HC-Cargo Dynamo
HC-Cargo Dynamo
Varenr.: F032116330

HC-Cargo Dynamo

Teknisk info:

Spenningsregulator: 14, Amp: 75, Rotasjon: CW, Festebrakett avstand: 55,00

Beskrivelse

Spenningsnivå: 14
Amp: 75
Drevavstand: 40,50
Bredde/holderarm: 64,00
Monteringsbeslag avstand: 55,00
Beslagshull: 10,50
Båndjusteringsbeslagshull 1: 10,50
Drevdiameter: 54,00
Morene/groove: 6
Radius: 76,50
Radius 2: 77,00
B+: M8
Posisjon/B+ i min.: 13
D+: M5
Rotasjon: medur → medurs
Total lengde mm: 175,00
Lysstoff: Aktiv
Drev: SP
Vifte: IF
Regulator type: IR

Filer

Spesifikasjon

B+ M8
Mount. bracket dist. 55.00
Belt. adj. bracket hole 1 10.50
Bracket hole 10.50
Position/B+ in min. 13
Pulley SP
Pulley dia. 54.00
Pulley dist. 40.50
Radius 76.50
D+ Size M5
Radius 2 77.00
Regulator type IR
Rotation CW
Fan IF
Grooves/pulley 6
Lamp type Active
Voltage 14
Total length 175.00 mm
Width/holder arm 64.00
Amp 75

  • OEM
    A3104(VALEO), A3104PR, A6086, A6086(DENSO), ALT-H152, CAL15124, CAL30200, DAN1003, DENDAN1003, DRA4249, F032116330, F042A0H152, LRA02797, TG8S021, 28-4914, 101210-1210, 101210-1211, 101211-1211, 112367, 112902, 210406, 210406A, 301856RI, 439506, 747036, 2542671, 2542671A, 2542671B, 2543484, 2543484A, 12090026, 46823546, 51784847, 51805803, 51984050, 52003511, 52092133, 063358062, 468235460, 943358062, 063358062010, 063377024010, 943358062010, 944390902100

  • Konkurrentreferens
    A3104(VALEO), A3104PR, A6086, A6086(DENSO), ALT-H152, CAL15124, CAL30200, DAN1003, DENDAN1003, DRA4249, F042A0H152, LRA02797, 28-4914, 112367, 112902, 210406, 210406A, 301856RI, 439506, 747036, 12090026, 063358062, 943358062, 063358062010, 063377024010, 943358062010, 944390902100

  • Bilmärken
    FIAT, LANCIA

  • NormaliseratArtNr
    a3104pr, a3104valeo, a6086, a6086denso, alth152, cal15124, cal30200, dan1003, dendan1003, dra4249, f032116330, f042a0h152, lra02797, tg8s021, 112367, 112902, 210406, 210406a, 284914, 301856ri, 439506, 747036, 2542671, 2542671a, 2542671b, 2543484, 2543484a, 12090026, 46823546, 51784847, 51805803, 51984050, 52003511, 52092133, 063358062, 468235460, 943358062, 1012101210, 1012101211, 1012111211, 063358062010, 063377024010, 943358062010, 944390902100

  • Passar modeller
    FIAT 500 (312_) 1.3 D Multijet (312AXB1A) Engine volume: 1.3 Engine type: 169 A1.000 Year: 10.07-
    FIAT DOBLO Buss (263_) 1.3 D Multijet (263AXC1A) Engine volume: 1.3 Engine type: 199 A3.000, 263 A2.000 Year: 02.10-12.23
    FIAT DOBLO Flak/chassi (263_) 1.3 D Multijet Engine volume: 1.3 Engine type: 199 A3.000, 263 A2.000 Year: 02.10-12.23
    FIAT DOBLO Skåpbil/minivan (223_) 1.3 JTD 16V Engine volume: 1.3 Engine type: 188 A9.000, 188 A8.000 Year: 05.04-12.06
    FIAT FIORINO Minibus, minivan (225_) 1.3 JTD Multijet (225BXB1A, 225BXB11) Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 11.07-
    FIAT FIORINO Minibus, minivan (225_) 1.3 JTD Multijet Engine volume: 1.3 Engine type: 330 A1.000, 199 B1.000, 463 45 266 Year: 01.11-
    FIAT FIORINO Skåp/stor limousine (225_) 1.3 D Multijet (225BXD1A, 225BXB1A, 225BXB11) Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 11.07-
    FIAT GRANDE PUNTO (199_) 1.3 D Multijet (199.AXD11, 199.AXD1A, 199.AXD1B,... Engine volume: 1.3 Engine type: 199 A3.000 Year: 10.05-12.10
    FIAT GRANDE PUNTO (199_) 1.3 D Multijet Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 10.05-06.13
    FIAT IDEA (350_) 1.3 D Multijet Engine volume: 1.3 Engine type: 188 A9.000 Year: 01.04-
    FIAT IDEA (350_) 1.3 D Multijet Engine volume: 1.3 Engine type: 199 A3.000 Year: 10.05-
    FIAT LINEA (323_, 110_) 1.3 D Multijet (323AXB11, 323AXB1A) Engine volume: 1.3 Engine type: 199 A3.000 Year: 06.07-
    FIAT PANDA (169_) 1.3 D Multijet (169.AXC1A) Engine volume: 1.3 Engine type: 188 A8.000 Year: 09.03-
    FIAT PANDA (169_) 1.3 D Multijet (169AXG1A, 169AXD1A) Engine volume: 1.3 Engine type: 169 A5.000, 169 A1.000 Year: 06.06-08.13
    FIAT PANDA (169_) 1.3 D Multijet 4x4 (169.AXC2A) Engine volume: 1.3 Engine type: 188 A8.000 Year: 10.04-
    FIAT PANDA Skåpbil/halvkombi (169_) 1.3 D Multijet 4x4 Engine volume: 1.3 Engine type: 169 A1.000 Year: 01.06-
    FIAT PUNTO (188_) 1.3 JTD 16V Engine volume: 1.3 Engine type: 188 A9.000 Year: 06.03-03.12
    FIAT PUNTO (199_) 1.3 D Multijet Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 03.12-
    FIAT PUNTO EVO (199_) 1.3 D Multijet (199AXD1B, 199AXD1A, 199BXD1B, 199BXD1A,... Engine volume: 1.3 Engine type: 199 A3.000 Year: 10.09-02.12
    FIAT PUNTO Skåp/halvkombi (199_) 1.3 D Multijet Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 04.08-
    FIAT QUBO (225_) 1.3 D Multijet (225CXB1A, 225AXB1A, 225CXB11, 225AXB11,... Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 02.08-
    FIAT STRADA Pick-up (178_, 278_) 1.3 D Multijet Engine volume: 1.3 Engine type: 223 A9.000 Year: 05.06-08.12
    LANCIA MUSA (350_) 1.3 D Multijet (350.AXB11, 350.AXB1A) Engine volume: 1.3 Engine type: 188 A9.000 Year: 10.04-09.12
    LANCIA MUSA (350_) 1.3 D Multijet (350.AXG11, 350.AXG1A) Engine volume: 1.3 Engine type: 199 A3.000 Year: 09.06-09.12
    LANCIA YPSILON (843_) 1.3 D Multijet (843.AXE11, 843.AXE1A) Engine volume: 1.3 Engine type: 199 A3.000 Year: 09.06-12.11
    LANCIA YPSILON (843_) 1.3 D Multijet (843.AXF11, 843.AXF1A, 843.AXM11,... Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 09.06-12.11
    LANCIA YPSILON (843_) 1.3 JTD (843.AXD11, 843.AXD1A) Engine volume: 1.3 Engine type: 188 A9.000 Year: 10.03-12.11
    1 / 6
  • Beskrivelse
    Spenningsnivå: 14
    Amp: 75
    Drevavstand: 40,50
    Bredde/holderarm: 64,00
    Monteringsbeslag avstand: 55,00
    Beslagshull: 10,50
    Båndjusteringsbeslagshull 1: 10,50
    Drevdiameter: 54,00
    Morene/groove: 6
    Radius: 76,50
    Radius 2: 77,00
    B+: M8
    Posisjon/B+ i min.: 13
    D+: M5
    Rotasjon: medur → medurs
    Total lengde mm: 175,00
    Lysstoff: Aktiv
    Drev: SP
    Vifte: IF
    Regulator type: IR

    Filer

  • Spesifikasjon
    B+ M8
    Mount. bracket dist. 55.00
    Belt. adj. bracket hole 1 10.50
    Bracket hole 10.50
    Position/B+ in min. 13
    Pulley SP
    Pulley dia. 54.00
    Pulley dist. 40.50
    Radius 76.50
    D+ Size M5
    Radius 2 77.00
    Regulator type IR
    Rotation CW
    Fan IF
    Grooves/pulley 6
    Lamp type Active
    Voltage 14
    Total length 175.00 mm
    Width/holder arm 64.00
    Amp 75
  • Kjøretøymatching

    • OEM
      A3104(VALEO), A3104PR, A6086, A6086(DENSO), ALT-H152, CAL15124, CAL30200, DAN1003, DENDAN1003, DRA4249, F032116330, F042A0H152, LRA02797, TG8S021, 28-4914, 101210-1210, 101210-1211, 101211-1211, 112367, 112902, 210406, 210406A, 301856RI, 439506, 747036, 2542671, 2542671A, 2542671B, 2543484, 2543484A, 12090026, 46823546, 51784847, 51805803, 51984050, 52003511, 52092133, 063358062, 468235460, 943358062, 063358062010, 063377024010, 943358062010, 944390902100

    • Konkurrentreferens
      A3104(VALEO), A3104PR, A6086, A6086(DENSO), ALT-H152, CAL15124, CAL30200, DAN1003, DENDAN1003, DRA4249, F042A0H152, LRA02797, 28-4914, 112367, 112902, 210406, 210406A, 301856RI, 439506, 747036, 12090026, 063358062, 943358062, 063358062010, 063377024010, 943358062010, 944390902100

    • Bilmärken
      FIAT, LANCIA

    • NormaliseratArtNr
      a3104pr, a3104valeo, a6086, a6086denso, alth152, cal15124, cal30200, dan1003, dendan1003, dra4249, f032116330, f042a0h152, lra02797, tg8s021, 112367, 112902, 210406, 210406a, 284914, 301856ri, 439506, 747036, 2542671, 2542671a, 2542671b, 2543484, 2543484a, 12090026, 46823546, 51784847, 51805803, 51984050, 52003511, 52092133, 063358062, 468235460, 943358062, 1012101210, 1012101211, 1012111211, 063358062010, 063377024010, 943358062010, 944390902100

    • Passar modeller
      FIAT 500 (312_) 1.3 D Multijet (312AXB1A) Engine volume: 1.3 Engine type: 169 A1.000 Year: 10.07-
      FIAT DOBLO Buss (263_) 1.3 D Multijet (263AXC1A) Engine volume: 1.3 Engine type: 199 A3.000, 263 A2.000 Year: 02.10-12.23
      FIAT DOBLO Flak/chassi (263_) 1.3 D Multijet Engine volume: 1.3 Engine type: 199 A3.000, 263 A2.000 Year: 02.10-12.23
      FIAT DOBLO Skåpbil/minivan (223_) 1.3 JTD 16V Engine volume: 1.3 Engine type: 188 A9.000, 188 A8.000 Year: 05.04-12.06
      FIAT FIORINO Minibus, minivan (225_) 1.3 JTD Multijet (225BXB1A, 225BXB11) Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 11.07-
      FIAT FIORINO Minibus, minivan (225_) 1.3 JTD Multijet Engine volume: 1.3 Engine type: 330 A1.000, 199 B1.000, 463 45 266 Year: 01.11-
      FIAT FIORINO Skåp/stor limousine (225_) 1.3 D Multijet (225BXD1A, 225BXB1A, 225BXB11) Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 11.07-
      FIAT GRANDE PUNTO (199_) 1.3 D Multijet (199.AXD11, 199.AXD1A, 199.AXD1B,... Engine volume: 1.3 Engine type: 199 A3.000 Year: 10.05-12.10
      FIAT GRANDE PUNTO (199_) 1.3 D Multijet Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 10.05-06.13
      FIAT IDEA (350_) 1.3 D Multijet Engine volume: 1.3 Engine type: 188 A9.000 Year: 01.04-
      FIAT IDEA (350_) 1.3 D Multijet Engine volume: 1.3 Engine type: 199 A3.000 Year: 10.05-
      FIAT LINEA (323_, 110_) 1.3 D Multijet (323AXB11, 323AXB1A) Engine volume: 1.3 Engine type: 199 A3.000 Year: 06.07-
      FIAT PANDA (169_) 1.3 D Multijet (169.AXC1A) Engine volume: 1.3 Engine type: 188 A8.000 Year: 09.03-
      FIAT PANDA (169_) 1.3 D Multijet (169AXG1A, 169AXD1A) Engine volume: 1.3 Engine type: 169 A5.000, 169 A1.000 Year: 06.06-08.13
      FIAT PANDA (169_) 1.3 D Multijet 4x4 (169.AXC2A) Engine volume: 1.3 Engine type: 188 A8.000 Year: 10.04-
      FIAT PANDA Skåpbil/halvkombi (169_) 1.3 D Multijet 4x4 Engine volume: 1.3 Engine type: 169 A1.000 Year: 01.06-
      FIAT PUNTO (188_) 1.3 JTD 16V Engine volume: 1.3 Engine type: 188 A9.000 Year: 06.03-03.12
      FIAT PUNTO (199_) 1.3 D Multijet Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 03.12-
      FIAT PUNTO EVO (199_) 1.3 D Multijet (199AXD1B, 199AXD1A, 199BXD1B, 199BXD1A,... Engine volume: 1.3 Engine type: 199 A3.000 Year: 10.09-02.12
      FIAT PUNTO Skåp/halvkombi (199_) 1.3 D Multijet Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 04.08-
      FIAT QUBO (225_) 1.3 D Multijet (225CXB1A, 225AXB1A, 225CXB11, 225AXB11,... Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 02.08-
      FIAT STRADA Pick-up (178_, 278_) 1.3 D Multijet Engine volume: 1.3 Engine type: 223 A9.000 Year: 05.06-08.12
      LANCIA MUSA (350_) 1.3 D Multijet (350.AXB11, 350.AXB1A) Engine volume: 1.3 Engine type: 188 A9.000 Year: 10.04-09.12
      LANCIA MUSA (350_) 1.3 D Multijet (350.AXG11, 350.AXG1A) Engine volume: 1.3 Engine type: 199 A3.000 Year: 09.06-09.12
      LANCIA YPSILON (843_) 1.3 D Multijet (843.AXE11, 843.AXE1A) Engine volume: 1.3 Engine type: 199 A3.000 Year: 09.06-12.11
      LANCIA YPSILON (843_) 1.3 D Multijet (843.AXF11, 843.AXF1A, 843.AXM11,... Engine volume: 1.3 Engine type: 199 A2.000, 199 A9.000 Year: 09.06-12.11
      LANCIA YPSILON (843_) 1.3 JTD (843.AXD11, 843.AXD1A) Engine volume: 1.3 Engine type: 188 A9.000 Year: 10.03-12.11
