HC-Cargo Dynamo
HC-Cargo Dynamo
Varenr.: F032111017

HC-Cargo Dynamo

Teknisk info:

Spenningsverdi: 14, Ampere: 50, Rotasjon: CW, Monteringsbeslag avstand: 67,30

Beskrivelse

Spenning: 14
Ampere: 50
Drevkugg: 45.00
Bredde/holderarm: 20.00
Festeanordningsavstand: 67.30
Festehull: 8.50
Beltesjusteringsbøssingposisjon: 60
Beltesjusteringsbøssing hull 1: M8
Drevdiameter: 79.00
Groper/drev: 1
Radius: 78.00
Radius 2: 78.00
B+: M6
Posisjon/B+ i min.: 8
Rotasjon: CW
Rørenummer: PL10
Total lengde mm: 160.50
Drev: P
Regul. type: IR
Prod. info: BN
Vedlikehold: Toyota

Filer

Spesifikasjon

B+ M6
Mount. bracket dist. 67.30
Belt. adj. bracket hole 1 M8
Belt. adj. brackethole pos. 60
Plug no. PL10
Bracket hole 8.50
Position/B+ in min. 8
Prod. info BN
Pulley P
Pulley dia. 79.00
Pulley dist. 45.00
Radius 78.00
Radius 2 78.00
Regulator type IR
Rotation CW
Servicing Toyota
Grooves/pulley 1
Voltage 14
Total length 160.50 mm
Width/holder arm 20.00
Amp 50

  • OEM
    F032111017, 27070-23000-71, 100211-4200, 100211-4201, 100211-4210

  • Konkurrentreferens
    ALT5095, CAL40197, DRA1387, 28-2805, 535.109.502, 12181N, 12186, 12186N

  • NormaliseratArtNr
    alt5095, cal40197, dra1387, f032111017, 12181n, 12186, 12186n, 282805, 535109502, 1002114200, 1002114201, 1002114210, 270702300071

  • Passar modeller
    Toyota Model: 5FG Model series: 5FG20 From date: 01-01-1989 Approved: Yes
    Toyota Model: 5FG Model series: 5FG23 From date: 01-01-1989 To date: 01-01-1993 Approved: Yes
    Toyota Model: 5FG Model series: 5FG25 From date: 01-01-1989 To date: 01-01-1993 Approved: Yes
    Toyota Model: 5FG Model series: 5FGL20 From date: 01-01-1989 Approved: Yes
    Toyota Model: 5FG Model series: 5FGL23 From date: 01-01-1989 Approved: Yes
  • Beskrivelse
    Spenning: 14
    Ampere: 50
    Drevkugg: 45.00
    Bredde/holderarm: 20.00
    Festeanordningsavstand: 67.30
    Festehull: 8.50
    Beltesjusteringsbøssingposisjon: 60
    Beltesjusteringsbøssing hull 1: M8
    Drevdiameter: 79.00
    Groper/drev: 1
    Radius: 78.00
    Radius 2: 78.00
    B+: M6
    Posisjon/B+ i min.: 8
    Rotasjon: CW
    Rørenummer: PL10
    Total lengde mm: 160.50
    Drev: P
    Regul. type: IR
    Prod. info: BN
    Vedlikehold: Toyota

    Filer

  • Spesifikasjon
    B+ M6
    Mount. bracket dist. 67.30
    Belt. adj. bracket hole 1 M8
    Belt. adj. brackethole pos. 60
    Plug no. PL10
    Bracket hole 8.50
    Position/B+ in min. 8
    Prod. info BN
    Pulley P
    Pulley dia. 79.00
    Pulley dist. 45.00
    Radius 78.00
    Radius 2 78.00
    Regulator type IR
    Rotation CW
    Servicing Toyota
    Grooves/pulley 1
    Voltage 14
    Total length 160.50 mm
    Width/holder arm 20.00
    Amp 50
  • Kjøretøymatching

    • OEM
      F032111017, 27070-23000-71, 100211-4200, 100211-4201, 100211-4210

    • Konkurrentreferens
      ALT5095, CAL40197, DRA1387, 28-2805, 535.109.502, 12181N, 12186, 12186N

    • NormaliseratArtNr
      alt5095, cal40197, dra1387, f032111017, 12181n, 12186, 12186n, 282805, 535109502, 1002114200, 1002114201, 1002114210, 270702300071

    • Passar modeller
      Toyota Model: 5FG Model series: 5FG20 From date: 01-01-1989 Approved: Yes
      Toyota Model: 5FG Model series: 5FG23 From date: 01-01-1989 To date: 01-01-1993 Approved: Yes
      Toyota Model: 5FG Model series: 5FG25 From date: 01-01-1989 To date: 01-01-1993 Approved: Yes
      Toyota Model: 5FG Model series: 5FGL20 From date: 01-01-1989 Approved: Yes
      Toyota Model: 5FG Model series: 5FGL23 From date: 01-01-1989 Approved: Yes
