HC-Cargo Startmotor
HC-Cargo Startmotor
Varenr.: F032111061

HC-Cargo Startmotor

Teknisk info:

Spenningsregulator: 12 V, KW: 0.8, Antall.tannhjul: 9, Rotasjon: Moturs

Beskrivelse

Spenning: 12
kW: 0.8
Monteringsflens: 76.00
Drivingsavstand: 44.50
Monteringshull 2 mm: 11.80
Monteringshull 1 mm: 10.50
Avstand/bak: 143.00
Avstand/frem: 78.00
Antall/tannhjul: 9
B+: M8
Posisjon/50: 15
Terminal 50: 6.30
Gavltype: DD/GR
Avstand mm: 105.00
Rotasjon: Mot klokken
Total lengde mm: 230.00
Drevtype: Stål
Prod. info: BN
Vanntett: Nei
Oljeforseglet: Nei
Merknader: Bøssing D.E. (clutch house): HC-CARGO 140008.
Antall/monteringshull: 2 (0)

Filer

Spesifikasjon

B+ M8
No./teeth 9
Mount. flange 76.00
Oil sealed No
No./mount. holes 2 (0)
Position/50 15
Prod. info BN
Remarks Bushing D.E. (clutch house): HC-CARGO 140008.
Rotation CCW
Dist./back 143.00
Dist./front 78.00
Drive dist. 44.50
Drive type Steel
Gear type DD/GR
kW 0.8
Terminal 50 6.30
Voltage 12
Total length 230.00 mm
Waterproof No
Dist. 105.00 mm
Mount. hole 2 11.80 mm
Mount. hole 1 10.50 mm

  • OEM
    cs298, F032111061, 0001211251, 0001211252, 0001211253, 0001211254, 1516725R, 091911023a, 091911023ax, 091911023b, 091911023bx

  • Konkurrentreferens
    drs0470, lrs00559, QS1476, SR19X, STR50053, 2-1359-BO, 2-1449-BO, 8ea726057-001, 25-0457, 41-10.470, 311.003.092, 1141, 3639, 10298, 11397, 16722R, 103391, 220356, 220356A, 433335, 8010470, 11010470, 66925378, 943221670, 943251670, 0986010470, 0986010477, 943251670010, 944280104700

  • NormaliseratArtNr
    cs298, drs0470, f032111061, lrs00559, qs1476, sr19x, str50053, 8ea726057001, 1141, 3639, 10298, 11397, 16722r, 21359bo, 21449bo, 103391, 220356, 220356a, 250457, 433335, 0001211251, 0001211252, 0001211253, 0001211254, 1516725r, 4110470, 8010470, 11010470, 66925378, 091911023a, 091911023ax, 091911023b, 091911023bx, 311003092, 943221670, 943251670, 0986010470, 0986010477, 943251670010, 944280104700

  • Passar modeller
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.6 Brand of engine: CT Body: Bus From date: 01-05-1979 To date: 01-12-1982 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.6 Brand of engine: CT Body: Van From date: 01-05-1979 To date: 01-12-1982 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DF Body: Bus From date: 01-08-1982 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DF Body: Van From date: 01-10-1982 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DG Body: Bus From date: 01-08-1982 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DG Body: Van From date: 01-10-1982 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DH Body: Bus From date: 01-01-1983 To date: 01-07-1985 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DH Body: Platform / Chassis From date: 01-10-1984 To date: 01-02-1989 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DH Body: Van From date: 01-10-1984 To date: 01-02-1989 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: GW Body: Bus From date: 01-08-1983 To date: 01-07-1985 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: GW Body: Van From date: 01-08-1983 To date: 01-02-1989 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.0 Brand of engine: CU Body: Bus From date: 01-05-1979 To date: 01-12-1982 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.0 Brand of engine: CU Body: Platform / Chassis From date: 01-05-1979 To date: 01-04-1986 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.0 Brand of engine: CU Body: Van From date: 01-05-1979 To date: 01-04-1986 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: DJ Body: Bus From date: 01-08-1984 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: DJ Body: Platform / Chassis From date: 01-03-1986 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: DJ Body: Van From date: 01-03-1986 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: MV Body: Bus From date: 01-06-1989 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: MV Body: Bus From date: 01-08-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: MV Body: Platform / Chassis From date: 01-08-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: MV Body: Van From date: 01-08-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: SS Body: Bus From date: 01-07-1989 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 1.9 Brand of engine: DG Body: Bus From date: 01-02-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 1.9 Brand of engine: DG Body: Platform / Chassis From date: 01-12-1984 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 1.9 Brand of engine: DG Body: Van From date: 01-11-1984 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 2.1 Brand of engine: DJ Body: Bus From date: 01-01-1986 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 2.1 Brand of engine: DJ Body: Platform / Chassis From date: 01-03-1986 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 2.1 Brand of engine: DJ Body: Van From date: 01-03-1986 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 2.1 Brand of engine: MV Body: Bus From date: 01-08-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 2.1 Brand of engine: MV Body: Platform / Chassis From date: 01-08-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 2.1 Brand of engine: MV Body: Van From date: 01-08-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
    1 / 7
  • Beskrivelse
    Spenning: 12
    kW: 0.8
    Monteringsflens: 76.00
    Drivingsavstand: 44.50
    Monteringshull 2 mm: 11.80
    Monteringshull 1 mm: 10.50
    Avstand/bak: 143.00
    Avstand/frem: 78.00
    Antall/tannhjul: 9
    B+: M8
    Posisjon/50: 15
    Terminal 50: 6.30
    Gavltype: DD/GR
    Avstand mm: 105.00
    Rotasjon: Mot klokken
    Total lengde mm: 230.00
    Drevtype: Stål
    Prod. info: BN
    Vanntett: Nei
    Oljeforseglet: Nei
    Merknader: Bøssing D.E. (clutch house): HC-CARGO 140008.
    Antall/monteringshull: 2 (0)

    Filer

  • Spesifikasjon
    B+ M8
    No./teeth 9
    Mount. flange 76.00
    Oil sealed No
    No./mount. holes 2 (0)
    Position/50 15
    Prod. info BN
    Remarks Bushing D.E. (clutch house): HC-CARGO 140008.
    Rotation CCW
    Dist./back 143.00
    Dist./front 78.00
    Drive dist. 44.50
    Drive type Steel
    Gear type DD/GR
    kW 0.8
    Terminal 50 6.30
    Voltage 12
    Total length 230.00 mm
    Waterproof No
    Dist. 105.00 mm
    Mount. hole 2 11.80 mm
    Mount. hole 1 10.50 mm
  • Kjøretøymatching

    • OEM
      cs298, F032111061, 0001211251, 0001211252, 0001211253, 0001211254, 1516725R, 091911023a, 091911023ax, 091911023b, 091911023bx

    • Konkurrentreferens
      drs0470, lrs00559, QS1476, SR19X, STR50053, 2-1359-BO, 2-1449-BO, 8ea726057-001, 25-0457, 41-10.470, 311.003.092, 1141, 3639, 10298, 11397, 16722R, 103391, 220356, 220356A, 433335, 8010470, 11010470, 66925378, 943221670, 943251670, 0986010470, 0986010477, 943251670010, 944280104700

    • NormaliseratArtNr
      cs298, drs0470, f032111061, lrs00559, qs1476, sr19x, str50053, 8ea726057001, 1141, 3639, 10298, 11397, 16722r, 21359bo, 21449bo, 103391, 220356, 220356a, 250457, 433335, 0001211251, 0001211252, 0001211253, 0001211254, 1516725r, 4110470, 8010470, 11010470, 66925378, 091911023a, 091911023ax, 091911023b, 091911023bx, 311003092, 943221670, 943251670, 0986010470, 0986010477, 943251670010, 944280104700

    • Passar modeller
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.6 Brand of engine: CT Body: Bus From date: 01-05-1979 To date: 01-12-1982 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.6 Brand of engine: CT Body: Van From date: 01-05-1979 To date: 01-12-1982 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DF Body: Bus From date: 01-08-1982 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DF Body: Van From date: 01-10-1982 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DG Body: Bus From date: 01-08-1982 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DG Body: Van From date: 01-10-1982 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DH Body: Bus From date: 01-01-1983 To date: 01-07-1985 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DH Body: Platform / Chassis From date: 01-10-1984 To date: 01-02-1989 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: DH Body: Van From date: 01-10-1984 To date: 01-02-1989 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: GW Body: Bus From date: 01-08-1983 To date: 01-07-1985 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 1.9 Brand of engine: GW Body: Van From date: 01-08-1983 To date: 01-02-1989 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.0 Brand of engine: CU Body: Bus From date: 01-05-1979 To date: 01-12-1982 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.0 Brand of engine: CU Body: Platform / Chassis From date: 01-05-1979 To date: 01-04-1986 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.0 Brand of engine: CU Body: Van From date: 01-05-1979 To date: 01-04-1986 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: DJ Body: Bus From date: 01-08-1984 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: DJ Body: Platform / Chassis From date: 01-03-1986 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: DJ Body: Van From date: 01-03-1986 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: MV Body: Bus From date: 01-06-1989 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: MV Body: Bus From date: 01-08-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: MV Body: Platform / Chassis From date: 01-08-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: MV Body: Van From date: 01-08-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Size of motor: 2.1 Brand of engine: SS Body: Bus From date: 01-07-1989 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 1.9 Brand of engine: DG Body: Bus From date: 01-02-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 1.9 Brand of engine: DG Body: Platform / Chassis From date: 01-12-1984 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 1.9 Brand of engine: DG Body: Van From date: 01-11-1984 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 2.1 Brand of engine: DJ Body: Bus From date: 01-01-1986 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 2.1 Brand of engine: DJ Body: Platform / Chassis From date: 01-03-1986 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 2.1 Brand of engine: DJ Body: Van From date: 01-03-1986 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 2.1 Brand of engine: MV Body: Bus From date: 01-08-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 2.1 Brand of engine: MV Body: Platform / Chassis From date: 01-08-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
      VW Model: Transporter Model series: Transporter Model type: T3 Syncro Size of motor: 2.1 Brand of engine: MV Body: Van From date: 01-08-1985 To date: 01-07-1992 Fuel: Gasoline Approved: Yes
