HC-Cargo Dynamo
HC-Cargo Dynamo
Varenr.: F032116089

HC-Cargo Dynamo

Teknisk info:

Spenning: 14, Amp: 120, Rotasjon: CW, Remskive diameter: 54.00

Beskrivelse

Spenning: 14
Amp: 120
Drevkugg. dist.: 116.00
Bredde/holder arm: 61.00
Gavl huls: 12.30
Reimh. justering Gavl huls pos.: 59
Reimh. justering Gavl huls 1: 12.30
Drevdiameter: 54.00
Grooves/drev: 5
Radius: 90.00
Radius 2: 90.00
B+: M8
D+: Størrelse: M5
Rotasjon: CW
Total lengde mm: 199.00
Drev: SP/FW
Vifte: IF
Regulator type: IR

Filer

Spesifikasjon

B+ M8
Belt. adj. bracket hole 1 12.30
Belt. adj. brackethole pos. 59
Bracket hole 12.30
Pulley SP/FW
Pulley dia. 54.00
Pulley dist. 116.00
Radius 90.00
D+ Size M5
Radius 2 90.00
Regulator type IR
Rotation CW
Fan IF
Grooves/pulley 5
Voltage 14
Total length 199.00 mm
Width/holder arm 61.00
Amp 120

  • OEM
    F032116089, 101210-1330, 101210-1331, 51820622, 51854917, 52003514

  • Konkurrentreferens
    A6165(DENSO), CAL30238, DAN1083, LRA03657, 28-6797, 218.324.1202, 209105, 209105A, 444223, 554151RI, 9090728, 12090853

  • NormaliseratArtNr
    a6165denso, cal30238, dan1083, f032116089, lra03657, 209105, 209105a, 286797, 444223, 554151ri, 9090728, 12090853, 51820622, 51854917, 52003514, 1012101330, 1012101331, 2183241202

  • Passar modeller
    Abarth Model: 500 Model series: 500 Model type: Abarth Size of motor: 1.4 Brand of engine: 312A1.000 Body: Hatchback From date: 01-08-2008 Fuel: Gasoline Approved: Yes
    Abarth Model: 500 Model series: 500 Model type: Abarth Size of motor: 1.4 Brand of engine: 312A3.000 Body: Convertible From date: 01-06-2010 Fuel: Gasoline Approved: Yes
    Abarth Model: 500 Model series: 500 Model type: Abarth Size of motor: 1.4 Brand of engine: 312A3.000 Body: Hatchback From date: 01-08-2008 Fuel: Gasoline Approved: Yes
    Abarth Model: 500 Model series: 500 Model type: Abarth Type of engine: 16V Size of motor: 1.4 Brand of engine: 312A3.000 Type description: 150 Body: Hatchback From date: 01-08-2008 Fuel: Gasoline Approved: Yes
    Abarth Model: 500C / 595C Model series: 500C / 595C Size of motor: 1.4 Brand of engine: 312B3.000 Type description: 312_ Body: Convertible From date: 01-05-2016 Fuel: Gasoline Approved: Yes
    Abarth Model: 500C / 595C Model series: 500C / 595C Size of motor: 1.4 Brand of engine: 312B4.000 Type description: 312_ Body: Convertible From date: 01-05-2016 Fuel: Gasoline Approved: Yes
    Fiat Model: 500 Model series: 500 C Model type: Abarth Size of motor: 1.4 Brand of engine: 312A1.000 Body: Convertible From date: 01-05-2011 Fuel: Gasoline Approved: Yes
    Fiat Model: 500 Model series: 500 C Model type: Abarth Size of motor: 1.4 Brand of engine: 312A3.000 Body: Convertible From date: 01-09-2009 Fuel: Gasoline Approved: Yes
    Fiat Model: 500 Model series: 500 Model type: Abarth Size of motor: 1.4 Brand of engine: 312A1.000 Body: Hatchback From date: 01-08-2008 Fuel: Gasoline Approved: Yes
    Fiat Model: 500 Model series: 500 Model type: Abarth Size of motor: 1.4 Brand of engine: 312A3.000 Body: Hatchback From date: 01-05-2010 Fuel: Gasoline Approved: Yes
    Fiat Model: 500 Model series: 500 Model type: Abarth Size of motor: 1.4 Brand of engine: 312A9.000 Body: Hatchback From date: 01-08-2008 Fuel: Gasoline Approved: Yes
    1 / 3
  • Beskrivelse
    Spenning: 14
    Amp: 120
    Drevkugg. dist.: 116.00
    Bredde/holder arm: 61.00
    Gavl huls: 12.30
    Reimh. justering Gavl huls pos.: 59
    Reimh. justering Gavl huls 1: 12.30
    Drevdiameter: 54.00
    Grooves/drev: 5
    Radius: 90.00
    Radius 2: 90.00
    B+: M8
    D+: Størrelse: M5
    Rotasjon: CW
    Total lengde mm: 199.00
    Drev: SP/FW
    Vifte: IF
    Regulator type: IR

    Filer

  • Spesifikasjon
    B+ M8
    Belt. adj. bracket hole 1 12.30
    Belt. adj. brackethole pos. 59
    Bracket hole 12.30
    Pulley SP/FW
    Pulley dia. 54.00
    Pulley dist. 116.00
    Radius 90.00
    D+ Size M5
    Radius 2 90.00
    Regulator type IR
    Rotation CW
    Fan IF
    Grooves/pulley 5
    Voltage 14
    Total length 199.00 mm
    Width/holder arm 61.00
    Amp 120
  • Kjøretøymatching

    • OEM
      F032116089, 101210-1330, 101210-1331, 51820622, 51854917, 52003514

    • Konkurrentreferens
      A6165(DENSO), CAL30238, DAN1083, LRA03657, 28-6797, 218.324.1202, 209105, 209105A, 444223, 554151RI, 9090728, 12090853

    • NormaliseratArtNr
      a6165denso, cal30238, dan1083, f032116089, lra03657, 209105, 209105a, 286797, 444223, 554151ri, 9090728, 12090853, 51820622, 51854917, 52003514, 1012101330, 1012101331, 2183241202

    • Passar modeller
      Abarth Model: 500 Model series: 500 Model type: Abarth Size of motor: 1.4 Brand of engine: 312A1.000 Body: Hatchback From date: 01-08-2008 Fuel: Gasoline Approved: Yes
      Abarth Model: 500 Model series: 500 Model type: Abarth Size of motor: 1.4 Brand of engine: 312A3.000 Body: Convertible From date: 01-06-2010 Fuel: Gasoline Approved: Yes
      Abarth Model: 500 Model series: 500 Model type: Abarth Size of motor: 1.4 Brand of engine: 312A3.000 Body: Hatchback From date: 01-08-2008 Fuel: Gasoline Approved: Yes
      Abarth Model: 500 Model series: 500 Model type: Abarth Type of engine: 16V Size of motor: 1.4 Brand of engine: 312A3.000 Type description: 150 Body: Hatchback From date: 01-08-2008 Fuel: Gasoline Approved: Yes
      Abarth Model: 500C / 595C Model series: 500C / 595C Size of motor: 1.4 Brand of engine: 312B3.000 Type description: 312_ Body: Convertible From date: 01-05-2016 Fuel: Gasoline Approved: Yes
      Abarth Model: 500C / 595C Model series: 500C / 595C Size of motor: 1.4 Brand of engine: 312B4.000 Type description: 312_ Body: Convertible From date: 01-05-2016 Fuel: Gasoline Approved: Yes
      Fiat Model: 500 Model series: 500 C Model type: Abarth Size of motor: 1.4 Brand of engine: 312A1.000 Body: Convertible From date: 01-05-2011 Fuel: Gasoline Approved: Yes
      Fiat Model: 500 Model series: 500 C Model type: Abarth Size of motor: 1.4 Brand of engine: 312A3.000 Body: Convertible From date: 01-09-2009 Fuel: Gasoline Approved: Yes
      Fiat Model: 500 Model series: 500 Model type: Abarth Size of motor: 1.4 Brand of engine: 312A1.000 Body: Hatchback From date: 01-08-2008 Fuel: Gasoline Approved: Yes
      Fiat Model: 500 Model series: 500 Model type: Abarth Size of motor: 1.4 Brand of engine: 312A3.000 Body: Hatchback From date: 01-05-2010 Fuel: Gasoline Approved: Yes
      Fiat Model: 500 Model series: 500 Model type: Abarth Size of motor: 1.4 Brand of engine: 312A9.000 Body: Hatchback From date: 01-08-2008 Fuel: Gasoline Approved: Yes
      1 / 3
