HC-Cargo Dynamo
HC-Cargo Dynamo
Varenr.: F032115994

HC-Cargo Dynamo

Teknisk info:

Spenning: 28, Amp: 40, Rotasjon: CW, Monteringsbeslag avstand: 68.00

Beskrivelse

Spenningsnivå: 28
Ampere: 40
Terminal: W
Drev avstand: 60.00
Bredde/holderarm: 16.00
Festebrakett avstand: 68.00
Brakett hull: 15.00
Båndjusteringsbrakett hull posisjon: 60
Båndjusteringsbrakett hull 1: 13.20
Drev diameter: 82.00
Ytterspor/drev: 2
Radius: 110.00
Radius 2: 115.00
B+: M5
Posisjon/B+ i min.: 5
D+ Størrelse: Plugg
Rotasjon: SIRKULÆR
Plugg nr.: PL185
W plugg type: Plugg
Total lengde mm: 220.00
Lysstoffrør type: Aktiv
Drev: DP
Spenningsregulator type: IR
Prod. info: BN

Filer

Spesifikasjon

B+ M5
Mount. bracket dist. 68.00
Belt. adj. bracket hole 1 13.20
Belt. adj. brackethole pos. 60
Plug no. PL185
Bracket hole 15.00
Position/B+ in min. 5
Prod. info BN
Pulley DP
Pulley dia. 82.00
Pulley dist. 60.00
Radius 110.00
D+ Size Plug
Radius 2 115.00
Regulator type IR
Rotation CW
Grooves/pulley 2
Terminal W
Lamp type Active
Voltage 28
W plug type Plug
Total length 220.00 mm
Width/holder arm 16.00
Amp 40

  • OEM
    0-35000-0013, 0-35000-3010, 0-35000-3011, 0-35000-3012, 0-35000-3013, 0-35000-3113, 0-35000-3410, F032115994, 714-40321, 1812002491, 1812002493

  • Konkurrentreferens
    A9266S, CAL50627, DRA1255, LRA03203, 48-5815, 266.003.050, 543.129.404, 111364, 553031RI

  • NormaliseratArtNr
    a9266s, cal50627, dra1255, f032115994, lra03203, 111364, 485815, 553031ri, 71440321, 266003050, 0350000013, 0350003010, 0350003011, 0350003012, 0350003013, 0350003113, 0350003410, 543129404, 1812002491, 1812002493

  • Passar modeller
    Hitachi Model: EX120 Model series: EX120 Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    Hitachi Model: EX130 Model series: EX130 Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    Hitachi Model: EX135 Model series: EX135 Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    Hitachi Model: EX150 Model series: EX150 Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    Hitachi Model: Zaxis 120 Model series: Zaxis 120 Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    Hitachi Model: ZX110 Model series: ZX110 Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    Hitachi Model: ZX120 Model series: ZX120 Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    Hitachi Model: ZX130H Model series: ZX130H Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    Hitachi Model: ZX135 Model series: ZX135 Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    Hitachi Model: ZX135US Model series: ZX135US Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    Isuzu Model: Various Industrial applications Approved: Yes
    JCB Model: JS130 Model series: JS130 Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    JCB Model: JS130 SERIES Model series: JS130 SERIES Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    JCB Model: JS130L Model series: JS130L Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    JCB Model: JS130LC Model series: JS130LC Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    JCB Model: JS130W Model series: JS130W Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    JCB Model: JS145W Model series: JS145W Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    JCB Model: JS160 Model series: JS160 Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    JCB Model: JS160L/NL Model series: JS160L/NL Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    JCB Model: JS160W Model series: JS160W Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    JCB Model: JS180L Model series: JS180L Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    JCB Model: JS220LR Model series: JS220LR Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    JCB Model: JZ140 SERIES Model series: JZ140 SERIES Model type: Excavators Brand of engine: 4BG1T Approved: Yes
    Takeuchi Model: TB1140 Model series: TB1140 Model type: Excavators Brand of engine: 4BG1T Approved: Yes
