Varenr.: F032111303

HC-Cargo Startmotor

Teknisk info:

Spenningsregulator: 12, kW: 0.8, Ant./tenner: 8, Rotasjon: CW

Beskrivelse

Nissan Primera 1.6L 93>, Start 12V - 1,2/1,4 kW, 8 tannhjul For Yourrex produktordre 91-400-0533

Spenning: 12
kW: 0,8
Festerende flens: 70,00
Drivingsavstand: 11,00
Festeringshull 2 mm: M10-1.50
Festeringshull 1 mm: 11,00
Avstand/bak: 160,50
Avstand/frem: 48,00
Antall/tannhjul: 8
B+: M8
Terminal 50: 6,30
Girtype: DD/GR
Avstand mm: 106,00
Rotasjon: med urviseren
Total lengde mm: 208,50
Drevtype: Stål
Prod. info: BN
Vanntett: Nei
Oljelagt: Nei
Antall/festeringshull: 2 (1)

Spesifikasjon

B+ M8
No./teeth 8
Mount. flange 70.00
Oil sealed No
No./mount. holes 2 (1)
Prod. info BN
Rotation CW
Dist./back 160.50
Dist./front 48.00
Drive dist. 11.00
Drive type Steel
Gear type DD/GR
kW 0.8
Terminal 50 6.30
Voltage 12
Total length 208.50 mm
Waterproof No
Dist. 106.00 mm
Mount. hole 2 M10-1.50 mm
Mount. hole 1 11.00 mm
  • OEM

    B330M70J00EX, F032111303, js672, M000T70281, M000T70285, M002T41171, M002T48681, m0t70281, m0t70285, M1T-72085, M1T-72086, M1T-72087, m2t41171, m2t48681, RGO 111303, S114-530, S114-533, s114-570, s114-570a, s114-570b, s114-570c, S114-750, s114-758, S114-766, s114-775, s114-775a, 23300-0M300, 23300-50Y00, 23300-50Y01, 23300-50y02, 23300-50Y04, 23300-50y12, 23300-50y14, 23300-53y00, 23300-53y01, 23300-65y10, 23300-70j00, 23300-70j01, 23300-70j02, 23300-70j03, 23300-73y00, 23300-73y01, 23300-73y10, 23300-81N00, 23300-81N01, 23300-81N10, 23300-81N11, 23300-95f0a, 23300-95f0b, 23300-95f0c, 26667, 26814, 26814a, 26814B, 26814D, 27022, 27043, 27047, 111303, 63227051
  • Konkurrentreferens

    ads-170, BSO7164, BSO7216, CST20124, drs3164, drs3608, F042200085, F042200102, F042S0H022, FRS599, lrs00704, lrs00711, QS1423, S2072S, S5382S, STR-H022, STR3010, STR72018, STR72040, 8ea730260-001, 8ea732668-001, 25-1349, 25-1458, 28-52.155, 327.048.082, 327.052.082, 327.068.082, 4243, 4303, 9568, 11705, 17146N, 20672, 104144, 104662, 455583, 455884, 11040162, 11040180, 063227046, 0986016581, 063227051010
  • Bilmärken

    Nissan
  • NormaliseratArtNr

    ads170, b330m70j00ex, bso7164, bso7216, cst20124, drs3164, drs3608, f032111303, f042200085, f042200102, f042s0h022, frs599, js672, lrs00704, lrs00711, m000t70281, m000t70285, m002t41171, m002t48681, m0t70281, m0t70285, m1t72085, m1t72086, m1t72087, m2t41171, m2t48681, qs1423, rgo111303, s114530, s114533, s114570, s114570a, s114570b, s114570c, s114750, s114758, s114766, s114775, s114775a, s2072s, s5382s, str3010, str72018, str72040, strh022, 8ea730260001, 8ea732668001, 4243, 4303, 9568, 11705, 17146n, 20672, 26667, 26814, 26814a, 26814b, 26814d, 27022, 27043, 27047, 104144, 104662, 111303, 233000m300, 251349, 251458, 455583, 455884, 2330050y00, 2330050y01, 2330050y02, 2330050y04, 2330050y12, 2330050y14, 2330053y00, 2330053y01, 2330065y10, 2330070j00, 2330070j01, 2330070j02, 2330070j03, 2330073y00, 2330073y01, 2330073y10, 2330081n00, 2330081n01, 2330081n10, 2330081n11, 2330095f0a, 2330095f0b, 2330095f0c, 2852155, 11040162, 11040180, 063227046, 63227051, 327048082, 327052082, 327068082, 0986016581, 063227051010
  • Passar modeller

    Nissan Model: Almera Model series: Almera Size of motor: 1.6 Brand of engine: QG16DE Type description: N16 Body: Saloon From date: 01-06-2000 To date: 01-12-2009 Fuel: Petrol Approved: Yes
    Nissan Model: Primera Model series: Primera Size of motor: 1.6 Brand of engine: GA16DE Body: Hatchback From date: 01-06-1993 To date: 01-01-1996 Fuel: Gasoline Approved: Yes
    Nissan Model: Primera Model series: Primera Size of motor: 1.6 Brand of engine: GA16DS Body: Hatchback From date: 01-06-1990 To date: 01-06-1993 Fuel: Gasoline Approved: Yes
    Nissan Model: Primera Model series: Primera Size of motor: 1.6 Brand of engine: GA16DS Type description: P10 Body: Hatchback From date: 01-06-1990 To date: 01-01-1996 Fuel: Gasoline Approved: Yes
    Nissan Model: Primera Model series: Primera Size of motor: 1.6 Brand of engine: GA16DS Type description: P10 From date: 01-06-1990 To date: 01-01-1996 Fuel: Gasoline Approved: Yes
    Nissan Model: Primera Model series: Primera Type of engine: i Size of motor: 1.6 Brand of engine: GA16DS Type description: W10 Body: Estate From date: 01-07-1990 To date: 01-03-1998 Fuel: Gasoline Approved: Yes
    Nissan Series: 100 NX Model: 1.6 SR Engine volume: 1.6 Engine type: GA 16 DE Year: 09.93-10.94
    Nissan Series: 100 NX Model: 1.6 Engine volume: 1.6 Engine type: GA 16 DS Year: 03.90-10.94
    Nissan Series: Primera (P/W10) Model: 1.6 Engine volume: 1.6 Engine type: GA 16 DE/DS Year: 07.90-03.98
    Nissan Series: Sunny III (N14) Model: 1.6 16V AUT Engine volume: 1.6 Engine type: GA 16 DS Year: 10.90-10.92
    Nissan Series: Sunny III (N14) Model: 1.6i 16V AUT Engine volume: 1.6 Engine type: GA 16 DE Year: 10.92-05.95
    Nissan Series: Sunny III Kombi Model: 1.6 16V AUT Engine volume: 1.6 Engine type: GA 16 DS Year: 06.91-10.92
    Nissan Series: Sunny III Kombi Model: 1.6i 16V AUT Engine volume: 1.6 Engine type: GA 16 DE Year: 10.92-
    1 / 3
  • Beskrivelse
    Nissan Primera 1.6L 93>, Start 12V - 1,2/1,4 kW, 8 tannhjul For Yourrex produktordre 91-400-0533

    Spenning: 12
    kW: 0,8
    Festerende flens: 70,00
    Drivingsavstand: 11,00
    Festeringshull 2 mm: M10-1.50
    Festeringshull 1 mm: 11,00
    Avstand/bak: 160,50
    Avstand/frem: 48,00
    Antall/tannhjul: 8
    B+: M8
    Terminal 50: 6,30
    Girtype: DD/GR
    Avstand mm: 106,00
    Rotasjon: med urviseren
    Total lengde mm: 208,50
    Drevtype: Stål
    Prod. info: BN
    Vanntett: Nei
    Oljelagt: Nei
    Antall/festeringshull: 2 (1)
  • Spesifikasjon
    B+ M8
    No./teeth 8
    Mount. flange 70.00
    Oil sealed No
    No./mount. holes 2 (1)
    Prod. info BN
    Rotation CW
    Dist./back 160.50
    Dist./front 48.00
    Drive dist. 11.00
    Drive type Steel
    Gear type DD/GR
    kW 0.8
    Terminal 50 6.30
    Voltage 12
    Total length 208.50 mm
    Waterproof No
    Dist. 106.00 mm
    Mount. hole 2 M10-1.50 mm
    Mount. hole 1 11.00 mm
  • Kjøretøymatching
    • OEM

      B330M70J00EX, F032111303, js672, M000T70281, M000T70285, M002T41171, M002T48681, m0t70281, m0t70285, M1T-72085, M1T-72086, M1T-72087, m2t41171, m2t48681, RGO 111303, S114-530, S114-533, s114-570, s114-570a, s114-570b, s114-570c, S114-750, s114-758, S114-766, s114-775, s114-775a, 23300-0M300, 23300-50Y00, 23300-50Y01, 23300-50y02, 23300-50Y04, 23300-50y12, 23300-50y14, 23300-53y00, 23300-53y01, 23300-65y10, 23300-70j00, 23300-70j01, 23300-70j02, 23300-70j03, 23300-73y00, 23300-73y01, 23300-73y10, 23300-81N00, 23300-81N01, 23300-81N10, 23300-81N11, 23300-95f0a, 23300-95f0b, 23300-95f0c, 26667, 26814, 26814a, 26814B, 26814D, 27022, 27043, 27047, 111303, 63227051
    • Konkurrentreferens

      ads-170, BSO7164, BSO7216, CST20124, drs3164, drs3608, F042200085, F042200102, F042S0H022, FRS599, lrs00704, lrs00711, QS1423, S2072S, S5382S, STR-H022, STR3010, STR72018, STR72040, 8ea730260-001, 8ea732668-001, 25-1349, 25-1458, 28-52.155, 327.048.082, 327.052.082, 327.068.082, 4243, 4303, 9568, 11705, 17146N, 20672, 104144, 104662, 455583, 455884, 11040162, 11040180, 063227046, 0986016581, 063227051010
    • Bilmärken

      Nissan
    • NormaliseratArtNr

      ads170, b330m70j00ex, bso7164, bso7216, cst20124, drs3164, drs3608, f032111303, f042200085, f042200102, f042s0h022, frs599, js672, lrs00704, lrs00711, m000t70281, m000t70285, m002t41171, m002t48681, m0t70281, m0t70285, m1t72085, m1t72086, m1t72087, m2t41171, m2t48681, qs1423, rgo111303, s114530, s114533, s114570, s114570a, s114570b, s114570c, s114750, s114758, s114766, s114775, s114775a, s2072s, s5382s, str3010, str72018, str72040, strh022, 8ea730260001, 8ea732668001, 4243, 4303, 9568, 11705, 17146n, 20672, 26667, 26814, 26814a, 26814b, 26814d, 27022, 27043, 27047, 104144, 104662, 111303, 233000m300, 251349, 251458, 455583, 455884, 2330050y00, 2330050y01, 2330050y02, 2330050y04, 2330050y12, 2330050y14, 2330053y00, 2330053y01, 2330065y10, 2330070j00, 2330070j01, 2330070j02, 2330070j03, 2330073y00, 2330073y01, 2330073y10, 2330081n00, 2330081n01, 2330081n10, 2330081n11, 2330095f0a, 2330095f0b, 2330095f0c, 2852155, 11040162, 11040180, 063227046, 63227051, 327048082, 327052082, 327068082, 0986016581, 063227051010
    • Passar modeller

      Nissan Model: Almera Model series: Almera Size of motor: 1.6 Brand of engine: QG16DE Type description: N16 Body: Saloon From date: 01-06-2000 To date: 01-12-2009 Fuel: Petrol Approved: Yes
      Nissan Model: Primera Model series: Primera Size of motor: 1.6 Brand of engine: GA16DE Body: Hatchback From date: 01-06-1993 To date: 01-01-1996 Fuel: Gasoline Approved: Yes
      Nissan Model: Primera Model series: Primera Size of motor: 1.6 Brand of engine: GA16DS Body: Hatchback From date: 01-06-1990 To date: 01-06-1993 Fuel: Gasoline Approved: Yes
      Nissan Model: Primera Model series: Primera Size of motor: 1.6 Brand of engine: GA16DS Type description: P10 Body: Hatchback From date: 01-06-1990 To date: 01-01-1996 Fuel: Gasoline Approved: Yes
      Nissan Model: Primera Model series: Primera Size of motor: 1.6 Brand of engine: GA16DS Type description: P10 From date: 01-06-1990 To date: 01-01-1996 Fuel: Gasoline Approved: Yes
      Nissan Model: Primera Model series: Primera Type of engine: i Size of motor: 1.6 Brand of engine: GA16DS Type description: W10 Body: Estate From date: 01-07-1990 To date: 01-03-1998 Fuel: Gasoline Approved: Yes
      Nissan Series: 100 NX Model: 1.6 SR Engine volume: 1.6 Engine type: GA 16 DE Year: 09.93-10.94
      Nissan Series: 100 NX Model: 1.6 Engine volume: 1.6 Engine type: GA 16 DS Year: 03.90-10.94
      Nissan Series: Primera (P/W10) Model: 1.6 Engine volume: 1.6 Engine type: GA 16 DE/DS Year: 07.90-03.98
      Nissan Series: Sunny III (N14) Model: 1.6 16V AUT Engine volume: 1.6 Engine type: GA 16 DS Year: 10.90-10.92
      Nissan Series: Sunny III (N14) Model: 1.6i 16V AUT Engine volume: 1.6 Engine type: GA 16 DE Year: 10.92-05.95
      Nissan Series: Sunny III Kombi Model: 1.6 16V AUT Engine volume: 1.6 Engine type: GA 16 DS Year: 06.91-10.92
      Nissan Series: Sunny III Kombi Model: 1.6i 16V AUT Engine volume: 1.6 Engine type: GA 16 DE Year: 10.92-
