HC-Cargo Startmotor
HC-Cargo Startmotor
Varenr.: F032113938

HC-Cargo Startmotor

Teknisk info:

Spenningsregulator: 12, kW: 2,7, No./tenner: 11, Rotasjon: medurssving

Beskrivelse

Spenningskilde: 12
kW: 2,7
Festebraktning: 82,50
Drevavstand: 18,00
Festeborrel 2 mm: 13,50
Avstand/bak: 202,00
Avstand/frem: 44,00
Antall/tenner: 11
B+: M10
Posisjon/50: 15
Kontakt 50: Plugg
Gevær type: GR
Avstand mm: 129,50
Rotasjon: medur
Total lengde mm: 258,00
Antall/festebor: 2 (1)

Filer

Spesifikasjon

B+ M10
No./teeth 11
Mount. flange 82.50
No./mount. holes 2 (1)
Position/50 15
Rotation CW
Dist./back 202.00
Dist./front 44.00
Drive dist. 18.00
Gear type GR
kW 2.7
Terminal 50 Plug
Voltage 12
Total length 258.00 mm
Dist. 129.50 mm
Mount. hole 2 13.50 mm

  • OEM
    cs1447, F032113938, js1155, RGO 113938, 1986S00913, 28100-30050, 28100-30051, 28100-30070, 28100-30071, 28100-30080, 28100-30081, 28100-67070, 28100-67090, 228000-5340, 228000-5341, 228000-5342, 228000-5650, 228000-5651, 228000-5652, 428000-0290, 428000-0291, 428000-1370, 428000-1371, 428000-3110

  • Konkurrentreferens
    CST40239, CST40379, DRS0434, drs3965, DSN1229, F042S0H078, J5212113, LES0639, LRS02217, LRS02374, S6021, STR-H078, 8EA012527-341, 8EA737760-001, 25-2447, 25-3388, 25-4046, 190.930.112, 335.065.112, 335.069.112, 335.224.112, 9728, 18630AN, 33217N, 101447, 105404, 201155, 201163, 220789, 220789A, 458865, 8052287, 8212807, 11040632, 11040770, 0986020591, 0986024320

  • NormaliseratArtNr
    cs1447, cst40239, cst40379, drs0434, drs3965, dsn1229, f032113938, f042s0h078, j5212113, js1155, les0639, lrs02217, lrs02374, rgo113938, s6021, strh078, 8ea012527341, 8ea737760001, 1986s00913, 9728, 18630an, 33217n, 101447, 105404, 201155, 201163, 220789, 220789a, 252447, 253388, 254046, 458865, 8052287, 8212807, 11040632, 11040770, 190930112, 335065112, 335069112, 335224112, 0986020591, 0986024320, 2280005340, 2280005341, 2280005342, 2280005650, 2280005651, 2280005652, 2810030050, 2810030051, 2810030070, 2810030071, 2810030080, 2810030081, 2810067070, 2810067090, 4280000290, 4280000291, 4280001370, 4280001371, 4280003110

  • Passar modeller
    Toyota Model: Dyna Model series: Dyna Type of engine: D-4D Size of motor: 2.5 Brand of engine: 2KD-FTV Type description: KD_, LY_ Body: Platform / Chassis From date: 01-07-2001 Fuel: Diesel Approved: Yes
    Toyota Model: Dyna Model series: Dyna Type of engine: D-4D Size of motor: 3.0 Type description: KD_, LY_ Body: Platform / Chassis From date: 01-09-2006 Fuel: Diesel Approved: Yes
    Toyota Model: Hiace Model series: Hiace Bus Model type: D-4D (KDH200) Type of engine: Diesel Size of motor: 2.5 Brand of engine: 2KD-FTV Body: Bus Fuel: Diesel Approved: Yes
    Toyota Model: Hiace Model series: Hiace Model type: 4WD Type of engine: D-4D Size of motor: 2.5 Brand of engine: 2KD-FTV Body: Bus From date: 01-11-2001 To date: 01-08-2006 Fuel: Diesel Approved: Yes
    Toyota Model: Hiace Model series: Hiace Model type: 4WD Type of engine: D-4D Size of motor: 2.5 Brand of engine: 2KD-FTV Type description: _H1_, _H2_ Body: Van From date: 01-08-2001 To date: 01-08-2006 Fuel: Diesel Approved: Yes
    Toyota Model: Hiace Model series: Hiace Model type: 4x4 Type of engine: D-4D Size of motor: 2.5 Brand of engine: 2KD-FTV Body: Bus From date: 01-09-2006 To date: 01-12-2012 Fuel: Diesel Approved: Yes
    Toyota Model: Hiace Model series: Hiace Type of engine: D-4D Size of motor: 2.5 Brand of engine: 2KD-FTV Body: Bus From date: 01-08-2001 To date: 01-08-2006 Fuel: Diesel Approved: Yes
    Toyota Model: Hiace Model series: Hiace Type of engine: D-4D Size of motor: 2.5 Brand of engine: 2KD-FTV Body: Bus From date: 01-08-2001 To date: 01-08-2006 Fuel: Diesel Approved: Yes Manufacture type: wagon
    Toyota Model: Hiace Model series: Hiace Type of engine: D-4D Size of motor: 2.5 Brand of engine: 2KD-FTV Body: Van From date: 01-08-2001 To date: 01-08-2006 Fuel: Diesel Approved: Yes
    Toyota Model: Hiace Model series: Hiace Type of engine: D-4D Size of motor: 2.5 Brand of engine: 2KD-FTV Body: Van From date: 01-09-2006 To date: 01-12-2012 Fuel: Diesel Approved: Yes
    Toyota Model: Hiace Model series: Hiace Type of engine: D-4D Size of motor: 2.5 Brand of engine: 2KD-FTV Type description: _H1_ ,_H2_ Body: Bus From date: 01-08-2006 To date: 01-12-2012 Fuel: Diesel Approved: Yes
    Toyota Model: Hiace Model series: Hiace Type of engine: D-4D Size of motor: 2.5 Brand of engine: 2KD-FTV Type description: _H1_, _H2_ Body: Bus From date: 01-09-2006 To date: 01-12-2012 Fuel: Diesel Approved: Yes
    Toyota Model: Hilux Model series: Hilux Model type: 4WD Type of engine: D-4D Size of motor: 2.5 Brand of engine: 2KD-FTV Body: Pick Up From date: 01-11-2001 To date: 01-07-2005 Fuel: Diesel Approved: Yes
    Toyota Model: Hilux Model series: Hilux Model type: 4WD Type of engine: D-4D Size of motor: 2.5 Brand of engine: 2KD-FTV Type description: TGN1_, GGN2_, LAN_, GGN1_, KUN Body: Pick Up From date: 01-11-2004 To date: 01-12-2005 Fuel: Diesel Approved: Yes
    Toyota Model: Hilux Model series: Hilux Type of engine: D-4D Size of motor: 2.5 Brand of engine: 2KD-FTV Body: Pick Up From date: 01-11-2001 To date: 01-07-2005 Fuel: Diesel Approved: Yes
    Toyota Model: Land Cruiser Model series: Land Cruiser 150 Type of engine: TDi Size of motor: 3.0 Brand of engine: 1KD-FTV Type description: KDJ15_, GRJ15_ From date: 01-08-2009 Fuel: Diesel Approved: Yes
    Toyota Model: Land Cruiser Model series: Land Cruiser Model type: 150 Type of engine: D-4D Size of motor: 3.0 Brand of engine: 1KD-FTV Type description: J15 From date: 01-08-2009 Fuel: Diesel Approved: Yes
    Toyota Model: Land Cruiser Model series: Land Cruiser Model type: 4WD Type of engine: TD Size of motor: 3.0 Brand of engine: 1KZ-TE From date: 01-04-1996 To date: 01-12-2002 Fuel: Diesel Approved: Yes
    Toyota Model: Land Cruiser Model series: Land Cruiser Model type: D-4D 3.5t 4x4 (GDJL76R, G Type of engine: Diesel Size of motor: 2.8 Brand of engine: 1GD-FTV Type description: _J7_, _JL7_ Body: Closed Off-Road Vehicle Fuel: Diesel Approved: Yes
    Toyota Model: Land Cruiser Model series: Land Cruiser Prado Type of engine: D-4D Size of motor: 2.8 Brand of engine: 1GD-FTV Type description: _J15_ From date: 01-07-2020 Fuel: Diesel Approved: Yes
    Toyota Model: Land Cruiser Model series: Land Cruiser Type of engine: D-4D Size of motor: 3.0 Brand of engine: 1KD-FTV From date: 01-09-2002 To date: 01-08-2009 Fuel: Diesel Approved: Yes
    Toyota Model: Land Cruiser Model series: Land Cruiser Type of engine: D-4D Size of motor: 3.0 Brand of engine: 1KD-FTV Type description: J12 From date: 01-07-2004 To date: 01-08-2009 Fuel: Diesel Approved: Yes
    Toyota Model: Land Cruiser Model series: Land Cruiser Type of engine: D-4D Size of motor: 3.0 Brand of engine: 1KD-FTV Type description: J12 From date: 01-09-2002 To date: 01-12-2010 Fuel: Diesel Approved: Yes
    Toyota Model: Land Cruiser Model series: Land Cruiser Type of engine: D-4D Size of motor: 3.0 Brand of engine: 1KD-FTV Type description: J15 From date: 01-08-2009 Fuel: Diesel Approved: Yes
    Toyota Model: Land Cruiser Model series: Land Cruiser Type of engine: D-4D Size of motor: 3.0 Brand of engine: 1KD-FTV Type description: _J9_ From date: 01-08-2000 To date: 01-08-2002 Fuel: Diesel Approved: Yes
    Toyota Model: Land Cruiser Model series: Land Cruiser Type of engine: Diesel Size of motor: 2.8 Brand of engine: 1GD-FTV Type description: KDJ15_, GRJ15_ From date: 01-06-2015 Fuel: Diesel Approved: Yes
    Toyota Model: Land Cruiser Model series: Land Cruiser Van Model type: 4WD Type of engine: D4-D Size of motor: 3.0 Brand of engine: 1KD-FTV Type description: _J15_ From date: 01-01-2011 Fuel: Diesel Approved: Yes
    Toyota Model: Land Model series: Land Type of engine: D-4D Size of motor: 2.8 Brand of engine: 1GD-FTV Type description: _J15_ Body: Closed Off-Road Vehicle From date: 01-10-2018 Fuel: Diesel Approved: Yes
    Toyota Model: Land Model series: Land Type of engine: TD Size of motor: 3.0 Brand of engine: 1KZ-TE Type description: _J9_ Body: Closed Off-Road Vehicle From date: 01-03-2000 To date: 01-02-2003 Fuel: Diesel Approved: Yes
