HC-Cargo Dynamo
HC-Cargo Dynamo
Varenr.: F032114248

HC-Cargo Dynamo

Teknisk info:

Spenningsgiver: 14, Amp: 150, Rotasjon: CW, Montering brakett avstand: 52.00

Beskrivelse

Spenningsverdi: 14
Amp: 150
Bredde/holderarm: 14.00
Monteringsbrakettavstand: 52.00
Bærehullsbrakett: 8.00
Belt. justeringsbrakett hullposisjon: 50
Belt. justeringsbrakett hull 1: 8.00
Radius: 80.00
Radius 2: 85.00
B+: M8
Posisjon/B+ i min.: 59
Rotasjon: CW
Plugg nr.: PL57
Total lengde mm: 153.00
Drev: uten
Spenningsregulator type: IR
Prod. info: BN

Filer

Spesifikasjon

B+ M8
Mount. bracket dist. 52.00
Belt. adj. bracket hole 1 8.00
Belt. adj. brackethole pos. 50
Plug no. PL57
Bracket hole 8.00
Position/B+ in min. 59
Prod. info BN
Pulley w/o
Radius 80.00
Radius 2 85.00
Regulator type IR
Rotation CW
Voltage 14
Total length 153.00 mm
Width/holder arm 14.00
Amp 150

  • OEM
    F032114248, 4M5T10300UA, 4M5T10300UB, 4m5t10300uc, 4M5T10300UD, 1986A01291, 1999ir, 104210-2730, 104210-2731, 104210-3640, 104210-3641, 104210-3642, 1352431, 1477740, 1708383, 63377418

  • Konkurrentreferens
    A6026, A6026(DENSO), A6026S, CAL40229, DAN932, DENDAN932, DRA0084, DRA0084X, 8EL012426-221, 8EL738212-521, 27-5525, 4724, 23913R, 112770, 200291, 210431, 210431A, 301999RI, 747051, 9090640, 12090194, 32118730, 063377418, 0986081140, 063377418010

  • NormaliseratArtNr
    a6026, a6026denso, a6026s, cal40229, dan932, dendan932, dra0084, dra0084x, f032114248, 4m5t10300ua, 4m5t10300ub, 4m5t10300uc, 4m5t10300ud, 8el012426221, 8el738212521, 1986a01291, 1999ir, 4724, 23913r, 112770, 200291, 210431, 210431a, 275525, 301999ri, 747051, 1352431, 1477740, 1708383, 9090640, 12090194, 32118730, 063377418, 63377418, 0986081140, 1042102730, 1042102731, 1042103640, 1042103641, 1042103642, 063377418010

  • Passar modeller
    Ford Model: C-Max Model series: C-Max Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDA Body: MPV From date: 01-02-2007 To date: 01-09-2010 Fuel: Diesel Approved: Yes
    Ford Model: Focus Model series: Focus Model type: C-Max Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDA Body: MPV From date: 01-01-2005 To date: 01-03-2007 Fuel: Diesel Approved: Yes
    Ford Model: Focus Model series: Focus Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDA Type description: DAW_ Body: Estate From date: 01-07-2004 To date: 01-09-2012 Fuel: Diesel Approved: Yes Manufacture type: turnier
    Ford Model: Focus Model series: Focus Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDA Type description: DA_ Body: Hatchback From date: 01-01-2005 To date: 01-09-2012 Fuel: Diesel Approved: Yes
    Ford Model: Focus Model series: Focus Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDA Type description: DA_ From date: 01-04-2005 To date: 01-09-2012 Fuel: Diesel Approved: Yes
    Ford Model: Focus Model series: Focus Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDB Type description: DAW_ Body: Estate From date: 01-07-2004 To date: 01-09-2012 Fuel: Diesel Approved: Yes Manufacture type: turnier
    Ford Model: Focus Model series: Focus Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDB Type description: DA_ Body: Hatchback From date: 01-01-2005 To date: 01-09-2012 Fuel: Diesel Approved: Yes
    Ford Model: Focus Model series: Focus Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDB Type description: DA_ From date: 01-04-2005 To date: 01-09-2012 Fuel: Diesel Approved: Yes
    1 / 2
  • Beskrivelse
    Spenningsverdi: 14
    Amp: 150
    Bredde/holderarm: 14.00
    Monteringsbrakettavstand: 52.00
    Bærehullsbrakett: 8.00
    Belt. justeringsbrakett hullposisjon: 50
    Belt. justeringsbrakett hull 1: 8.00
    Radius: 80.00
    Radius 2: 85.00
    B+: M8
    Posisjon/B+ i min.: 59
    Rotasjon: CW
    Plugg nr.: PL57
    Total lengde mm: 153.00
    Drev: uten
    Spenningsregulator type: IR
    Prod. info: BN

    Filer

  • Spesifikasjon
    B+ M8
    Mount. bracket dist. 52.00
    Belt. adj. bracket hole 1 8.00
    Belt. adj. brackethole pos. 50
    Plug no. PL57
    Bracket hole 8.00
    Position/B+ in min. 59
    Prod. info BN
    Pulley w/o
    Radius 80.00
    Radius 2 85.00
    Regulator type IR
    Rotation CW
    Voltage 14
    Total length 153.00 mm
    Width/holder arm 14.00
    Amp 150
  • Kjøretøymatching

    • OEM
      F032114248, 4M5T10300UA, 4M5T10300UB, 4m5t10300uc, 4M5T10300UD, 1986A01291, 1999ir, 104210-2730, 104210-2731, 104210-3640, 104210-3641, 104210-3642, 1352431, 1477740, 1708383, 63377418

    • Konkurrentreferens
      A6026, A6026(DENSO), A6026S, CAL40229, DAN932, DENDAN932, DRA0084, DRA0084X, 8EL012426-221, 8EL738212-521, 27-5525, 4724, 23913R, 112770, 200291, 210431, 210431A, 301999RI, 747051, 9090640, 12090194, 32118730, 063377418, 0986081140, 063377418010

    • NormaliseratArtNr
      a6026, a6026denso, a6026s, cal40229, dan932, dendan932, dra0084, dra0084x, f032114248, 4m5t10300ua, 4m5t10300ub, 4m5t10300uc, 4m5t10300ud, 8el012426221, 8el738212521, 1986a01291, 1999ir, 4724, 23913r, 112770, 200291, 210431, 210431a, 275525, 301999ri, 747051, 1352431, 1477740, 1708383, 9090640, 12090194, 32118730, 063377418, 63377418, 0986081140, 1042102730, 1042102731, 1042103640, 1042103641, 1042103642, 063377418010

    • Passar modeller
      Ford Model: C-Max Model series: C-Max Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDA Body: MPV From date: 01-02-2007 To date: 01-09-2010 Fuel: Diesel Approved: Yes
      Ford Model: Focus Model series: Focus Model type: C-Max Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDA Body: MPV From date: 01-01-2005 To date: 01-03-2007 Fuel: Diesel Approved: Yes
      Ford Model: Focus Model series: Focus Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDA Type description: DAW_ Body: Estate From date: 01-07-2004 To date: 01-09-2012 Fuel: Diesel Approved: Yes Manufacture type: turnier
      Ford Model: Focus Model series: Focus Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDA Type description: DA_ Body: Hatchback From date: 01-01-2005 To date: 01-09-2012 Fuel: Diesel Approved: Yes
      Ford Model: Focus Model series: Focus Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDA Type description: DA_ From date: 01-04-2005 To date: 01-09-2012 Fuel: Diesel Approved: Yes
      Ford Model: Focus Model series: Focus Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDB Type description: DAW_ Body: Estate From date: 01-07-2004 To date: 01-09-2012 Fuel: Diesel Approved: Yes Manufacture type: turnier
      Ford Model: Focus Model series: Focus Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDB Type description: DA_ Body: Hatchback From date: 01-01-2005 To date: 01-09-2012 Fuel: Diesel Approved: Yes
      Ford Model: Focus Model series: Focus Type of engine: TDCi Size of motor: 1.8 Brand of engine: KKDB Type description: DA_ From date: 01-04-2005 To date: 01-09-2012 Fuel: Diesel Approved: Yes
