HC-Cargo Dynamo
HC-Cargo Dynamo
Varenr.: F032114026

HC-Cargo Dynamo

Teknisk info:

Spenningsregulator: 14, Amp: 80, Rotasjon: CW, Festebrakett avstand: 66,50

Beskrivelse

Spenning: 14
Ampere: 80
Drevskive avstand: 42,00
Bredde/holderarm: 27,00
Festebrakett avstand: 66,50
Brakett hull: 10,50
Belt. justeringsbrakett hullposisjon: 3
Belt. justeringsbrakett hull 1: 8,00
Drevskivediameter: 62,50
Løper/krans: 6
Radius: 84,00
Radius 2: 87,00
B+: M8
Posisjon/B+ i min.: 6
D+: størrelse: M5
Rotasjon: med urviseren
Drevskive: SP
Regulator type: IR
Produsentinfo: BN

Filer

Spesifikasjon

B+ M8
Mount. bracket dist. 66.50
Belt. adj. bracket hole 1 8.00
Belt. adj. brackethole pos. 3
Bracket hole 10.50
Position/B+ in min. 6
Prod. info BN
Pulley SP
Pulley dia. 62.50
Pulley dist. 42.00
Radius 84.00
D+ Size M5
Radius 2 87.00
Regulator type IR
Rotation CW
Grooves/pulley 6
Voltage 14
Width/holder arm 27.00
Amp 80

  • OEM
    a13vi31, a13vi85, F032114026, 639ir, 2541360, 2541738, 2541738B, 2541738C, 95598735, 95667748, 95667749, 96076616, 96122598, 96667749

  • Konkurrentreferens
    A3021, ALT-7226, CAL15140, DRA3233, dra3235, F042208037, F042A0B015, lra00946, 8EL012427-361, 8el725923-001, 16-38.811, 28-1973, 216.112.802, 3658, 4941, 5705e3, 5705HX, 5705k4, 5705N5, 5705V0, 22448N, 30639RI, 56503, 118454, 118673, 200128, 436340, 746876, 9212359, 12037050, 12038810, 0986038811, 943356567010

  • NormaliseratArtNr
    a13vi31, a13vi85, a3021, alt7226, cal15140, dra3233, dra3235, f032114026, f042208037, f042a0b015, lra00946, 8el012427361, 8el725923001, 639ir, 3658, 4941, 5705e3, 5705hx, 5705k4, 5705n5, 5705v0, 22448n, 30639ri, 56503, 118454, 118673, 200128, 281973, 436340, 746876, 1638811, 2541360, 2541738, 2541738b, 2541738c, 9212359, 12037050, 12038810, 95598735, 95667748, 95667749, 96076616, 96122598, 96667749, 216112802, 0986038811, 943356567010

  • Passar modeller
    Citroen Model: AX Model series: AX 10 Size of motor: 1.0 Brand of engine: CDZ (TU9M) Body: Hatchback From date: 01-02-1987 To date: 01-12-1998 Fuel: Gasoline Approved: Yes
    Citroen Model: AX Model series: AX 11 Model type: 4x4 Size of motor: 1.1 Brand of engine: H1A (TU1) Type description: ZA_ Body: Hatchback From date: 01-06-1991 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    Citroen Model: AX Model series: AX Model type: 4x4 Size of motor: 1.4 Brand of engine: K2A Type description: ZA-: Body: Hatchback From date: 01-09-1986 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    Citroen Model: Xantia Model series: Xantia Type of engine: Diesel Size of motor: 1.9 Brand of engine: DHW (XUD9SD) Body: Estate From date: 01-04-1997 To date: 01-04-2003 Fuel: Diesel Approved: Yes Manufacture type: break
    Citroen Model: ZX Model series: ZX Break Type of engine: Diesel Size of motor: 1.9 Brand of engine: D9B (XUD9A/L) Type description: N2 Body: Estate From date: 01-10-1993 To date: 01-07-1999 Fuel: Diesel Approved: Yes Manufacture type: Break
    Citroen Model: ZX Model series: ZX Type of engine: Diesel Size of motor: 1.8 Type description: N2 Body: Estate From date: 01-06-1996 To date: 01-10-1997 Fuel: Diesel Approved: Yes Manufacture type: Estate
    Citroen Model: ZX Model series: ZX Type of engine: Diesel Size of motor: 1.9 Brand of engine: D9B (XUD9A/L) Type description: N2 Body: Hatchback From date: 01-10-1993 To date: 01-07-1999 Fuel: Diesel Approved: Yes
    Citroen Model: ZX Model series: ZX Type of engine: Diesel Size of motor: 1.9 Brand of engine: D9B (XUD9A/U) Body: Hatchback From date: 01-07-1993 To date: 01-06-1997 Fuel: Diesel Approved: Yes
    Citroen Model: ZX Model series: ZX Type of engine: Diesel Size of motor: 1.9 Brand of engine: DJY (XUD9A) Body: Hatchback From date: 01-07-1993 To date: 01-06-1997 Fuel: Diesel Approved: Yes
    Citroen Model: ZX Model series: ZX Type of engine: Diesel Size of motor: 1.9 Brand of engine: DJZ (XUD9Y) Body: Estate From date: 01-10-1993 To date: 01-10-1997 Fuel: Diesel Approved: Yes Manufacture type: break
    Citroen Model: ZX Model series: ZX Type of engine: Diesel Size of motor: 1.9 Brand of engine: DJZ (XUD9Y) Body: Hatchback From date: 01-03-1991 To date: 01-06-1997 Fuel: Diesel Approved: Yes
    Citroen Model: ZX Model series: ZX Type of engine: TD Size of motor: 1.9 Brand of engine: DHY (XUD9TE/Y) Body: Estate From date: 01-10-1993 To date: 01-10-1997 Fuel: Diesel Approved: Yes Manufacture type: break
    Peugeot Model: 205 Model series: 205 Model type: Rally Size of motor: 1.3 Brand of engine: TU24 Body: Hatchback From date: 01-10-1987 To date: 01-10-1990 Fuel: Gasoline Approved: Yes
    Peugeot Model: 205 Model series: 205 Size of motor: 1.0 Brand of engine: TU9 Body: Hatchback From date: 01-10-1987 To date: 01-09-1998 Fuel: Gasoline Approved: Yes
    Peugeot Model: 205 Model series: 205 Size of motor: 1.1 Brand of engine: HDZ (TU1M) Body: Hatchback From date: 01-07-1989 To date: 01-09-1998 Fuel: Gasoline Approved: Yes
    Peugeot Model: 205 Model series: 205 Size of motor: 1.4 Brand of engine: KDY (TU3M) Body: Hatchback From date: 01-07-1988 To date: 01-09-1998 Fuel: Gasoline Approved: Yes
    Peugeot Model: 205 Model series: 205 Size of motor: 1.4 Brand of engine: KDZ (TU3M) Body: Hatchback From date: 01-07-1988 To date: 01-09-1998 Fuel: Gasoline Approved: Yes
    Peugeot Model: 405 Model series: 405 Type of engine: Diesel Size of motor: 1.9 Brand of engine: DJY (XUD9A) From date: 01-06-1994 To date: 01-10-1995 Fuel: Diesel Approved: Yes
    Peugeot Model: 405 Model series: 405 Type of engine: Diesel Size of motor: 1.9 Brand of engine: DJZ (XUD9Y) From date: 01-08-1992 To date: 01-10-1995 Fuel: Diesel Approved: Yes
    Peugeot Model: 405 Model series: 405 Type of engine: Diesel Size of motor: 1.9 Brand of engine: XUD9 Type description: 4E Body: Estate From date: 01-09-1993 To date: 01-12-1995 Fuel: Diesel Approved: Yes Manufacture type: break
    Peugeot Model: 405 Model series: 405 Type of engine: TD Size of motor: 1.9 Brand of engine: DHY (XUD9TE) Body: Estate From date: 01-08-1992 To date: 01-10-1996 Fuel: Diesel Approved: Yes Manufacture type: break
    Peugeot Model: 405 Model series: 405 Type of engine: TD Size of motor: 1.9 Brand of engine: DHY (XUD9TE) From date: 01-08-1992 To date: 01-10-1995 Fuel: Diesel Approved: Yes
    1 / 5
