HC-Cargo Startmotor
HC-Cargo Startmotor
Varenr.: F032113356

HC-Cargo Startmotor

Teknisk info:

Spenningsregulator: 24, kW: 3.5, No./tenner: 10, Rotasjon: CW

Beskrivelse

Spenning: 24
kW: 3,5
Monteringsflens: 100,00
Drevavstand: 32,00
Monteringshull 3 mm: 13,00
Monteringshull 2 mm: 13,00
Monteringshull 1 mm: 13,00
Avstand/bak: 200,50
Avstand/forside: 32,00
Num./tenner: 10
B+: M10
Posisjon/50: 15
Terminal 50: M5
Gavltype: GR
Avstand 2: 126,00
Avstand 3: 126,00
Avstand mm: 126,00
Rotasjon: medur
Total lengde mm: 235,00
Drevetype: Stål
Prod. info: BN
Vannavstøtende: Nei
Oljetett: Nei
Num./monteringhull: 3 (0)

Filer

Spesifikasjon

B+ M10
No./teeth 10
Mount. flange 100.00
Oil sealed No
No./mount. holes 3 (0)
Position/50 15
Prod. info BN
Dist. 2 126.00
Dist. 3 126.00
Rotation CW
Dist./back 200.50
Dist./front 32.00
Drive dist. 32.00
Drive type Steel
Gear type GR
kW 3.5
Terminal 50 M5
Voltage 24
Total length 235.00 mm
Waterproof No
Dist. 126.00 mm
Mount. hole 3 13.00 mm
Mount. hole 2 13.00 mm
Mount. hole 1 13.00 mm

  • OEM
    AZF4910, AZJ3223, AZJ3381, F032113356, 11.130.676, 11.131.104, 11.139.199, 9172702, 9172780, 20073708000

  • Konkurrentreferens
    IS1035, IS9497, LRS01945, ms1002, MS360, MS411, S9041, S9041(MAGNETON), S9093, S9093(LETRIKA), 45-3110, 231.509.103, 612.006.104, 18547N

  • NormaliseratArtNr
    azf4910, azj3223, azj3381, f032113356, is1035, is9497, lrs01945, ms1002, ms360, ms411, s9041, s9041magneton, s9093, s9093letrika, 18547n, 453110, 9172702, 9172780, 11130676, 11131104, 11139199, 231509103, 612006104, 20073708000

  • Passar modeller
    Belarus Model: MTZ Series Model series: MTZ 1221 Size of motor: 7.2 Brand of engine: D-260.2 Body: Tractor Approved: Yes
    Belarus Model: MTZ Series Model series: MTZ 1522 Size of motor: 7.2 Brand of engine: D-260.6 Approved: Yes
    Belarus Model: MTZ Series Model series: MTZ 890 Brand of engine: D-245.5 Approved: Yes
  • Beskrivelse
    Spenning: 24
    kW: 3,5
    Monteringsflens: 100,00
    Drevavstand: 32,00
    Monteringshull 3 mm: 13,00
    Monteringshull 2 mm: 13,00
    Monteringshull 1 mm: 13,00
    Avstand/bak: 200,50
    Avstand/forside: 32,00
    Num./tenner: 10
    B+: M10
    Posisjon/50: 15
    Terminal 50: M5
    Gavltype: GR
    Avstand 2: 126,00
    Avstand 3: 126,00
    Avstand mm: 126,00
    Rotasjon: medur
    Total lengde mm: 235,00
    Drevetype: Stål
    Prod. info: BN
    Vannavstøtende: Nei
    Oljetett: Nei
    Num./monteringhull: 3 (0)

    Filer

  • Spesifikasjon
    B+ M10
    No./teeth 10
    Mount. flange 100.00
    Oil sealed No
    No./mount. holes 3 (0)
    Position/50 15
    Prod. info BN
    Dist. 2 126.00
    Dist. 3 126.00
    Rotation CW
    Dist./back 200.50
    Dist./front 32.00
    Drive dist. 32.00
    Drive type Steel
    Gear type GR
    kW 3.5
    Terminal 50 M5
    Voltage 24
    Total length 235.00 mm
    Waterproof No
    Dist. 126.00 mm
    Mount. hole 3 13.00 mm
    Mount. hole 2 13.00 mm
    Mount. hole 1 13.00 mm
  • Kjøretøymatching

    • OEM
      AZF4910, AZJ3223, AZJ3381, F032113356, 11.130.676, 11.131.104, 11.139.199, 9172702, 9172780, 20073708000

    • Konkurrentreferens
      IS1035, IS9497, LRS01945, ms1002, MS360, MS411, S9041, S9041(MAGNETON), S9093, S9093(LETRIKA), 45-3110, 231.509.103, 612.006.104, 18547N

    • NormaliseratArtNr
      azf4910, azj3223, azj3381, f032113356, is1035, is9497, lrs01945, ms1002, ms360, ms411, s9041, s9041magneton, s9093, s9093letrika, 18547n, 453110, 9172702, 9172780, 11130676, 11131104, 11139199, 231509103, 612006104, 20073708000

    • Passar modeller
      Belarus Model: MTZ Series Model series: MTZ 1221 Size of motor: 7.2 Brand of engine: D-260.2 Body: Tractor Approved: Yes
      Belarus Model: MTZ Series Model series: MTZ 1522 Size of motor: 7.2 Brand of engine: D-260.6 Approved: Yes
      Belarus Model: MTZ Series Model series: MTZ 890 Brand of engine: D-245.5 Approved: Yes
