/holder arm 63.00
Amp 120

  • OEM
    F032115409, 2018ir, 02131-9261, 02131-9262, 37300-27020, 37300-27021, 115409

  • Konkurrentreferens
    A3173, A3173(VALEO), A6223(DENSO), CAL32139, DRA0243, DRA0243N, 8EL012426-181, 8EL738212-641, 28-5667, 9405, 24027N, 24027R, 210024, 210024A, 440982, 12060938

  • Bilmärken
    Hyundai, Kia

  • NormaliseratArtNr
    a3173, a3173valeo, a6223denso, cal32139, dra0243, dra0243n, f032115409, 8el012426181, 8el738212641, 2018ir, 9405, 24027n, 24027r, 115409, 210024, 210024a, 285667, 440982, 12060938, 021319261, 021319262, 3730027020, 3730027021

  • Passar modeller
    Hyundai Model: Grandeur Model series: Grandeur Type of engine: CRDi Size of motor: 2.2 Brand of engine: D4EB From date: 01-06-2006 To date: 01-10-2010 Fuel: Diesel Approved: Yes
    Hyundai Model: i30 Model series: i30 Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Body: Hatchback From date: 01-10-2007 To date: 01-11-2011 Fuel: Diesel Approved: Yes
    Hyundai Model: i30 Model series: i30 Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: FD Body: Estate From date: 01-10-2008 To date: 01-06-2012 Fuel: Diesel Approved: Yes Manufacture type: CW
    Hyundai Model: i30 Model series: i30 Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: FD Body: Hatchback From date: 01-10-2007 To date: 01-11-2011 Fuel: Diesel Approved: Yes
    Hyundai Model: Sonata Model series: Sonata Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA From date: 01-02-2006 To date: 01-12-2010 Fuel: Diesel Approved: Yes
    Hyundai Model: Sonata Model series: Sonata Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: NF From date: 01-03-2009 To date: 01-12-2010 Fuel: Diesel Approved: Yes
    Hyundai Series: Grandeur Model: 2.2 CRDi Engine volume: 2.2 Engine type: D4EB Year: 06.06-
    Hyundai Series: i30 Model: 2.0 CRDi Engine volume: 2.0 Engine type: D4EA Year: 10.07-
    Hyundai Series: Sonata V Model: 2.0 CRDi Engine volume: 2.0 Year: 03.09-
    Kia Model: Carens Model series: Carens Model type: 115 Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: UN Body: MPV From date: 01-05-2007 Fuel: Diesel Approved: Yes
    Kia Model: Carens Model series: Carens Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Body: MPV From date: 01-09-2006 Fuel: Diesel Approved: Yes
    Kia Model: Carens Model series: Carens Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: UN Body: MPV From date: 01-08-2009 Fuel: Diesel Approved: Yes
    Kia Model: Cee'D Model series: Cee'D Model type: 140 Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: ED Body: Estate From date: 01-07-2007 To date: 01-12-2012 Fuel: Diesel Approved: Yes Manufacture type: SW
    Kia Model: Cee'd Model series: Cee'd Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA-F Body: Estate From date: 01-07-2007 To date: 01-12-2012 Fuel: Diesel Approved: Yes
    Kia Model: Cee'd Model series: Cee'd Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA-F Body: Hatchback From date: 01-09-2007 To date: 01-12-2012 Fuel: Diesel Approved: Yes
    Kia Model: Magentis Model series: Magentis Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA From date: 01-04-2006 Fuel: Diesel Approved: Yes
    Kia Model: Magentis Model series: Magentis Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: MG From date: 01-11-2005 To date: 01-12-2008 Fuel: Diesel Approved: Yes
    Kia Series: Carens III (UN) Model: 2.0 CRDi 140 Engine volume: 2.0 Engine type: D4EA Year: 09.06-
    Kia Series: CEE´D Model: 2.0 CRDi 140 Engine volume: 2.0 Engine type: D4EA-F Year: 09.07-
    Kia Series: CEE´D SW Model: 2.0 CRDi 140 Engine volume: 2.0 Engine type: D4EA-F Year: 09.07-
    Kia Series: Magentis Model: 2.0 CRDi Engine volume: 2.0 Engine type: D4EA Year: 04.06-
    Kia Series: PRO CEE´D Model: 2.0 CRDi 140 Engine volume: 2.0 Engine type: D4EA-F Year: 02.08-
    1 / 5
  • Beskrivelse
    Hyundai Diesel Dynamo 12V-120A 12V - 120A, 6gr.frg, (S, L) Original Denso generator for Yourex produkt bestilling 90-228-2702 Uttak: 14 Ampere: 120 Bøssing av remskiva: 103.00 Bredde/holderarm: 63.00 Hjulbrønn for brakett: 10.50 Remjusteringsbrakettposisjon: 50 Remjusteringsbrakett hull 1: M10 Remskive diameter: 59.70 Dybder/grooves på remskive: 6 Radius: 83.00 Radius 2: 92.50 B+: M8 Posisjon/B+ i min.: 46 Rotasjon: med urviseren Stikkontaktnummer: PL07 Remskive: SP/FW Regulator type: IR Vakuumpumpe: Ja Produsent info: BN

    Filer

  • Spesifikasjon
    B+ M8
    Belt. adj. bracket hole 1 M10
    Belt. adj. brackethole pos. 50
    Plug no. PL07
    Bracket hole 10.50
    Position/B+ in min. 46
    Prod. info BN
    Pulley SP/FW
    Pulley dia. 59.70
    Pulley dist. 103.00
    Radius 83.00
    Radius 2 92.50
    Regulator type IR
    Rotation CW
    Grooves/pulley 6
    Vac. pump Yes
    Voltage 14
    Width/holder arm 63.00
    Amp 120
  • Kjøretøymatching

    • OEM
      F032115409, 2018ir, 02131-9261, 02131-9262, 37300-27020, 37300-27021, 115409

    • Konkurrentreferens
      A3173, A3173(VALEO), A6223(DENSO), CAL32139, DRA0243, DRA0243N, 8EL012426-181, 8EL738212-641, 28-5667, 9405, 24027N, 24027R, 210024, 210024A, 440982, 12060938

    • Bilmärken
      Hyundai, Kia

    • NormaliseratArtNr
      a3173, a3173valeo, a6223denso, cal32139, dra0243, dra0243n, f032115409, 8el012426181, 8el738212641, 2018ir, 9405, 24027n, 24027r, 115409, 210024, 210024a, 285667, 440982, 12060938, 021319261, 021319262, 3730027020, 3730027021

    • Passar modeller
      Hyundai Model: Grandeur Model series: Grandeur Type of engine: CRDi Size of motor: 2.2 Brand of engine: D4EB From date: 01-06-2006 To date: 01-10-2010 Fuel: Diesel Approved: Yes
      Hyundai Model: i30 Model series: i30 Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Body: Hatchback From date: 01-10-2007 To date: 01-11-2011 Fuel: Diesel Approved: Yes
      Hyundai Model: i30 Model series: i30 Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: FD Body: Estate From date: 01-10-2008 To date: 01-06-2012 Fuel: Diesel Approved: Yes Manufacture type: CW
      Hyundai Model: i30 Model series: i30 Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: FD Body: Hatchback From date: 01-10-2007 To date: 01-11-2011 Fuel: Diesel Approved: Yes
      Hyundai Model: Sonata Model series: Sonata Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA From date: 01-02-2006 To date: 01-12-2010 Fuel: Diesel Approved: Yes
      Hyundai Model: Sonata Model series: Sonata Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: NF From date: 01-03-2009 To date: 01-12-2010 Fuel: Diesel Approved: Yes
      Hyundai Series: Grandeur Model: 2.2 CRDi Engine volume: 2.2 Engine type: D4EB Year: 06.06-
      Hyundai Series: i30 Model: 2.0 CRDi Engine volume: 2.0 Engine type: D4EA Year: 10.07-
      Hyundai Series: Sonata V Model: 2.0 CRDi Engine volume: 2.0 Year: 03.09-
      Kia Model: Carens Model series: Carens Model type: 115 Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: UN Body: MPV From date: 01-05-2007 Fuel: Diesel Approved: Yes
      Kia Model: Carens Model series: Carens Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Body: MPV From date: 01-09-2006 Fuel: Diesel Approved: Yes
      Kia Model: Carens Model series: Carens Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: UN Body: MPV From date: 01-08-2009 Fuel: Diesel Approved: Yes
      Kia Model: Cee'D Model series: Cee'D Model type: 140 Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: ED Body: Estate From date: 01-07-2007 To date: 01-12-2012 Fuel: Diesel Approved: Yes Manufacture type: SW
      Kia Model: Cee'd Model series: Cee'd Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA-F Body: Estate From date: 01-07-2007 To date: 01-12-2012 Fuel: Diesel Approved: Yes
      Kia Model: Cee'd Model series: Cee'd Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA-F Body: Hatchback From date: 01-09-2007 To date: 01-12-2012 Fuel: Diesel Approved: Yes
      Kia Model: Magentis Model series: Magentis Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA From date: 01-04-2006 Fuel: Diesel Approved: Yes
      Kia Model: Magentis Model series: Magentis Type of engine: CRDi Size of motor: 2.0 Brand of engine: D4EA Type description: MG From date: 01-11-2005 To date: 01-12-2008 Fuel: Diesel Approved: Yes
      Kia Series: Carens III (UN) Model: 2.0 CRDi 140 Engine volume: 2.0 Engine type: D4EA Year: 09.06-
      Kia Series: CEE´D Model: 2.0 CRDi 140 Engine volume: 2.0 Engine type: D4EA-F Year: 09.07-
      Kia Series: CEE´D SW Model: 2.0 CRDi 140 Engine volume: 2.0 Engine type: D4EA-F Year: 09.07-
      Kia Series: Magentis Model: 2.0 CRDi Engine volume: 2.0 Engine type: D4EA Year: 04.06-
      Kia Series: PRO CEE´D Model: 2.0 CRDi 140 Engine volume: 2.0 Engine type: D4EA-F Year: 02.08-
